Fuji Software Upgrade Report (Appendix) 02022A3 17/21

http://www.fuji.co.jp/

11.Production Program Settings

In order to use the [PAM Equip] and [PAM Measure] commands, the nozzle name (GNANAM) used

in the production program must be set at the part data special nozzle name (PENNZN). By making

this setting, the parts are only placed using the specified nozzle.

“UNIT”,”NOZZLE”

"BLOCK","CP732+"

"GNANN","GNANAM"

1,"R08-007"

2,"R08-010"

3,

"R08-013"

"R08-013" "R08-013"

"R08-013" ç

çç

ç

This nozzle must be set in part data.

4,"R16-018"

5,"R16-025"

6,"R08-004"

"UNIT","PARTS"

Omitted

"ELEMENT","VISION-"

"PTPVICVT",10

"PENVILIT",0

"PTPVILCA",0

"PTPVILB",0

"AUTOHEIGHTCHK",1

"PARTHEIGHTTOL",0

"PTPVIPL",0

"ELEMENT","ENVDT"

"LEVEL1","CP732ENVDT-"

"PENNMI",1.3

"PENNMA",1.3

"PENNZN",

"R08-013"

"R08-013" "R08-013"

"R08-013" ç

çç

ç

For PAM placement and measurement.

"PENBLM",9

Omitted

Fuji Software Upgrade Report (Appendix) 02022A3 18/21

http://www.fuji.co.jp/

12.Saved Files

The files are saved when the [File Save] command is selected at the PAM measurement commands

screen. The files have the following format.

PAMNEW_512_CP7.PGO [100%]

Panel SeqNo Mode X Y Q (1/1000mm,1/1000degree)

P1 N 1 F -113 -396

P1 N 2 F -65 -324

P1 N 3 D 162 -63 148

P1 N 4 D 143 86 408

P1 N 5 D 138 13 285

P1 N 6 D 175 -26 486

P1 N 7 D 156 -10 372

P1 N 8 D 157 -62 545

P1 N 9 D 198 -34 -57

P1 N 10 D 67 -14 -357

P1 N 11 D 104 -52 444

P1 N 12 D 190 -34 19

P1 N 13 D 221 46 361

P1 N 14 D 129 -16 -41

P1 N 15 D 131 -17 191

P1 N 16 D 90 -24 53

P1 N 17 D 145 -7 450

P1 N 18 D 153 -69 390

P1 N 19 D 152 -25 -3

P1 N 20 D 130 69 769

P1 N 21 D 156 27 295

P1 N 22 D 206 -22 228

P1 N 23 D 177 1 768

P1 N 24 D 156 -50 525

P1 N 25 D 192 -10 -133

X USL Y USL (1/1000mm)

100 100

X LSL Y LSL (1/1000mm)

-100 -100

All data. X(1/1000mm) Y(1/1000mm) Ang(1/1000deg)

X Y Ang

4 -5 187

3sigmaX 3sigmaY 3sigmaAng

333 330 918

6sigmaX 6sigmaY 6sigmaAng

666 660 1836

dXmax dYmax dAng max

231 206 1164

Fuji Software Upgrade Report (Appendix) 02022A3 19/21

http://www.fuji.co.jp/

dXmin dYmin dAng min

-218 -228 -693

CpX CpY

8.33 -40.00

CpkX CpkY

8.00 -38.00

Data by nozzle and angle. Unit(1/1000mm)?(1/1000deg)

Nozzle 1

[Average]

0deg 90deg 180deg 270deg

No X Y Ang X Y Ang X Y Ang X Y Ang

A 160 -29 175 -24 -168 99 -146 14 142 33 157 211

B 117 75 514 102 -102 236 -103 -80 342 -92 90 213

C 157 30 334 35 -170 34 -168 -41 263 -36 157 314

D 205 -30 195 -21 -210 247 -197 17 364 35 193 322

E 173 -8 537 -1 -180 162 -164 -8 469 5 171 173

F 159 -64 317 -60 -162 232 -143 63 360 65 141 278

G 186 -4 72 -6 -179 306 -164 -15 2 18 161 -29

H 80 6 75 19 -87 117 -97 -20 -1 -21 81 279

I 97 -40 156 -39 -91 44 -87 44 482 50 88 -23

J 183 -2 103 -3 -192 32 -170 -5 206 11 175 4

K 218 38 119 42 -212 101 -205 -51 271 -38 197 199

L 134 -1 56 5 -142 117 -118 2 121 16 134 81

M 148 -11 101 -11 -138 283 -124 -1 191 6 121 -301

N 91 -17 -9 -8 -97 33 -89 2 -17 24 82 103

O 155 3 368 16 -134 277 -139 -7 405 0 124 10

P 144 -46 307 -39 -154 268 -147 40 304 52 133 230

[3 sigma]

0deg 90deg 180deg 270deg

No X Y Ang X Y Ang X Y Ang X Y Ang

A 477 99 612 78 504 555 441 63 465 105 468 648

B 354 228 1659 306 315 954 315 246 1110 279 276 759

C 471 96 1020 105 510 405 504 135 807 114 468 1260

D 612 99 1263 78 627 894 588 63 1137 108 573 1056

E 516 36 1641 33 540 549 492 42 1665 27 510 1035

F 474 195 1173 189 486 816 429 195 1149 198 423 948

G 552 60 675 57 537 969 489 57 441 72 483 639

H 240 60 1149 78 267 1086 291 78 444 90 246 927

I 291 126 651 123 273 543 264 138 1491 150 264 393

J 546 39 570 18 573 291 510 36 699 42 519 390

K 648 120 594 132 636 621 615 159 936 123 588 699

L 399 30 444 45 426 561 360 42 603 72 402 567

M 441 45 552 60 417 1026 375 21 708 33 360 975

N 270 63 951 51 291 858 270 36 1119 87 246 930

O 462 27 1161 60 402 1074 420 45 1368 30 369 429

P 429 144 969 123 462 828 441 123 978 162 396 765
