34 A TOM miniature encoder system Digital: Ti 0200 A 20 E Options E - Standard Clocked output option 50, 40, 25, 20, 12, 10, 08, 06, 04, 01 (MHz) Alarm format and conditions A - Line driven; All alarms B - Line driven; l…

100%1 / 36
33 ATOM miniature encoder system
ACi 0020 A 04 A
Options
A - Standard
Clocked output option
40 - 40MHz (0020, 0040, 0080, 0100 and 0200 interpolation factors only)
20 - 20MHz (0020, 0040, 0080, 0100 and 0200 interpolation factors only)
12 - 12MHz (0400, 1000 and 2000 interpolation factors only)
10 - 10 MHz (0020, 0040, 0080, 0100 and 0200 interpolation factors only)
06 - 6MHz (0400, 1000 and 2000 interpolation factors only)
05 - 5MHz (0020, 0040, 0080, 0100 and 0200 interpolation factors only)
04 - 4MHz (0400, 1000 and 2000 interpolation factors only)
PCB type
A - FPC input connector
B - Cable input connector
C - Pin headers for PCB mounting
Analogue: Ri 0000 A 00 A
Digital: Ri 0400 A 12 B
Options
B - Standard
Clocked output option
12 - 12MHz (0200 and 0400 interpolation factors only)
10 - 10MHz (0200 and 0400 interpolation factors only)
06 - 6MHz (0100, 0200 and 0400 interpolation factors only)
04 - 4MHz (0100, 0200 and 0400 interpolation factors only)
00 - Non-clocked (0004, 0008, 0020 and 0040 interpolation factors only)
Alarm format
A - Line driven
E - 3-state
Series
Ri
Series
Interpolation factor
Interpolation factor
Ri interface
ACi interface
Interpolation
factor
Resolution
20 µm
system
40 µm
system
0004 5 µm 10 µm
0008 2.5 µm 5 µm
0020 1 µm 2 µm
0040 0.5 µm 1 µm
0100 0.2 µm 0.4 µm
0200 0.1 µm 0.2 µm
0400 50 nm 0.1 µm
Interpolation
factor
Resolution
20 µm
system
40 µm
system
0020 1 µm 2 µm
0040 0.5 µm 1 µm
0080 0.25 µm 0.5 µm
0100 0.2 µm 0.4 µm
0200 0.1 µm 0.2 µm
0400 50 nm 0.1 µm
1000 20 nm 40 nm
2000 10 nm 20 nm
34 ATOM miniature encoder system
Digital: Ti 0200 A 20 E
Options
E - Standard
Clocked output option
50, 40, 25, 20, 12, 10, 08, 06, 04, 01 (MHz)
Alarm format and conditions
A - Line driven; All alarms
B - Line driven; low signal, high signal
E - 3-state; All alarms
F - 3-state; low signal, high signal
Analogue: Ti 0000 A 00 A
Series
Ti
Options
A - Vmid - 1.65V
V - Vmid - 2.5V
Interpolation factor
Ti interface
Interpolation
factor
Resolution
20 µm
system
40 µm
system
0004 5 µm 10 µm
0020 1 µm 2 µm
0040 0.5 µm 1 µm
0100 0.2 µm 0.4 µm
0200 0.1 µm 0.2 µm
0400 50 nm 0.1 µm
1000 20 nm 40 nm
2000 10 nm 20 nm
4000 5 nm 10 nm
10KD 2 nm 4 nm
20KD 1 nm 2 nm
35 ATOM miniature encoder system
ATOM compatible scales
RTLF-S self-adhesive tape scale
RCLC glass spar
RCDM glass disc
For more information refer to the relevant data sheets and installation guides
which can be downloaded from www.renishaw.com/atomdownloads.
ATOM compatible interfaces
Ri interface
Ti interface
ACi interface
ACi interface
RKLF-S self-adhesive mastered
tape scale
RKLF40-S self-adhesive
tape scale (partial arc)
