Benchmark test using QC-Calc
•
QC-Calc by Prolink Corporation
Issue 2: July 2007
•
QC-Calc by Prolink Corporation
•
Pre-installed on all machines
– Standard on Micron
– Option on instinctiv class with trial period after
installation
•
Accessed via DUI or desktop
•
Can be run in real time along with Dek software
Real-time graphical display
TOLERANCE
CONTROL LIMIT
PLOTTING LIMIT
PARAMETER NAME
(3) Theta Error (arcsec)
27.0000
Issue 2: July 2007
NOMINAL
DATA DETAILS
Cpk = 1.11
10.0474 14310.0474 143
-27.0000
0.0000
(3) Theta Error (arcsec)
27.0000
Real time Display-Compared to
bellcurve
Issue 2: July 2007
Cpk = 1.11
10.0474 14310.0474 143
-27.0000
0.0000
Tolerance
Range
Process
Width
Average (x)
