A8 コンベア ユニット Conveyor unit ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 1 EZ1- 492 - 175 - 11 ｾﾝｻ - ASSY (AD3 ｼﾞｸ CW ) ASSY , SENSOR 1 2 EZ1- 492 - 175 - 21 ｾﾝｻ - ASSY (AD1 …
A8
コンベアユニット
Conveyor unit
25
33
17
9
9
14
23
27
22
23
10
19
12
26
26
21
26
26
26
21
21
26
19
19
19
22
27
23
14
23
10
10
25
33
33
34
14
30
18
14
18
31
32
20
16
6
28
31
28
28
28
28
28
25
6
32
16
20
32
16
20
32
20
16
7
32
16
20
32
16
20
13
33
24
25
25
25
33
17
10
10
19
19
19
19
15
12
10
33
11
1
1
24
29
2
5
4
1
3
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
8
30
A-28
A8
コンベアユニット
Conveyor unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ1-492-175-11
ｾﾝｻ
-
ASSY (AD3
ｼﾞｸ
CW)
ASSY, SENSOR
1
2 EZ1-492-175-21
ｾﾝｻ
-
ASSY (AD1
ｼﾞｸ
CCW)
ASSY, SENSOR
1
3 EZ1-492-178-11
ｾﾝｻ
-
ASSY (AD1
ｼﾞｸ
ORG)
ASSY, SENSOR
1
4 EZ1-492-178-21
ｾﾝｻ
-
ASSY (AD2
ｼﾞｸ
ORG)
ASSY, SENSOR
1
5 EZ1-492-178-31
ｾﾝｻ
-
ASSY (AD3
ｼﾞｸ
ORG)
ASSY, SENSOR
1
6 EZ3-971-050-01
E
ﾘﾝｸﾞ
RING, E
2
7 EZ3-217-504-21
ｹ-ﾌﾞﾙ ﾍﾞｱ
(TKP0180W30-R28-25L*
BARE (TKP0180W30-R28-25L*)
1
8 EZ4-453-933-02
ﾀｲ
ﾏｳﾝﾄ
(LPMS-S8-C)
MOUNT (LPMS-S8-C), TIE
24
9 EZ4-452-329-02
ｽﾌﾟﾗｲﾝ
ｼﾞｸ
SHAFT, SPLIN
2
10 EZ4-452-335-03
ﾀﾞｲｹｲ
ﾈｼﾞ
SCREW, TRAPEZOIDAL
6
11 EZ4-469-061-01
ｾﾝｻ
ﾄﾞｸﾞ
(C)
DOG (C), SENSOR
2
12 EZ4-469-069-02
ﾍﾞｱﾘﾝｸﾞ
ﾎﾙﾀﾞ
ﾘｱ
HOLDER (REAR), BEARING
2
13 EZ4-469-057-01
ｺﾝﾍﾞｱ ﾍﾞ-ｽ
A
BASE (A), CONVEYOR
1
14 EZ4-452-357-01
ﾎﾙﾀﾞ
(1)
HOLDER (1)
4
15 EZ4-469-067-01
ﾊﾞﾌﾟﾂｸ ｱﾂ ﾖｳ ﾌﾟﾚ-ﾄ
A
PLATE (A), BACK UP
1
16 EZ4-454-550-01
ﾉﾌﾞ
KNOB
6
17 EZ4-455-748-01
LM
ｶﾞｲﾄﾞ
(SHS15V2UU+720-2)
LM GUIDE (SHS15V2UU+720-2)
2
18 EZ4-455-778-01
ﾍﾞｱﾘﾝｸﾞ
626ZZ1
BEARING (626ZZ1)
2
19 EZ4-455-783-01
ﾌﾗﾝｼﾞ
ﾂｷ
ｼﾞｸ
ｳｹ
(SFL6900ZZ)
RETAINER (SFL6900ZZ), SHAFT
12
20 EZ4-455-784-01
C
ｶﾞﾀ
ﾄﾒﾜ
(STWN10)RING
(STWN10),C TYPE RETAINING
6
21 EZ4-455-786-01
ﾀｲﾐﾝｸﾞ
ﾍﾞﾙﾄ
(1722-3GT-9)
BELT (1722-3GT-9), TIMING
3
22 EZ4-455-787-01
ﾀｲﾐﾝｸﾞ
ﾍﾞﾙﾄ
(240-3GT-9)
BELT (240-3GT-9), TIMING
2
23 EZ4-455-789-01
ﾍﾞｱﾘﾝｸﾞ
(F626ZZ1)
BEARING (F626ZZ1)
4
24 EZ4-455-790-02
ｹ-ﾌﾞﾙﾍﾞｱ
(TKP13H10-20WR28-34L*)
BARE (TKP13H10-20WR28-34L-FO-*)
2
25 EZ4-455-791-01
ﾅﾂﾄ
ATM14R-TNBC
NUT (ATM14R-TNBC)
6
26 EZ4-455-794-02
ﾌﾟ-ﾘ
(A)
PULLEY (A)
6
27 EZ4-455-799-02
ﾌﾟ-ﾘ
(B)
PULLEY (B)
2
28 EZ4-455-798-01
ｳｽﾆｸ ｷﾝｿﾞｸ ｶﾗ
-
(TASC2-0.5-3.5)
COLLAR (TASC2-0.5-3.5), METAL
6
29 EZ4-465-809-01
ﾊ-ﾈｽ ｶﾊﾞ
-
COVER, HARNESS
1
30 EZ4-469-070-02
ﾍﾞｱﾘﾝｸﾞ ﾎﾙﾀﾞ ﾌﾟﾛﾝﾄ
HOLDER (FRONT), BEARING
2
A-29
A8
コンベアユニット
Conveyor unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
31 EZ4-469-071-01
ﾍﾞｱﾘﾝｸﾞ ﾎﾙﾀﾞ ｾﾝﾀ
-
HOLDER (CENTER), BEARING
2
32 EZ4-677-258-01
ﾎﾞ-ﾙ ﾍﾞｱﾘﾝｸﾞ
(6900ZZ)
BEARING (6900ZZ), BALL
6
33 EZ4-469-074-02
ﾚ-ﾙ ｽﾃｲ
STAY, RAIL
6
34 EZ4-469-064-01
ｾﾝｻ
ﾄﾞｸﾞ
(F)
DOG (F), SENSOR
1
EZ4-461-460-11
ﾀｲ ｱﾝｶ
-
(TA1S10-M0)
ANCHOR, TIE (TA1S10-M0)
1
EZ2-580-614-01
ﾈｼﾞ
+K M3X8
SCREW, +K M3X8
8
EZ7-682-260-09
+K 4X6
SCREW +K 4X6
24
EZ7-683-246-08
6
ｶｸｱﾅﾂｷ
ﾄﾒﾈｼﾞ
4.0X5,
ﾋﾗｻｷ
SET SCREW 4.0X5, FLAT-POINT
12
EZ7-683-404-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X8
BOLT,HEXAGON SOCKET 3X8
22
EZ7-683-417-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X5BOLT,HEXAGON
SOCKET 4X5
4
EZ7-683-418-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X6
BOLT,HEXAGON SOCKET 4X6
8
EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
42
EZ7-683-422-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X14
BOLT,HEXAGON SOCKET 4X14
54
EZ7-683-427-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X25
BOLT,HEXAGON SOCKET 4X25
4
EZ7-683-437-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X14
BOLT,HEXAGON SOCKET 5X14
8
EZ7-683-442-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X25
BOLT,HEXAGON SOCKET 5X25
8
EZ4-722-178-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾄﾒﾈｼﾞ
(SBCP3-5)
SET-SCREW, HEAD (SBCP3-5)
16
EZ3-608-695-02
ｻﾞｶﾞﾈﾂｷ
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X14
HEXAGON SOCKET HEAD SCREW
4X14
24
EZ4-456-435-01
ｸﾐｺﾐ
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(CBST3-6)
BOLT (CBST3-6), HEXAGON HOLE
14
EZ4-455-805-01
ｻﾞｶﾞﾈﾂｷ
ﾛﾂｶｸ
ｱﾅ
ﾎﾞﾙﾄ
(CBST4-10)
BOLT (CBST4-10), HEXAGON HOLE
12
EZ7-684-024-04
N 4, TYPE 2
N 4, TYPE 2
4
EZ3-607-925-02
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
(M4X60)
BOLT,HEXAGON SOCKET 4X60
2
EZ7-683-435-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X10
BOLT,HEXAGON SOCKET 5X10
8
EZ7-682-561-09
+B 4X8
SCREW +B 4X8
4
EZ4-462-897-01
ｶﾗ- ﾁﾂﾌﾟ
(GR19)
CHIP, COLLAR
1
EZ4-462-897-11
ｶﾗ- ﾁﾂﾌﾟ
(GR20)
CHIP, COLLAR
1
EZ4-462-897-21
ｶﾗ- ﾁﾂﾌﾟ
(GR21)
CHIP, COLLAR
1
EZ4-462-897-31
ｶﾗ- ﾁﾂﾌﾟ
(GR22)
CHIP, COLLAR
1
EZ4-462-897-41
ｶﾗ- ﾁﾂﾌﾟ
(BLK24)
CHIP, COLLAR
1
A-30
