MACHINE PROGRAMMING
STAGE 5C - DEDICATED TOOLING
User Manual 1.37
29. Select Vision Height (F3). The message ‘Table at Vision Height. Check
Tooling Clearance’ is displayed.
30. Select Contact Height (F3).
The following window and menu bar is displayed:
31. Select Continue (F1). The message ‘Table at Contact Height. Check
Tooling Clearance’ is displayed.
32. Select Open Cover (F7).
33. Either:
a. Open the front printhead cover.
or
b. Raise the printhead shutter.
34. Check that the setup of the tooling is adequate for the board, adjust as
necessary.
NOTE
If adjustment is required, this can be carried out at Transport Height.
35. Either:
a. Close the front printhead cover.
or
b. Lower the printhead shutter.
36. Press the System button.
Unload
Vision
Height
Home
Height
Board
Clamps
Change
Screen
Open
Cover
Exit
Contact
Height
Tra nsp r t
Height
Change
Screen
Open
Cover
Exit
Contact Height Warning
WARNING Check for obstructions between
the Rails and the Screen
Continue
Open
Cover
Exit
Continue
Open
Cover
Exit
Vision
Height
Open
Cover
Exit
MACHINE PROGRAMMING
STAGE 5C - DEDICATED TOOLING
1.38 User Manual
37. Select Exit (F8).
38. Select Exit (F8).
The following window and menu bar is displayed:
39. Select Continue (F1).
40. Select Auto Board (F1). The message ‘Board on rails, remove and
continue’ is displayed.
41. Remove the board from the rails.
42. Select Continue (F1).
43. Either:
a. Open the front printhead cover.
or
b. Raise the printhead shutter and lower the drop down panel.
44. To adjust the width of the chase rails to accommodate the stencil for the
product file loaded, carry out the following (ASM only):
Exit
Vision
Height
Open
Cover
Exit
Leaving Generic Tooling
WARNING You are about to return
to the Setup Page
Clear all tooling setup
equipment before proceeding
Continue Exit
Continue Exit
Auto
Board
Manual
Board
Continue
Open
Cover
MACHINE PROGRAMMING
STAGE 5C - DEDICATED TOOLING
User Manual 1.39
a. Press and hold the left hand chase rail push button valve.
b. Slide the left hand chase rail to the desired position indicated on the
graduated scale.
c. Release the push button valve.
d. Repeat the procedure for the right hand chase rail.
45. If the stencil size is less than 29″ x 29″ the screen depth adjuster position is
to be adjusted as follows (ASM only):
a. Slide the screen depth adjuster towards the front of the machine.
