4 Setting up and commissioning 4.3 Setting up the machine 64 Instruction Guide ASM ProcessLens Dual-lane 06/2018 4.3.3.3 Fixing the monitors ► Install and secure the monitor in the bracket using 4x M4 x 8mm screws with w…
4 Setting up and commissioning
4.3 Setting up the machine
Instruction Guide ASM ProcessLens Dual-lane 06/2018 63
► Position the forklift truck at right angles to the PCB conveyor and open the forks until the con-
tact surfaces of the machine lie evenly on the forks.
WARNING
Risk of injury
Please note the following points before you raise the machine in order to avoid irreversible
damage to the machine
► The forks must be aligned parallel to the PCB conveyor.
► Make sure to push the forks all the way through. Not pinching cables. There is an area
in the center of the machine's base plate where there is a fan. If the forks are not go-
ing through fully, they could lift up the machine and be in contact with the fan and not
the machine's base plate which means the fan would get destroyed.
► The forks may only be opened to a degree which ensures that they are still within the
contact area of the machine underside (see 4.1.5.3 "Forklift attachment points on the
machine" [}58]).
► Do not increase the distance between the forks so that the machine is lifted outside
this contact surface. This would lead to deformation of the machine frame and/or dam-
age to the cables and leads.
► Make sure that the forks are evenly loaded when you lift the machine.
► A firm support between the forks and machine will prevent the machine tilting when it
is raised. This will also prevent a one-sided load on the machine feet, which would de-
form the fixing of the machine feet. We recommend that a second person watch the
machine as it is raised, and make sure that the machine does not tip to one side when
lifted with the forklift.
WARNING
Transporting the machine
When you are transporting the machine, make sure that all the feet are clear of the floor. If
they are not clear, the feet will drag along the floor or bump into obstacles. This could dam-
age the machine foot fixing in the machine frame.
► With the forklift, raise the machine approximately 35 cm. This prevents the risk of any
injuries to your feet if the machine feet are unintentionally lowered.
4.3.3 Fitting attached parts
The machine is delivered with the monitor, keyboard and tower lamp dismantled. To fit these com-
ponents, proceed as follows:
●
To fit the tower lamp see section 4.3.3.2 "Fitting the tower lamp" [}63].
●
To fit the monitor see section 4.3.3.3 "Fixing the monitors" [}64].
► Hook up the keyboard fixture and connect the keyboard.
4.3.3.1 Checking and setting the protective cover switch
► Check the function of the protective cover switch (see section 2.5.2.3 "Position of protective
switch on the machine" [}37].
► Adjust the protective cover switch if necessary (see service manual).
4.3.3.2 Fitting the tower lamp
► Remove the cover on the tower lamp base.
► Fix the connector between the machine and the tower lamp.
► Insert the tower lamp into the holder.
► Put on the cover onto the tower lamp.
4 Setting up and commissioning
4.3 Setting up the machine
64 Instruction Guide ASM ProcessLens Dual-lane 06/2018
4.3.3.3 Fixing the monitors
► Install and secure the monitor in the bracket using 4x M4 x 8mm screws with washer.
► Insert the power cable.
► Insert and tighten the screws of the VGA cable.
4.3.4 Tools and equipment
You will need the following tools and equipment to adjust the height of your machine:
●
Open-ended wrench SW 19, SW 30, SW 36
●
One or two machine spirit level(s): accuracy 0.02 mm/m
●
Forklift truck (specification see 4.1.4.3 "Means of transport" [}57]).
4.3.5 Adjusting the machine height
The machine can be set at any PCB conveyor height within the following range:
●
900 mm ± 15 mm
●
930 mm ± 15 mm
●
950 mm ± 15 mm
CAUTION
Foot spacers
When using the 950 ± 15 mm PCB conveyor height, foot spacers are required to maintain
ASM ProcessLens Dual-lane measurement accuracy and stability.
NOTICE
PCB conveyor height
The PCB conveyor height is the distance between the top edge of the PCB conveyor belt
and the bottom edge of the machine feet.
5 Working with the machine
5.1 Controls and displays
Instruction Guide ASM ProcessLens Dual-lane 06/2018 75
5.1.2 Description
All the controls can be reached by a 1.40 m tall person.
Programmable tower lamp with buzzer
(see fig. "Controls and displays" [}74])
The programmable tower lamp is used to signal operating statuses and malfunctions of the
machine. The buzzer indicates when an alert has occurred. The sequence of colors of the tower
lamps is red - amber - green.
The programmable tower lamp functionality allows the operator to assign a combination of the fol-
lowing tower lamps conditions to machine events:
Condition Possible states Frequency of flashes
Green On
Off
Pulse
Pulse Frequency (ms)
Amber On
Off
Pulse
Pulse Frequency (ms)
Red On
Off
Pulse
Pulse Frequency (ms)
Buzzer On
Off
Pulse Frequency (ms)
LCD monitor
(see fig. "Controls and displays" [}74])
There is a flat LCD monitor at the front side of the ASM ProcessLens Dual-lane machine. A LCD
monitor with a touch-sensitive surface (touchscreen) as an option is available.
Keyboard
(see fig. "Controls and displays" [}74])
The keyboard and mouse are located beneath the monitor.
CAUTION
Risk of collision of personal with monitor and keyboard holder
Risk of collision of the front hood with the arm where the monitor, keyboard and mouse are
mounted.
Key switch ON/OFF
(see fig. "Controls and displays" [}74])
Turn on the control power manually and switch the conveyor into pass through mode when the PC
is down.
► Close the GUI program.
► Switch off the machine by the main switch.
► Wait for 30 sec switch on the machine by the main switch.
► Turn the key switch to the left and release to turn on the control power.
► Turn the key switch to the right.
The conveyor set to pass through running mode.
