4.2SoftwareSetting
Whenthe[SaveNGimages.]checkboxischecked,itsavesanimageofNGnozzledetectedbyTipDirt
Check,ShapeCheck,orAlignmentCheck.
Whenthe[Savelogfile]checkboxischecked,itsaveslogfileofcheckresults.Butwhen[OutputPath]is
empty,itdoesnotsavelogfile.
Whenthe[Don’tstartrunningifNozzleHealthCheckNGisdetected.]checkboxischecked,auto‑running
doesnotstartaslongasNozzleHealthCheckisnotcompletedoranabnormalnozzleisdetectedinboard
data.IntheNozzleHealthCarefunction,ifthereisusablesparenozzle,auto‑runningstart.▲4
OnlywhentheNozzleHealthCarefunctionisvalid,[TakeoverthenozzlestatusfromNozzleIDReport]is
displayed.Whenthischeckboxischecked,itispossibletotakeoverthenozzlestatusfromNozzleID
Report.Whenthischeckboxisnotchecked,theNozzleHealthCheckstatusissetto[Uncarried]inmachine
poweredon.
※ItispossibletotakeoverOnlythenozzlestatus.TheeachresultoftheNozzleHealthCheck
isnottakenover.▲4
Youneedtohaveadministratorauthoritytomakethissetting.The
outputpathfolderrequiresatleast100MBoffreespace.Thesecheck
boxesareuncheckedbydefault.
ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,
LTD
MDOC‑SOFT50394 16/22
5.ErrorMessage
Thetablebelowistheerrormessagesaddedforthisfunction.
ErrorMessageList
No. Title CauseandSolution
7573
NozzleHealthCheckis
completed.
Noabnormalnozzlewasdetected.
ProductEngineeringDivision
SMTSection
IMOperations
YAMAHAMOTORCO.,
LTD
MDOC‑SOFT50394 17/22
7574
NozzleHealthCheckis
completed.
Abnormalnozzlewasdetected.
Fordetails,refertothe[Monitor]‑[NzleHlthChk]screen.
7575
AbnormalitydetectedatAnabnormalitywasdetectedatNozzleHealthCheck,soNozzle
HealthCheck.
thatauto‑runningisnotstarted.
Refertothe[Monitor]‑[NzleHlthChk]screen.
