Fuji Software Upgrade Report (Appendix) 02022A3 1/21 htt p:/ /www.f uj i. co. jp / Copyright © 2002 Fuji Mac hine Manufacturi ng Co., Ltd. All Right s Reserved. Model : CP-742ME (Control sof tware) Version : V1.21 (Curre…
Fuji Software Upgrade Report (Appendix) 02022A3 1/21
http://www.fuji.co.jp/
Copyright © 2002 Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
Model : CP-742ME (Control software)
Version : V1.21 (Current version: V1.20) April 15, 2002
The following pages are the document PAM Operation Manual which is a supplement to the Fuji Software
Upgrade Report 02022.
Fuji Software Upgrade Report (Appendix) 02022A3 2/21
http://www.fuji.co.jp/
Copyright © 2002 Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
PAM Operation Manual
April 15, 2002
Fuji Software Upgrade Report (Appendix) 02022A3 3/21
http://www.fuji.co.jp/
Copyright © 2002 Fuji Machine Manufacturing Co., Ltd. All Rights Reserved.
1. Overview
This document describes the operation of the Placement Accuracy Measurement (PAM) software for
the CP-732E.
Note: The layout of some of the operation screens may differ from the actual screens at the
machine.
2. Getting Started
Press [Maintenance] - [PAM Measure] to display the [Cam Speed Select] dialog box.
Select a cam speed and then press [OK] to enter the PAM commands section.
