1-54
AKFEMT-ID
(6) Usetheinnerholesofthecutunitxingjigwiththetapeclampbeing
closed and attach the jig with the bent portion being directed upward.
Fig. 4A52
WARNING
Pay close attention to the cutter blade during the maintenance
work.
·
Lack of attention will result in a hand injury, etc.
·
Besuretoattachthexingjigtothecutunitduringthe
maintenance work for safety purposes.
(7) Cuttheusedatringwithacutteronmarketanddetachit.
(8) Attachtheatringtotheatringreplacementjig.
Fig. 4A53
0601-002
4.4 Procedure of Flat Ring Replacement
1-55
AKFEMT-ID
(9) Puttheatringreplacementjigontherollerontheoscillatingside
(outside of the machine).
Pushonlytheatringdownwardbyhandandinsertitintothegroove
of the roller.
Flat Ring
Fig. 4A54
(10) Payattentiontothecutterbladeanddetachtheatringreplacement
jig.
(11) Attach the tape guide and the transparent cover.
0601-002
4.4 Procedure of Flat Ring Replacement
1-56
AKFEMT-ID
4.5 Cleaning of Linear Measure Sensor
Periodically perform cleaning of the linear measure sensor to maintain
reliable and stable measurement of component thickness.
·
Clean the sensor every day.
·
Change cleaning frequency according to varying frequency of use and
environmental conditions.
Conic Cap
Linear Measure Sensor
(Light Emitter)
Linear Measure Sensor (Light Receiver)
Surface of Conic
Reflector
Horizontal Direction
Linear Measure Sensor (Light Emitter)
Fig. 4A55
·
Whileyouarecleaningthelightemitter
,
the
surface
oftheconicreector
must be cleaned softly and horizontally.
Notice
Cleaning it vertically may damage the conic cap.
When the conic cap is damaged, the component recognition might
not be made correctly.
CAUTION
The light emitter of the linear measure sensor is made of glass.
If the light emitter happens to be damaged, be sure to suck up
the fragments with a vacuum cleaner, etc.
Do not collect the fragments with your bare hands to protect
your hands from injuries.
0607-003
4.5 Cleaning of Linear Measure Sensor
