Ref No. Remark s R 1 Q'ty 2-B X 軸 ユニ ッ ト X-Axi s U nit ｲﾗｽﾄ No. Part No. 品 名 品番 数量 R 2 パーツリスト Kit N o . キット 品 番 Kit Name キット名称 N610097178AA Part Nam e 備 考 ｾｸｼｮﾝN o. PARTS LIST Section No. R 3 HOUSING 1 1 KXFB02PHA01…
2-B
X
軸
ユニ
ッ
ト
X-Axis Unit
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610097178AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M21
( KN610097178AA-08-2 )
Ref
No.
Remarks
R
1
Q'ty
2-B
X
軸
ユニ
ッ
ト
X-Axis Unit
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610097178AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
HOUSING
1
1 KXFB02PHA01
PLATE
1
2 N210009901AA
STOPPER
1
3 KXFB01FRA00
FLANGE
1
4 KXFB02PMA00
BRACKET
1
5 KXFB02PNA00
HOLDER
1
6 KXFB02PPA01
COUPLING
1
7 N210174452AA
DOG
1
8 KXFB02PVA00
NUT-PLATE
3
9 KXFB02RMA00
BRACKET
2
10 N210045351AA
JOINT
1
11 KXF029JAA00 KJL04-M5
PH-SENSOR
1
12 KXF0DL7AA01 PM-L53-C1(DA KXF0DL7AA01)
PH-SENSOR
1
13 KXF0DL4AA01 PM-L53B-C1(DA KXF0DL4AA01)
PH-SENSOR
1
14 KXF0DL5AA01 PM-L53B-C1(DA KXF0DL5AA01)
C-RING
1
15 KXF04CRAA00 STW-10
BEARING
2
16 KXF00JZAA00 6000ZZ/2AS
BALL-SCREW
1
17 N510054192AA SBK1530ZS-3.4RRG0+717LCp5R(B)(30013755M010)
MOTOR
1
18 N510005279AA
S
HC-MFS43-S25
BEARING
1
19 KXF0A1QAA00 7201T2DF/GNP5
BEARING-WASHER
1
20 KXF0E3LDA00 AW01
BEARING-NUT
1
21 KXF0E3M2A00 AN01
PIN
2
22 N510020598AA MMS4-15
PIN
2
23 N510020607AA MMS5-10
WASHER
2
24 N510038743AA TT20
SPACER
2
25 N510016347AA 3382330-40030
SPACER
1
26 KXF0747AA00 CL-525N
BOLT
1
27 KXF0CJFAA00 UNAH5-30
BOLT
6
28 N510017311AA
Hexagon socket head cap screw M3X14-10.9 A2J (Trivalent)
BOLT
2
29 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
4
30 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
2
31 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
20
32 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
4
33 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
18
34 N510017395AA
Hexagon socket head cap screw M5X16-10.9 A2J (Trivalent)
BOLT
2
35 N510017435AA
Hexagon socket head cap screw M6X20-10.9 A2J (Trivalent)
BOLT
4
36 N510017437AA
Hexagon socket head cap screw M6X25-10.9 A2J (Trivalent)
WASHER
2
37 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
20
38 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
8
39 N510018480AA
Small round-plain washer 5 10H A2J (Trivalent)
WASHER
6
40 N510018481AA
Small round-plain washer 6 10H A2J (Trivalent)
WASHER
4
41 N510020099AA Thick washer for M4
WASHER
4
42 N510018332AA Spring lock washer No.2 5 S A2J (Trivalent)
COVER
1
43 N210088751AA
COVER
1
44 N210059862AA
SCREW
2
45 N510018061AA
Cross recessed Pan head machine screw M3X8-4.8 A2J (Trivalent)
WASHER
2
46 N510020098AA Thick washer for M3
WASHER
6
47 N510018478AA
Small round-plain washer 3 10H A2J (Trivalent)
WASHER
6
48 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
M22
--
( KN610097178AA-08-2 )
2-C
X
軸
ユニ
ッ
ト
X-Axis Unit
パーツレイアウト
Kit No.
キット品
番
Kit Name
キット名称
N610097178AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M23
( KN610097178AA-08-3 )
