3.8保存日志文件
选中[设置]‑[软件设置]‑[运行状况检查]‑[保存日志文件]复选框时，日志文件将保存到[输出路径]文件夹中。
日志文件名为“NHCLog_（机器序列号）_（安装表号）_YYYYMMDD.csv”。（例如：NHCLog_Y20000_A_201
50315.csv）
Wheneitheroffollowingisperformed,resultsof[VacuumCheck],[NozzleTipDirtCheck],[NozzleBuffing
Check],[NozzleShapeCheck],[NozzleAlignmentCheck]areoutputtologfile.Non‑checkednozzleisnot
outputtologfile.
1.Tap[HealthCheck]button.
2.Tapeitherof[Vacuumcheck],[NozzleTipDirtCheck],[NozzleBuffingCheck],[NozzleShape
Check],[NozzleAlignmentCheck]button.
3.Performschedulespec.
Table3.2Formatoflogfile
No.
1
ItemName Explanation
Year,month,day,hour,minute,secondwhenoutput.Date
2 TableNo Mounttablename
3 HeadNo Headnumber
4 NozzleType Nozzletypename
5 NozzleStation Nozzlestationnumber
6 ExecuteTrigger Checktiming
“NHC”:Whenexecutedfrom[HealthCheck]button.
“UTL”:Whenexecutedfromeachbutton.
“SCH”:Whenexecutedfromschedulespec.
ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,LTD
MDOC‑SOFT50394 10/22
7
VacuumCheck
ResultofVacuumCheck.
([OK]or[NG].Emptywhendoesnotperformed)
ResultofNozzleTipDirtCheck.
([OK]or[NG].Emptywhendoesnotperformed)
ResultofNozzleBuffingCheck.
([OK]or[NG].Emptywhendoesnotperformed)
ResultofNozzleShapeCheck.
([OK]or[NG].Emptywhendoesnotperformed)
ResultofNozzleAlignmentCheck.
([OK]or[NG].Emptywhendoesnotperformed)
Resultofvacuumlevel.
(Onlywhenvacuumcheckisexecuted)
Valueof[Machine]‑[MachineData]‑[Head]‑[VacuumLevel]‑
[LowLevel].
(Onlywhenvacuumcheckisexecuted)
Valueof[Machine]‑[MachineData]‑[Head]‑[VacuumLevel]‑
[HighLevel].
(Onlywhenvacuumcheckisexecuted)
DetectionRate(%)=(VacuumLevel‑LowLevel)/(HighLevel‑
LowLevel)*100
(Onlywhenvacuumcheckisexecuted)
DetectionValueof[Machine]‑[SpecificationInformation]‑[Schedule
Specification]‑[VacuumCheck]‑[ErrorDetectionRate].(Only
whenvacuumcheckisexecuted)
Measureresultofnozzletiplength.
(OnlywhenNozzleShapeCheckisexecuted)
“Thedesignvalueunderanozzletiplength(um)”＋“Theerror
underanozzletiplength(um)”valueof[Machine][Specification
Information]‑[SideViewCameraSpec][NozzleBasicSetting].
(OnlywhenNozzleShapeCheckisexecuted)
“Thedesignvalueunderanozzletiplength(um)”‑“Theerror
underanozzletiplength(um)”valueof[Machine][Specification
Information]‑[SideViewCameraSpec][NozzleBasicSetting].
(OnlywhenNozzleShapeCheckisexecuted)
MeasureresultofnozzlegapX
(OnlywhenNozzleAlignmentCheckisexecuted)
8
TipDirtCheck
9
BuffingCheck
10
ShapeCheck
11
AlignmentCheck
12
[Vacuum]VacuumLevel
13 [Vacuum]PickLowLevel
14 [Vacuum]PickHighLevel
15 [Vacuum]DetectionRate
16 [Vacuum]Error
Rate
17
[Shape]Measurement[um]
18 [Shape]UpperLimit[um]
19 [Shape]LowerLimit[um]
20
[Alignment]X‑gaps[mm]
ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,
LTD
MDOC‑SOFT50394 11/22
No.
21
ItemName
[Alignment]X‑Upper
limit[mm]
Explanation
Valueof[Machine]‑[MachineData]‑[PickupMACS][NozzleMACS]‑
[CorrectLimitX(mm)].
(OnlywhenNozzleAlignmentCheckisexecuted)
MeasureresultofnozzlegapsY.
(OnlywhenNozzleAlignmentCheckisexecuted)
Valueof[Machine]‑[MachineData]‑[PickupMACS][NozzleMACS]‑
[CorrectLimitY(mm)].
(OnlywhenNozzleAlignmentCheckisexecuted)
22
[Alignment]Y‑gaps[mm]
23 [Alignment]Y‑Upper
limit[mm]
*Exampleoflogfile
V1.00,MultiLanguage
EN,Date,TableNo,HeadNo,NozzleType,Nozzletation,ExecuteTrigger,VacuumCheck,TipDirtCheck,Buffing
Check,hapeCheck,AlignmentCheck,[Vacuum]VaccumLevel,[Vacuum]PickLowLevel,[Vacuum]PickHigh
Level,[Vacuum]Detectionate,[Vacuum]ErrorDetectionate,[hape]Measurement[um],[hape]Upper
Limit[um],[hape]LowerLimit[um],[Alignment]X‑gaps[mm],[Alignment]X‑Upper
limit[mm],[Alignment]Y‑gaps[mm],[Alignment]Y‑Upperlimit[mm]EN,2015/03/1512:00:00,A,1,
TYPE‑301,1,NHC,OK,OK,OK,OK,OK,200,180,200,100,30,2000,2040,1960,0.100,0.150,0.200,0.160
EN,2015/03/1512:01:00,A,3,TYPE‑301,3,CH,,NG,OK,OK,OK,,,,,,2000,2040,1960,0.200,0.150,0.100,0.160EN
,2015/03/1512:02:00,B,8,TYPE‑302,28,UTL,OK,,,,,190,104,190,100,28,,,,,,,
4.SettingMethod
4.1MachineSetting
4.1.1InstallationSetting
Set［Machine］‑[Setting]‑[MachineInformation]‑[InstallationSetting]‑[NozzleHealthCheck]
to“Use”.
