High Speed Multi Tray Feeder STF-100NA
用户手册
11-74
No.
TECHWIN
Part No.
JINYOUNG
Part No.
Part Name Q'ty
Type
( Specification)
Remark
1
AM16-
001186A
KJ_100NA_E_C033 ASSY,CABLE-SOLENOID-TOP-DOOR-100NA 1
2464 24AWG-
3C
TSOL
2
AM16-
001191A
KJ_100NA_E_C030 ASSY,CABLE-SOLENOID-BUFFER1-100NA 1
2464 24AWG-
3C
BSOL1
3
AM16-
001194A
KJ_100NA_E_C020 ASSY,CABLE-START-SWITCH-100NA 1
2465 24AWG-
3C
LEDG/START
4
AM16-
001192A
KJ_100NA_E_C021 ASSY,CABLE-STOP-SWITCH-100NA 1
2466 24AWG-
3C
LEDR/STOP
5
AM16-
001193A
KJ_100NA_E_C022 ASSY,CABLE-SOLENOID-FRONT-DOOR-100NA 1
2467 24AWG-
3C
FSOL
6
AM16-
001183A
KJ_100NA_E_C085 ASSY,CABLE-TOWER_LAMP-100NA 1
2468 24AWG-
3C
ALARM
7
AM16-
001185A
KJ_100NA_E_C032 ASSY,CABLE-SOLENOID-BUFFER3-100NA 1
2469 24AWG-
3C
BSOL3
8
AM16-
001132A
KJ_100NA_E_C031 SWITCH,ETC-LIMIT-100NA(TOP DOOR SWITCH) 1
2470 24AWG-
3C
TDSW
9
AM16-
001144A
KJ_100NA_E_C051
ACCESSORY,SENSOR-PHOTO-100NA(ELEVATOR UP
LIMIT SENSOR)
1 EE-SX671A EULS
SMT顶级人脉圈平台资料下载
A
/S
器具资材信息
11-75
SMT顶级人脉圈平台资料下载
High Speed Multi Tray Feeder STF-100NA
用户手册
11-76
No.
TECHWIN
Part No.
JINYOUNG
Part No.
Part Name Q'ty
Type
( Specification)
Remark
1
AM16-
001187A
KJ_100NA_E_C035 ASSY,CABLE-SOLENOID-BUFFER4-100NA 1
2464 24AWG-
3C
BSOL4
2
EP19-
001006A
KJ_100NA_E_C036
ACCESSORY,SENSOR-MICROPHOTO-100NA(BUFFER
PALLET CHECK2)
1 EE-SPY401 BPC
3
AM16-
001188A
KJ_100NA_E_C037 ASSY,CABLE-SOLENOID-BUFFER2-100NA 1
2464 24AWG-
3C
BSOL2
4
AM16-
001189A
KJ_100NA_E_C023 ASSY,CABLE-SWITCH,ETC-EMERGENCY-100NA 1
2464 24AWG-
3C
ESW
5
EP19-
000043A
KJ_100NA_E_C029
ACCESSORY,SENSOR-PHOTO-100NA
(MAGAZINE IN PALLET CHECK SENSOR)
1 E3T-FD11 MICS
6
AM16-
001190A
KJ_100NA_E_C024 ASSY,CABLE-CHANGE-SWITCH-100NA 1
2464 24AWG-
3C
LEDB/CHANGE
7
EP20-
001001A
KJ_100NA_E_C025
SWITCH,ETC-LIMIT-100NA
(FRONT DOOR SWITCH SENSOR)
1
2464 24AWG-
3C
FDSW
8
EP20-
001002A
KJ_100NA_E_C026
SWITCH,ETC-PHOTO-100NA
(BACK PALLET CHECK_ EMITTER)
1 E3T-ST11 BPCE
