A /S 器具 资 材信息 11 - 6 1 11.1.31. Door Ass'y -T op Door 组装完成图 SMT 顶级人脉圈平台资料下载
High Speed Multi Tray Feeder STF-100NA
用户手册
11-60
No.
TECHWIN
Part No.
JIYOUNG
Part No.
Part Name Q'ty Type ( Specification) Remark
1 FC30-004380A JW100N-MEL01-028 SENSOR PLATE 2 90*32*1.6T
2 FC09-006792A JW100N-MEL01-023 MOTOR BRACKET 1 150*74*20
3 FC09-006795A JW100N-MEL01-030 END BRACKET 1 70*46*20
4 MC03-002328A JW100N-MEL01-101 BEARING 1 6000ZZ
5 FC18-003310A JW100N-MEL01-102 SNAP RING 1 SHAFT C10
6 MC13-001009A JW100N-MEL01-103 BALLSCREW 1 BNK1510-5.6G2+671LC7Y
7 AM03-018856A JW100N-MEL01-104 SUPPORT UNIT 1 EK12
8 FC14-002158A JW100N-MEL01-105 COUPLING 1 SRB-39-10-14
9 EP08-001006 KJ_100NA_E_P002 SERVO MOTOR 1 MSME042G1T
SMT顶级人脉圈平台资料下载
A
/S
器具资材信息
11-61
11.1.31. Door Ass'y -Top Door
组装完成图
SMT顶级人脉圈平台资料下载
High Speed Multi Tray Feeder STF-100NA
用户手册
11-62
No.
TECHWIN
Part No.
JINYOUNG
Part No.
Part Name Q'ty Type ( Specification) Remark
1 AM03-017459A JW100N-MMA05-001
ASSY,TRAYFEEDER-TOP
DOOR_STF100NA
1 500*462.3*99*2T
2 FC09-006722A JW100N-MMA05-002 ACRYL BRACKET 1 360*333*1.6T
3 CM01-001013A JW100N-MMA05-003 ACRYL 1 360*333*3T
4 FC29-006404A JW100N-MMA05-101 PULL HANDLE 1 BYGSR10100
5 FC29-006419A JW100N-MMA05-102 TENSION HINGES 2 BYHS60-AT
6 FC38-001033A JW100N-MMA05-103 GAS SPRING 2
7 FC09-006278A JW100N-MMA05-104 GAS SPRING BRACKET 4 BY4-BK-2
8 AM03-018621A JW100N-MMA05-105 E-TYPE BEND RING 4 E-6
