SIPLACE Pro 16.0 (R18-2) / Version Description 11/2018 Edition

Contents

1 Introduction 5

1.1 System Overview ................................................................................................. 6

2 Scope of Delivery 7

2.1 Packages ............................................................................................................. 7

2.2 Languages ........................................................................................................... 8

2.3 Licenses ............................................................................................................... 9

3 Prerequisites 11

3.1 Supported Station Software Versions and Machine Types ................................ 11

3.2 Supported DEK Printer Software Versions and Printer Types ........................... 13

3.3 Supported Feeder Types ................................................................................... 13

4 Features of SIPLACE Pro 16.0 15

4.1 Customer-Specific Nozzles – Improvements ..................................................... 15

4.2 OSC Package Option – Enhancements............................................................. 16

4.3 "IPC-HERMES-9852" – Interface ID .................................................................. 16

4.4 Using Placements as Fiducials for Aligning Components .................................. 17

4.5 CPP Placement Head – Increased Placement Force and Component

Weight ................................................................................................................ 17

4.6 Smart Pin Support for SIPLACE TX V2 Series .................................................. 17

4.7 Long Board Option (LBO) for SIPLACE TX- and TX V2-Series ......................... 18

4.8 Station Behavior When Using Alternative Tracks .............................................. 18

4.9 Linear Dipping Unit 2 X / Linear Dipping Unit E – Enhancements ..................... 18

4.10 Flux Inspection ................................................................................................... 19

4.11 SIPLACE MeasuringFeeder X ........................................................................... 19

4.12 DEK Printer Support - Enhancements ............................................................... 21

4.13 Cracked Die Inspection ...................................................................................... 21

4.14 Measuring Barcode on Bottom Side of Component........................................... 22

4.15 Disabling Creation of LCU Number .................................................................... 22

4.16 Free Nozzle Orientation ..................................................................................... 22

4.17 Stand-alone Data Model Import Tool ................................................................. 23

4.18 Grid Board Editor – Enhancements ................................................................... 23

4.19 Line Control GUI – Improved Conveyor Lane Settings ...................................... 24

4.20 ASCII Centroid Import Wizard – Enhancements ................................................ 24

4.21 Logging of Changes To User Data .................................................................... 25

4.22 Miscellaneous SIPLACE Pro Improvements and Enhancements ...................... 26

5 Restrictions 27

6 Troubleshooting 29

6.1 Problems and Solutions ..................................................................................... 29

7 Appendix 30

7.1 ASM Error Reporter Service .............................................................................. 30

SIPLACE Pro 16.0 (R18-2) / Version Description 11/2018 Edition

1 Introduction

SIPLACE® Pro 16.0 (R18-2) is the programming system for SIPLACE placement. The placement

programs for the placement lines are prepared, generated and optimized with SIPLACE Pro. The

Release-Tag displays in which ASM Release the current product has been released.

Example: (R18-2) –> 2nd Release, 2018.

Additionally, the SIPLACE Pro programming system supports DEK printing solutions. ASM Printer

Programming extends the existing SIPLACE Pro programming system by adding functionality for

editing print process data for DEK printing systems. The SIPLACE Pro programming system allows

preparing, optimizing and downloading printing programs. The ASM Printer Programming license

can be ordered separately, item no: [00117815-xx].

NOTICE

Please note the following:

As a user of the statistic functionalities of ASM's software in this ASM's product, you may

process personal data. Processing - including analyzing - personal data is subject to

data protection and other laws, which might impose restrictions and that might differ by

country. You are responsible to ensure that such processing is performed in compliance

with data protection and other laws applicable to you and your company. We therefore

would like to urge you to consult your supervisor or your legal departmen

t as regards the

data protection and other legal requirements to be followed.
