Test Research Inc.

12 TR518 SII 使用手冊---硬體規格與架構

3.2 規格

3.2.1

類比測量模組

 1 DCV or ACV or DC Constant Current Source.

 1 DCV Source

 1 High Voltage Source

 AC/DC Voltage Measurement

 AC/DC Current Measurement

 System Diagnostic

3.2.2 直流電壓源

 Two Programmable Output Voltage: 0V ~ +/-10V

 Resolution: 5.86mV

 Voltage Accuracy: 1.5%

 Source-Configurable as Current and/or Voltage

 High Voltage Current Source :30 ~ 100V , 4%

3.2.3 交流電壓源

 1 Sine wave Voltage Source

 Programmable Output Voltage: 0V ~ +/-10(AC+DC)(Max)

 Resolution: 23.44mV

 Voltage Accuracy: 2%

 Frequency Range : 1 ~ 100KHZ (Max)

3.2.4 直流電流源

 1 DC Current Source

 Programmable Output Current:

 Current Range : 50mA ~ 100nA

 Accuracy: 3% FS +/-100nA

 Programmable Clamping voltage

Test Research Inc.

TR518 SII 使用手冊---硬體規格與架構 13

3.2.5 直流電壓測量

 Auto rang

 Common Mode / Differential Mode

 Input Voltage Range : 0 ~ +/- 100V

 Input Impedance : 1MΩ

 Resolution : 2.5mA ~ 50 mV

 Accuracy : +/-0.5% of reading

3.2.6 交流電壓測量

 Auto Range

 True RMS, Peak , & Offset Measurement

 Input Voltage Range : 0 ~ +/- 100Vpeak

 Input Frequency Range : 10 ~ 50KHZ

 Input Impedance : 1MΩ

 Coupling AC / DC selectable

 Conversion Time : 50ns

 Accuracy : +/- 3.0%

 Acquisition Memory : 512K byte

3.2.7 直流電流測量

 Auto range

 Current Input Range: 1uA ~ 50mA

 Resolution: 30nA ~ 30uA

 Accuracy : +/- 2%

3.2.8 交流電流測量

 Auto range

 True RMS, Peak, & Offset Measurement

 Current Input Range: 1uA ~ 20mA

 Input Frequency Range : 10 ~ 50KHZ

 Conversion Time : 50ns

 Accuracy : +/- 2.0 %

 Acquisition Memory : 512K

Test Research Inc.

14 TR518 SII 使用手冊---硬體規格與架構

3.2.9 阻抗測量

 RC & Other Analog Circuits

 Programming Frequency: 0.15 ~ 100KHz

 AC level 100mVrms\

3.2.10 訊號產生器

 1 Sine wave voltage Source

 Frequency Range : 0 ~ 100KHZ(Max)

 Frequency Resolution : 1 HZ

 DC offset Range: 0 ~ +/-10V (Max)

 Minimum output level : 100 mV

3.2.11 電阻測量

 40mΩ- 40MΩ over 7 range

 Uses 2-, 4- Wire Unguarded Tests

 Uses 3-, 6- Wire Guarded Tests

 Accuracy: 1% to 10%

3.2.12 電容測量

 Range: 1pF ~ 40mF

 Accuracy: (3% - 10%)+/-100pF

3.2.13 電容放電

 Yes

3.2.14 針對極性電容的定向測量

 2-pole Polarized Capacitor Leakage Current Test Technology

 3-pole Polarized Capacitor Test Technology

 HP-Test-Jet

3.2.15 針對 IC 裝置的定向測量 (not on 2-sided devices with VCC and GND

symmetrical)

 Clamping Diode Test Technology
