01005 Placement

In its standard version, the E

by SIPLACE is designed for

placement of 01005 compo-

nents (0.4 mm x 0.2 mm).

The SIPLACE component

library already contains the

contours and dimensions of

01005 components. Spe-

cially developed component

nozzles of type 1005 are also

available for the E by

SIPLACE. These are

adjusted to the shape and

size of the 01005 compo-

nents and have - as with all

other SIPLACE nozzles - a

highly wear-proof ceramic tip

and flexible nozzle seat. This

guarantees maximum preci-

sion and process reliability.

Optimized pickup is guaran-

teed by the ideal feeding

conditions in the SIPLACE

SmartFeeder E module. The

smaller the elements to be

picked up, the more accurate

the pickup needs to be.

Pickup is performed contact-

free to compensate minor

inaccuracies e.g. from com-

ponent or pocket tolerances

and to prevent mechanical

damage to the components.

The design of the SIPLACE

SmartFeeder E modules

takes this problem into

account: new motors and the

reduced use of fine mechan-

ics help. Small components

can be placed without per-

formance loss with mini-

mum pitch and irrespective

of the larger components

which are next to the 01005

component. This equates to

true 01005 capability. As a

rule with 01005 placement, a

finely tuned overall process

is the basic requirement if

you want to achieve excel-

lent results.

For high volume produc-

tion

It's recommended that CP14

be use for 01005 placement.

The CP14 head is immediate

ready for 01005 placement.

For CP12 head

An additional option - 01005

package CP12 E (sales num-

ber: 288605), needs to be

purchase. This option

includes nozzles and three

low force sleeves needed for

01005 placement by CP12

head.

The following table shows typical values for 01005 placement,

which can be achieved with a E by SIPLACE, provided the rel-

evant underlying conditions are fulfilled:

Machine type

E by SIPLACE

Placement head SIPLACE CP14 with

component camera type 23 GigE

Feeder module type SIPLACE SmartFeeder 8 mm E

SIPLACE SmartFeeder 2x8 mm E

Pickup rate ≥ 99,97%

Dpm rate ≤ 5

Pad width ≥ 200 µm

Pitch ≥ 100 µm

Components (L x W x H) 400 µm x 200 µm x 200 µm (±20 µm)

Number of pixels for a

01005 component

275

Solder paste type 5

Template thickness 60 µm

Technical Data

Electrical Ratings, Energy Consumption and

Compressed Air supply

Electrical ratings

Supply voltage Fuse

Main power supply 3 x 200 V~ up to 3 x 230 V~; ± 10 %; 50/60 Hz)

3 x 380 V~ up to 3 x 415 V~; ± 10 %; 50/60 Hz

a) with adapter kit (US option)

3 x 16 A characteristic C

Mains power connection Cable 4 x 4 mm² with CEKON connector

Energy consumption

Energy consumptionwith

vacuum pump

Nominal active power 1.8 kW

Nominal apparent power 2.3 kVA

Compressed air supply

Compressed air pressure values

min

max

0.5 MPa = 5.0 bar

1.0 MPa = 10 bar

Operating pressure 0.48 MPa ± 0.025 MPa (4.8 bar ± 0.25 bar)

Compressed air connection R 3/4" inner thread (pipe thread) with 1/2" hose connection

Ambient conditions for packaging, transportation and storage

Temperature range Between -25°C and 55°C

Atmospheric humidity Up to 95%

Ambient pressure Up to 3000 m height without pressure equalization

Ambient conditions for machine operation

Room temperature Between 15°C and 35°C

Atmospheric humidity 30% to 75 % (no higher than 45% on average to prevent any possibility of

condensation on the machine)

Ambient pressure > 890 mbar (corresponds to 1000 m above mean sea level)

Compressed air consumption

a) Average consumption values

Placement head configura-

tion

Compressed air consumption

with vacuum

pump

b) Under normal atmospheric conditions at 20°C and 1013 hPa.

c) Vacuum pump for SIPLACE CP14/CP12 head only.

E by SIPLACE

CP14

CP12

CP12 / PP

90 Nl/min

140 Nl/min

185 Nl/min

Compressed air specification according to DIN ISO 8573-1:2010

Particle size (ISO class 1) 0.1 µm

Particle density (ISO class 1) 0.1 mg/m³

Maximum oil content (ISO class 1) 0.01 mg/m³

Pressure dewpoint (ISO class 4) + 3°

Technical Data

Dimensions and Setup Conditions

Length of the machine

E by SIPLACE

E by SIPLACE with LBO1200

1500 mm

1910 mm

Width of the machine

E by SIPLACE 1666 mm

Height of the machine

with indicator lamp

With folded-up protective covers

(for PCB conveyor height 900 mm)

(for PCB conveyor height 930 mm)

(for PCB conveyor height 950 mm)

max. 1760mm

1750 mm

1780 mm

1800 mm

Machine ground clearance

(for PCB conveyor height 900 mm)

(for PCB conveyor height 930 mm)

(for PCB conveyor height 950 mm)

120 mm ± 15 mm

150 mm ± 15 mm

170 mm ± 15 mm

Weight of E by SIPLACE

Single sided

Double sided

1850 kg

2050 kg

Weight of component table

Changeover table 60

Changeover table 60 (fully configured)

Fixed table 60

Fixed table 60 (fully configured)

88 kg

138 kg

53 kg

104 kg

Floor space for E by SIPLACE

Single sided with 1 x changeover table 60

Double sided with 2 x changeover table 60

2.835 m²

3.338 m²

Floor stiffness

Minimum vertical floor stiffness

Recommended vertical floor stiffness

0,5E8 N/m

≥ 1,5E8 N/m

The load per unit area calculation included an additional working space of 0.5 m on each side

of the machine.

Load per unit area for E by SIPLACE

Single sided

Double sided

5.02 kN/m²

5.04 kN/m²

Number of machine feet 4
