5 DELIVERY , TRANSPOR T AND SET TING UP CAUTION ≤ 260 L > 260 L Y ou could be injured due to the weight of the device if you try to lift it alone. Observe the required number of people to carry equipment. Larger equip…
4
GmbH+Co.KG D-91126 Schwabach FRG
Äußere
Rittersbacher Str. 38 Made in Germany
memmert
Schutzart DIN EN 60529 - IP 20
1
2
3
4
5
6
10
9
8
7
Typ: IN260
230 V~ 50/60 Hz
DIN12880-2007-Kl.: 1
F-Nr.: B618.3008
7,4 A 1700 W
Nenntemp.: 300 °C
CONSTRUCTION AND DESCRIPTION
memmert
1
2
3
4
5
6
Appliance overview
Designation (nameplate)
Connections and interfaces
1
2 On/Off switch
3 Door handle
1 Type designation
2 Operating voltage
3 Applied standard
4 Protection type
5
1
2
3
4 Nameplate (Door frame inside)
5
6 USB interface (TwinDisplay)
6 Address of manufacturer
7 Disposal note
8 Temperature range
9
10 Appliance number
1
2
3
4
4 Power connection
5
DELIVERY, TRANSPORT AND SETTING UP
CAUTION
≤ 260 L > 260 L
You could be injured due to the weight of the device if you try to lift
it alone. Observe the required number of people to carry equipment.
Larger equipment must not be carried, but only transported with a lift
truck or forklift.
≤ 75 L
Setting up
Due to its centre of gravity, the appliance can fall over to the front and
injure you or other people. Always attach the appliance to a wall with
the tilt protection.
WARNING
The distance between the wall and the rear of the appliance must be at least 15 cm.
The clearance from the ceiling must not be less than 20 cm and the side clearance
in the vicinity of the appliance must be guaranteed at all times.
Putting into operation
reached the steady state.
-
nection and power ratings (see nameplate and Technical data). Make sure to establish
Lay the power cable so that
X no one can trip over it;
X it does not come into contact with any hot parts;
X it is always accessible and within reach so it can be disconnected quickly in the
event of failure or emergencies.
≥ 15 cm
You may get your hands or feet squashed when transporting and in-
stalling the appliance. Wear protective gloves and safety boots. When
grasping the bottom of the appliance, grasp it only on the sides.
CAUTION
The appliance could fall over and seriously injure you. Never tilt the ap-
pliance and transport it in upright position and without load only (except
for standard accessories such as steel grids or shelves). Appliances
with castors always have to be moved by two people.
CAUTION
NOTICE
at high humidity conditions, the appliance shall be stored unpacked at
normal conditions for at least 24 hours. During this period of time the
appliance shall not be connected to the power supply.
WARNING
6
SWITCHING ON AND OPERATION
DEVICE LOADING
Basic operation - Setting the temperature
PRESS
to switch on
PRESS
to activate
TURN
to adjust
PRESS
22
.4
37
.0
TEMP
Set
°C
°C
22
.4 °C
TEMP
37
.0 °CSet
. 5°C
100
TEMP
22
.4 °C
TEMP
37
.0 °C
Set
In case of unfavourable charging (e.g. too dense) the set temperature may be excee-
ded or only reached after a longer period of time.
To open the door, pull the handle to the
side and open the door completely.
To close the door, close the door and
push the handle to the side.
Menu control - Language selection
PRESS
to activate
PRESS
to activate
TURN
to adjust
PRESS
SPRACHE
SPRACHE
ENGLISH
DEUTSCH
MAGYAR
ITALIANO
ESPANOL
FRANCAIS
POLSKI
CESTINA
SPRACHE
ENGLISH
DEUTSCH
MAGYAR
ITALIANO
ESPANOL
FRANCAIS
POLSKI
CESTINA
