7-A 基 板 ホルダユニ ット Boa r d Ho ld er Un it パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N610027373AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - M55 ( KN610027373AA-08-1 )

100%1 / 368
Ref
No.
Remarks
R
1
Q'ty
6-C
基
板
コンベアR:CM232-M
_
3分割対応
Board Conveyor R:CM232-M_3 divided
ｲﾗｽﾄ
No.
Part No.
品　　名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610116671AA
Part Name
備　　　考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
PULLEY
6
31 KXFB02QLB00
NUT
6
43 KXFB02U4A00
PLATE
2
45 N210006519AA
BRACKET
2
46 N210121572AA
BRACKET
2
47 KXFB0EMSA00
RING
6
58 N210088855AA
SPACER
2
59 N510017101AA CB-425E
MOTOR
6
60 KXF0DWW9A00
S
K0354-F2M -2(Delivery drawing available)
PULLEY
16
69 N610116865AA
BOLT
6
77 N510017376AA
Hexagon socket head cap screw M4X6-10.9 A2J(Trivalent)
BOLT
4
79 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
2
83 N510017364AA
Hexagon socket head cap screw M4X35-10.9 A2J (Trivalent)
BOLT
24
84 N510017368AA
Hexagon socket head cap screw M4X45-10.9 A2J (Trivalent)
BOLT
12
85 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
12
86 N510017399AA
Hexagon socket head cap screw M5X25-10.9 A2J (Trivalent)
WASHER
4
90 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
24
91 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
28
92 N510018479AA
Small round-plain washer 4 10H A2J (Trivalent)
WASHER
24
95 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
SCREW
6
96 XXE5D6FT
Hexagon socket set screw Cup point M5X6-45H SOB
PULLEY
12
100 N610116866AA
BELT
2
102 N510050557AA
A
XVT-952 8.5X760E
PLATE
2
110 N210010735AA
BRACKET
2
111 N210121577AB
BRACKET
2
112 KXFB0A49B00
BELT
2
113 N510050555AA
A
XVT-952 8.5X926E
BELT
2
114 N510050556AA
A
XVT-952 8.5X1570E
M54
--
( KN610116671AA-01-3 )
7-A
基
板
ホルダユニット
Board Holder Unit
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610027373AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M55
( KN610027373AA-08-1 )
Ref
No.
Remarks
R
1
Q'ty
7-A
基
板
ホルダユニット
Board Holder Unit
ｲﾗｽﾄ
No.
Part No.
品　　名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610027373AA
Part Name
備　　　考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
CYL-NUT
1
4 KXFB00VKA00
CYL-NUT
1
5 N210164894AA
PLATE
1
6 N210041362AB
PLATE
2
8 N210037013AA
PLATE
1
10 N210037015AA
STOPPER
4
11 KXFB02R2A00
DOG
1
17 N210006364AA
BRACKET
1
20 N210037017AA
BRACKET
1
21 KXFB02RPA00
BRACKET
1
22 N210037018AA
CYLINDER
1
29 KXF0A6QAA00 CM2F40-30
JOINT
2
30 KXF02BZAA00 KQL06-02S
LINEAR-BUSH
4
31 KXF0DUXAA00 KTB10UU
SHAFT
4
32 KXF0DWW7A00 LSW-SC-10-144-01(DDA)
SENSOR
1
33 KXF0DL2AA01 PM-K53-C1(DA KXF0DL2AA01)
SHOCK-ABSORBER
4
34 KXF038NAA00 RB1007
SCREW
4
35 N510009302AA MSSG10-35
NUT
4
36 N510017889AA
Hexagon nut Type-3 Best class M10-6H-4T A2J (Trivalent)
PH-SENSOR
1
40 KXF0DL0AA01 PM-K53B-C1(DA KXF0DL0AA01)
BOLT
4
47 N510017494AA
Hexagon socket head cap screw M8X85-10.9 A2J (Trivalent)
COLLAR
4
48 N510014601AA NCLB8-16-58.0
WASHER
4
49 KXF0A11AA00 R8-20
PH-SENSOR
1
50 KXF0DXQRA00 PM-K53B-C1(DA KXF0DXQRA00)
BOLT
2
51 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
6
52 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
6
55 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
4
56 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
4
57 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
WASHER
6
60 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
4
61 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
2
63 N510020098AA Thick washer for M3
WASHER
6
64 N510020099AA Thick washer for M4
WASHER
6
67 N510018327AA Spring lock washer No.2 3 S A2J (Trivalent)
BOLT
8
70 N510017472AA
Hexagon socket head cap screw M8X20-10.9 A2J (Trivalent)
BOLT
16
71 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
4
72 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
4
73 N510017433AA
Hexagon socket head cap screw M6X16-10.9 A2J (Trivalent)
M56
--
( KN610027373AA-08-1 )
