i3070 Software Installation 21

Troubleshooting

Troubleshooting Software Installation

If you encounter problems after software installation and find that you are unable

to uninstall or reinstall the i3070 In-Circuit Test Software, follow the instructions

below. These steps will not remove all i3070 files from your system, but will clean

up the system sufficiently to enable you to reinstall the software.

1 If there are any i3070 programs running, you must stop them.

a Press Ctrl+Alt+Delete and select Start Task Manager.

b On the Processes tab, check whether any of the following programs are

running:

• rmiregistry.exe

• RmiServer.exe

• translogd.exe

• xinitcolorcells.exe

c Select each program that is running and click End Process.

2 Rename your existing i3070 installation folder.

3 Remove the i3070 uninstall key from the registry.

a Select Start > Run, type

regedit and click OK.

b Navigate to the following:

64-bit OS:

HKEY_LOCAL_MACHINE\SOFTWARE\WOW6432Node\Microsoft\

Windows\CurrentVersion\Uninstall

c Look for the key whose Product Name in the right panel shows

Keysight i3070.

d Delete that key.

4 Remove the i3070 configuration information from the registry. Look for

HKEY_LOCAL_MACHINE\SOFTWARE\Keysight Technologies, Inc. If you find

this key delete it.

At this point there will still be some i3070 icons and programs on your system.

However, you should now be able to successfully reinstall the i3070 In-Circuit Test

Software.

22 i3070 Software Installation

Uninstalling the i3070 In-Circuit Test Software

1 Uninstall the i3070 software from either Settings or Control Panel.

• Click Start > Settings > Apps & Features.

Click Keysight In-circuit Test <xx.xx>p and click Modify.

• From Control Panel, click Programs and Features.

Click Keysight In-circuit Test <xx.xx>p and click Change.

2 Select one of the options:

• Remove All to remove the i3070 In-Circuit Test Software together with

associated third party software.

Choose this option if you no longer want the i3070 In-Circuit Test Software

on this PC, or when you are upgrading the i3070 In-Circuit Test Software

from one release to another.

• Select Remove to remove the i3070 In-Circuit Test Software only.

You can choose this option if you want to reinstall the same release.

3 Follow the instructions to complete the uninstallation.

4 If the Keysight LXI Mdns Responder dialog box appears, click Ignore.

5 If the following dialog box appears, click OK to continue.

6 (Optional) Remove the i3070 online help.

7 Reboot the PC.

• xx.xx indicates the release that is currently installed.

• You can click Uninstall if you want to remove the i3070

software only. Third party software will not be removed.

The uninstall process does not remove the i3070 user

accounts.

i3070 Software Installation 23

i3070 Users on Testhead Controller

If you upgraded the i3070 software from a previous release

You can continue to use the same User accounts and passwords to run this release

of the i3070 software. No new Users are created during installation.

However, if you want to set up User accounts with new default passwords, first

remove the existing Users, then create the new ones. You must be signed on to

Windows using an account with adminstrator rights. Then run the batch files

described below.

Remove Users

a Locate the batch file: C:\I3070_ICT\util\3070removeaccounts.bat

b Right-click the file and click Run as administrator.

Create Users

a Locate the batch file: C:\I3070_ICT\home\system\3070accounts.bat

b Right-click the file and click Run as administrator.

New i3070 Users will be created with default passwords as shown in Table 3.

First-time installation of the i3070 software

The following Users are created during software installation.

Table 3 Default User names and passwords

User Name Default Password (i3070 software release 10.30p)

operator Resetme@3070

tcm Resetme@3070

user Alterme@3070

engineer Alterme@3070

calibrate Changeme@3070
