4 Electrical Section
4-15
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0004h 0 Air Pressure: Head A1 Bit 0 000Ah 0 Air Pressure: Head A4 Bit 0
1 Air Pressure: Head A1 Bit 1 1 Air Pressure: Head A4 Bit 1
2 Air Pressure: Head A1 Bit 2 2 Air Pressure: Head A4 Bit 2
3 Air Pressure: Head A1 Bit 3 3 Air Pressure: Head A4 Bit 3
4 Air Pressure: Head A1 Bit 4 4 Air Pressure: Head A4 Bit 4
5 Air Pressure: Head A1 Bit 5 5 Air Pressure: Head A4 Bit 5
6 Air Pressure: Head A1 Bit 6 6 Air Pressure: Head A4 Bit 6
7 Air Pressure: Head A1 Bit 7 7 Air Pressure: Head A4 Bit 7
0006h 0 Air Pressure: Head A2 Bit 0 000Ch 0 Air Pressure: Head A5 Bit 0
1 Air Pressure: Head A2 Bit 1 1 Air Pressure: Head A5 Bit 1
2 Air Pressure: Head A2 Bit 2 2 Air Pressure: Head A5 Bit 2
3 Air Pressure: Head A2 Bit 3 3 Air Pressure: Head A5 Bit 3
4 Air Pressure: Head A2 Bit 4 4 Air Pressure: Head A5 Bit 4
5 Air Pressure: Head A2 Bit 5 5 Air Pressure: Head A5 Bit 5
6 Air Pressure: Head A2 Bit 6 6 Air Pressure: Head A5 Bit 6
7 Air Pressure: Head A2 Bit 7 7 Air Pressure: Head A5 Bit 7
0008h 0 Air Pressure: Head A3 Bit 0 000Eh 0 Air Pressure: Head A6 Bit 0
1 Air Pressure: Head A3 Bit 1 1 Air Pressure: Head A6 Bit 1
2 Air Pressure: Head A3 Bit 2 2 Air Pressure: Head A6 Bit 2
3 Air Pressure: Head A3 Bit 3 3 Air Pressure: Head A6 Bit 3
4 Air Pressure: Head A3 Bit 4 4 Air Pressure: Head A6 Bit 4
5 Air Pressure: Head A3 Bit 5 5 Air Pressure: Head A6 Bit 5
6 Air Pressure: Head A3 Bit 6 6 Air Pressure: Head A6 Bit 6
7 Air Pressure: Head A3 Bit 7 7 Air Pressure: Head A6 Bit 7
■ Device 6
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit0 0002h 0 Start(F)
1 Device No. Bit1 1 Cycle Stop(F)
2 Device No. Bit2 2 Cancel(F)
3 Device Added Information Bit0 3 Alarm Off(F)
4 Device Added Information Bit1 4 Recovery(F)
5 Device Added Information Bit2 5 Servo(F)
6 Device Added Information Bit3 6 Enable(F)
7 Output Register Value Bit0 7 Setup(MXR)
0001h 0 Output Register Value Bit1 0003h 0 Setup(CFB-F)
1 Output Register Value Bit2 1 Go Rear(F)
2 Output Register Value Bit3 2 Auto/Manual Select Switch (F) (1:Auto)
3 Output Register Value Bit4 3 EMG(F)
4 Input Register Value Bit0 4 Front Cover OPEN Detection
5 Input Register Value Bit1 5 EMG Stop External Input
6 Input Register Value Bit2 6 Slowdown External Input
4 Electrical Section
4-16
7 Input Register Value Bit3 7
■ Device 8
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit0 0002h 0 Start(R)
1 Device No. Bit1 1 Cycle Stop(R)
2 Device No. Bit2 2 Cancel(R)
3 Device Added Information Bit0 3 Alarm Off(R)
4 Device Added Information Bit1 4 Recovery(R)
5 Device Added Information Bit2 5 Servo(R)
6 Device Added Information Bit3 6 Enable(R)
7 Output Register Value Bit0 7 Setup(MXR)
0001h 0 Output Register Value Bit1 0003h 0 Setup(CFB-R)
1 Output Register Value Bit2 1 Go Front(R)
2 Output Register Value Bit3 2 Auto/Manual Select Switch (R) (1:Auto)
3 Output Register Value Bit4 3 EMG(R)
4 Input Register Value Bit0 4 Rear Cover OPEN Detection
5 Input Register Value Bit1 5 EMG Stop External Input
6 Input Register Value Bit2 6 Slowdown External Input
7 Input Register Value Bit3 7
■ Device 10
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0000h 0 Device No. Bit0 0002h 0 Board Stopper Up A
1 Device No. Bit1 1 Board Stopper Down
2 Device No. Bit2 2 Main Clamp Up A
3 Device Added Information Bit0 3
4 Device Added Information Bit1 4 Main Clamp Down
5 Device Added Information Bit2 5
6 Device Added Information Bit3 6
7 Output Register Value Bit0 7 Entrance Sensor
0001h 0 Output Register Value Bit1 0003h 0
1 Output Register Value Bit2 1 Buffer Stopper Up
2 Output Register Value Bit3 2 Buffer Stopper Down
3 Output Register Value Bit4 3 Main Conveyor Arrival A
4 Input Register Value Bit0 4 Exit Sensor
5 Input Register Value Bit1 5
6 Input Register Value Bit2 6 Entrance Buffer Arrival
7 Input Register Value Bit3 7 Exit Buffer Arrival
4 Electrical Section
4-17
Address
Bit
No.
Signal Name Address
Bit
No.
Signal Name
0004h 0 Y-axis ORG 0008h 0 Rear Clamp On
1 Y-axis OP- 1 Rear Clamp Off
2 Y-axis OR+ 2 Side Clamp On
3 3 Side Clamp Off
4 X-axis ORG 4
5 X-axis OR- 5
6 X-axis OR+ 6
7 7 Conveyor Width Sensor
0005h 0 0009h 0
1 1
2 2
3 3
4 Air Pressure Down (failure) 4 AWC OR+
5 Ready Input 5 Grid-Lok On
6 Board Available Input 6
7 AWC Pin Detection 7
0006h 0 CFB(F) Lock 000Ah 0
1 CFB(F) Unlock 1
2 CFB(F) Check 1 2
3 3
4 CFB(R) Lock 4
5 CFB(R) Unlock 5
6 CFB(R) Check 1 6
7 7
0007h 0 ANC A Close 000Bh 0 Conveyor1 Alarm
1 ANC A Open 1 Conveyor2 Alarm
2 ANC B Close 2 Conveyor3 Alarm
3 ANC B Open 3
4 4
5 5
6 MXST2 L Position 1 6
7 MXST2 L Position 2 7
