2 Brief Description
2.1 Product Description
Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V2 Thick Board Option Option Dicke Leiterplatte
02/2019
43
2 Brief Description
The "Thick Board" option enables you to place boards with a thickness up to 6.5mm.
2.1 Product Description
The "Thick Board" option is needed in order to process boards with a thickness up to 6.5mm.
You also need to use other clamping rails and will have to lower the entire conveyor.
2.2 Prerequisites
This option can be fitted in all SX1/SX2 V2 machines from serial number Lxxxx.
NOTICE
Other machine types
► For machines of type SX1/SX2/DX1/DX2 (serial number Kxxxx), read the Assembly
Instructions "Thick Board 6mm – SX1/SX2 – DE+EN" [00196613‑xx].
2.3 Restrictions
●
Once you have installed this option, you will no longer be able to clamp boards with a thick-
ness of below 2 mm.
●
Both conveyor lanes need to be converted when using a dual conveyor. If you do not convert
both sides, the Z axis for the placement heads will not reach far enough down and the PCB fi-
ducials will be outside the focus of the PCB camera.
2.4 Scope of Delivery
"Thick Board option SX1/SX2 V2" [00519871-xx] package (for one conveyor lane)
NOTICE
Dual Conveyor
The package contains all parts needed to convert one conveyor lane. You will need to order
this package 2x for a dual conveyor.
Quantity Designation Item no.
2 Clamping rail for thick board SX1a assembly 03099567-xx
4 ISO 14581 M5x25-8.8, chem. nickel-plated 03095127-xx
4 ISO 14581 M5x14.7-8.8, chem. nickel-plated 03098065-xx
1 Warning sign no. W208 03009347-xx
1 Assembly instructions “Thick Board Option" (DE+EN) (this docu-
ment)
00197288-xx
2 Washer for clamping plate 03091791-xx
2 Clamping plate washer 03091711-xx
2 DIN 7991 - M4x8-A2-70 03047055- xx
4 Setting screw 3mm SXa 03104139-xx
4 U-distance 2mm 03104937-xx
4 U-distance 5mm 03104924-xx
2 Brief Description
2.5 Tools and Equipment Required
44 Assembly Instructions / Montageanleitung SIPLACE SX1/SX2 V2 Thick Board Option Option Dicke Leiterplatte
02/2019
2.5 Tools and Equipment Required
T Standard tooling
T 03079617-xx Depth measuring gauge 300mm
Service manual for your machine
2.6 Required Working Time
●
The complete installation for the single conveyor will take approx. 1.5 hours.
●
The complete installation for the dual conveyor will take approx. 2.5 hours.
●
Programming work on the SIPLACE Pro computer may also be needed.
