ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,LTD
MDOC‑SOFT50394 20/22
7585
NozzleHealthCheck
failed
Checktheconditionsbelowandtryitagain.
・Execute[Unit]‑[Head]‑[NozzleChange]andconfirm
thenozzleissuccessfullychanged.
・Execute[Unit]‑[Head]‑[CleaningBlow]andconfirm
thecleaningblowissuccessfullyperformed.
・Settingsofeachnozzlecheck(*)arecorrect.
（Fordetails,refertotheoperationmanual.）
*“Eachnozzlecheck”meansthefollowingitemsofNozzle
HealthCheck.
・VacuumCheck
・NozzleTipDirtCheck
・NozzleBuffingCheck
・NozzleShapeCheck
・NozzleAlignmentCheck
7590
NozzleHealthCheck
ExecutionError
UnabletoexecuteNozzleHealthCheckwith[boarddata
nozzle]becausetheboarddatahasanerror.
Reloadtheboarddataandremovethecauseoftheerror.
7591
NozzleHealthCheck
ExecutionError
UnabletoexecuteNozzleHealthCheckwith[boarddata
nozzle]becauseboarddataisnotread.
Readboarddata.
ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,LTD
MDOC‑SOFT50394 21/22
7592
NozzleHealthCheck
ExecutionError
UnabletoexecuteNozzleHealthCheckwith[NGNozzle]
becausethereisnoNGnozzle.
7594
NozzleShapeCheck
Error
NozzleShapeCheckfailed.
[Measure]
Pleaseconfirmthestateofthenozzle.
Pleaseinstallacorrectnozzlewhenanozzledifferent
fromthenozzleusedisinstalled.
Pleasecleanthenozzlewhenacorrectnozzleis
installed.
7595
NozzleAlignmentCheckNozzleAlignmentCheckfailed.error
[Cause]
‑ Thenozzlemightbedirty.
‑ Databasenumberisnotcorrect.
[Measures]
‑ Checkwhetherthenozzleisdirty.
‑ Checkwhetherthepartsdatabasenumberfor
NozzleMACSisright.
[PickupMACS]‑[NozzleMACS]‑[DatabaseNumber]
ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,LTD
MDOC‑SOFT50394 22/22
13233
(NozzleStation)Not
enoughowningnozzle
numbererror▲4
Numberofowningnozzletypesisnotenoughtouseforthe
production.
[Cause]
‑Usablenozzleisnotexist.(Includesparenozzle)
[Measure]
‑Clean,changeoraddnozzle.
‑Execute[NozzleHealthCheck]again.
