6-B 基 板 コンベアR:CM232-M _ 3分割対応 Board Conveyor R :CM232-M _3 divided パーツレイアウト Ki t N o . キット 品番 Kit N a me キット名称 N610116671AA ｾｸｼｮﾝNo. PARTS LAYOUT Section No. - - M51 ( KN610116671AA-01-2 )
Ref
No.
Remarks
R
1
Q'ty
6-A
基
板
コンベアR:CM232-M
_
3分割対応
Board Conveyor R:CM232-M_3 divided
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610116671AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SENSOR
1
6 N610012889AA
FRAME
1
21 N210121567AB
GUIDE
1
22 KXFB01J2A00
GUIDE
2
23 N210022333AB
CLAMPER
2
24 N210071190AB
GUIDE
2
25 N210120283AA
GUIDE
2
26 N210022323AA
FRAME
1
27 N210121568AC
GUIDE
1
28 KXFB01J3A00
PLATE
1
29 N210125164AA
BLOCK
6
30 KXFB0EMPA00
BRACKET
2
42 N210121571AA
BRACKET
6
44 KXFB03Y3A00
BOLT
12
53 KXF0ATMAA00 CBS4-8
JOINT
4
54 N510064398AA M-3ALU-4-X83
JOINT
8
55 KXF0DX7DA00 UTF4BU-M3
AIR-SLIDE
6
57 N510019323AA MXPJ6-5-X23A
BOLT
12
74 N510017305AA
Hexagon socket head cap screw M3X10-10.9 A2J (Trivalent)
BOLT
8
78 N510017381AA
Hexagon socket head cap screw M4X8-10.9 A2J (Trivalent)
BOLT
14
80 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
2
82 N510017359AA
Hexagon socket head cap screw M4X25-10.9 A2J (Trivalent)
BOLT
12
85 N510017390AA
Hexagon socket head cap screw M5X12-10.9 A2J (Trivalent)
BOLT
24
87 N510017337AA
Hexagon socket head cap screw M3X6-10.9 A2J (Trivalent)
WASHER
24
90 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
12
91 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
6
94 N510020099AA Thick washer M4
BOLT
6
101 KXF0BNYAA00 CBSST4-12
BOLT
8
104 N510026171AA SEH0410
WASHER
4
105 N510029995AA 87FWSSB-D8.0-V4.0-T1.5
M50
--
( KN610116671AA-01-1 )
6-B
基
板
コンベアR:CM232-M
_
3分割対応
Board Conveyor R:CM232-M_3 divided
パーツレイアウト
Ki
t
N
o
.
キット
品番
Kit Name
キット名称
N610116671AA
ｾｸｼｮﾝNo.
PARTS LAYOUT
Section No.
--
M51
( KN610116671AA-01-2 )
Ref
No.
Remarks
R
1
Q'ty
6-B
基
板
コンベアR:CM232-M
_
3分割対応
Board Conveyor R:CM232-M_3 divided
ｲﾗｽﾄ
No.
Part No.
品 名品番 数量
R
2
パーツリスト
Kit N
o
.
キット品
番
Kit Name
キット名称
N610116671AA
Part Name
備 考
ｾｸｼｮﾝNo.
PARTS LIST
Section No.
R
3
SENSOR
1
11 N610012890AA
SENSOR
2
16 N610012891AA
STOPPER
1
32 KXFB02N4A03
PLATE
1
33 N210022326AA
PLATE
1
34 N210022327AA
D-PIN
1
36 KXFB02NAA00
BLOCK
2
38 N210127276AB
BRACKET
3
41 N210129274AA
BRACKET
1
48 KXFB0A4FA00
BRACKET
2
49 N210121573AA
BRACKET
1
51 KXFB0A4GB00
BRACKET
2
52 N210127277AA
BOLT
1
61 KXF0ASEAA00 CBSS4-6
SPRING
1
62 KXF0CWKAA00 HP063-027-0.6
CYLINDER
1
63 KXF0DZBAA00
CJPB15-DCG8017G-15(Delivery drawing available)
SPEED-CONTROLLER
1
64 KXF00YSAA00 AS1211F-M5-04
WASHER
1
65 N510010165AA WASM12-6-1
PIN
1
66 KXF02Y8AA00 MS4-20
PIN
1
67 KXF0303AA00 MSTH6-30
WASHER
1
68 KXF0E0UXA00 FWSSS-D9.0-V6.0-T2.6
JOINT
8
71 N510064400AA M-3AU-4-X83
BOLT
2
72 N986ACB340 ACB3-40
BOLT
16
73 N510017341AA
Hexagon socket head cap screw M3X8-10.9 A2J (Trivalent)
BOLT
10
75 N510017308AA
Hexagon socket head cap screw M3X12-10.9 A2J (Trivalent)
BOLT
2
79 N510017344AA
Hexagon socket head cap screw M4X10-10.9 A2J (Trivalent)
BOLT
6
80 N510017346AA
Hexagon socket head cap screw M4X12-10.9 A2J (Trivalent)
BOLT
2
81 N510017351AA
Hexagon socket head cap screw M4X16-10.9 A2J (Trivalent)
BOLT
2
82 N510017359AA
Hexagon socket head cap screw M4X25-10.9 A2J (Trivalent)
BOLT
2
88 N510017354AA
Hexagon socket head cap screw M4X20-10.9 A2J (Trivalent)
WASHER
8
89 N510018494AA
Round finish plain washer 3 10H A2J (Trivalent)
WASHER
10
90 N510018497AA
Round finish plain washer 4 10H A2J (Trivalent)
WASHER
1
91 N510018499AA
Round finish plain washer 5 10H A2J (Trivalent)
WASHER
14
93 N510020098AA Thick washer M3
WASHER
4
94 N510020099AA Thick washer M4
WASHER
6
95 N510018330AA Spring lock washer No.2 4 S A2J (Trivalent)
NUT
10
97 N510017855AA
Hexagon nut Type-1 Best class M4-6H-4T A2J (Trivalent)
NUT
2
98 N510017849AA
Hexagon nut Type-1 Best class M3-6H-4T A2J (Trivalent)
NUT
1
106 N210020696AA
STOPPER
1
107 N210020697AA
BRACKET
1
108 KXFB02KWB00
NUT-PLATE
1
109 KXFB01JGA00
CYLINDER
1
115 KXF0DWWEA00 CJ2B16-35S
JOINT
1
116 KXF02BTAA00 KQL04-M5
M52
--
( KN610116671AA-01-2 )
