Error
Number
Title Causes and measures
24596
Board Data Error
<Cause>
Mount position is out of the moving area.
This mount can be mounted at neither "first half mount"
nor "second half mount".
Mount No.: XXX
<Measures>
Correct mount coordinates.
24597
Board Data Error
<Cause>
Local fiducial mark of following mount data is not
recognizable.
Mount No.: XXX
- Local fiducial corresponding to mount data of "first half
mount" is not recognizable at "first half mount".
- Local fiducial corresponding to mount data of "second
half mount" is not recognizable at "second half mount".
<Measures>
Correct local fiducial mark coordinates.
(Local fiducial corresponding to mount data of "first half
mount" has to be recognizable at "first half mount", and
local fiducial corresponding to mount data of "second
half mount" has to be recognizable at "second half
mount")
Error
Number
Title Causes and measures
24598
Board Data Error
<Cause>
Local bad mark of following mount data is not
recognizable.
Mount No.: XXX
- Local bad mark corresponding to mount data of "first
half mount" is not recognizable at "first half mount".
- Local bad mark corresponding to mount data of
"second half mount" is not recognizable at "second half
mount".
<Measures>
Correct local bad mark coordinates.
(Local bad mark corresponding to mount data of "first
half mount" has to be recognizable at "first half mount",
and local bad mark corresponding to mount data of
"second half mount" has to be recognizable at "first half
mount" or "second half mount")
24599
Optimization
Uncompleted
Warning
<Cause>
This board data is not optimized correctly for "long
board partition mount".
When auto-running is started, “first half mount” and
“second half mount” of unoptimized mount are uniformly
decided from mount coordinates.
Unoptimized first mount no.: XXX
<Measures>
For more efficient mount, optimize board data.
24600
Machine Data Error
<Cause>
When using “Long board partition mount”, following
settings are required.
- [Machine] - [Machine Information] - [Installation] - [Exit
Stopper] : “Exist”
- [Machine] - [Mechanical] - [Position] - [Fiducial All
Recognition] : “Not Use”
<Measures>
Change settings.
Error
Number
Title Causes and measures
24601
Board Data Error
<Cause>
Local bad mark position is outside moving area.
Local bad mark No.: XXX
<Measures>
Change local bad mark position to movable area.
5 I/O address
In [Unit] – [I/O] screen, “STAGE-2 MAIN STOPPER HIGH END” is correspond to the exit
stopper high end sensor.
I/O address Type Contents I/O state
1 DETECT
N01008F7 CONV STAGE-2 MAIN STOPPER HIGH END
0
NOT
DETECT
6 Appendix
6.1 Setting method
This function is enabled with the following setting.
Select [Machine] -
[Machine Information] -
[Installation Setting] and
set [Long Board Partition
Mount Conveyor] to
“Exist”.
Select [Machine] -
[Machine Data] -
[Mechanical] - [Position]
and set [Distance exit
stopper to main stopper]
and [Exit stopper arrival
add time].
