SIPLACE Pro 16.1 (R19-1) / Version Description 05/2019 Edition
16
Defining Circular or Elliptical Panels
The dropdown list in the New Polygon Shape dialog can also be used to define circular or elliptical
panels by selecting the respective shape from the list.
4.6 LED Centering Simulation – Enhancements
The SIPLACE Pro Optimizer has been enhanced to now consider the process time for LED
Centering. LED Centering can be switched on and off for individual placement positions by setting
an Align flag.
4.7 Activating 64-bit Object ID Range
It is possible to activate the 64-bit object ID range to use a higher number of objects in the
SIPLACE Pro Database. The 64-bit object ID range can be activated in the settings dialog.
NOTICE
As soon as this option has been enabled, the SIPLACE Pro objects can only be
transferred to stations with station software 712.x and higher or to stations with station
software 4.xx or 5.xx.
After enabling, all possible object IDs will first be filled up in the number band 32-bit,
before any object IDs larger than 32-bit are created. If no object IDs larger than 32-bit
are created, this option can be disabled again.
4.8 Grid Report of Placement List – Enhancements
The Grid Report of the placement list has been enhanced to show alternative components of the
placement. The Grid Report shows the total amount of alternative components and the amount of
alternative components per placement.
Restrictions
– Alternative component shapes are not listed.
4.9 New Nozzles for Measuring Feeder
The following measuring nozzle types have been introduced:
– 1403, 1404, 1406
– 2403, 2404, 2406
– 4403, 4404, 4406
– 6403, 6404, 6406
The nozzles are designed for electrical verification of components in the measuring feeder. They
are not assigned to any component shape of the standard shape library.
SIPLACE Pro 16.1 (R19-1) / Version Description 05/2019 Edition
17
4.10 License Changes for “Whispering Down The Line”
The “Whispering Down The Line” license has been updated. With this new version, the “Whispering
Down The Line of barcode information – Machine Connection“ license is no longer required.
If previously only the “Whispering Down The Line of barcode information – Machine Connection“
license has been purchased, then the “Whispering Down The Line” license needs to be purchased
when upgrading to SIPLACE Pro 16.1.
The “Whispering Down The Line” license is only required if IPC-HERMES-9852 is not used on the
devices between the first and last placement stations.
4.11 Individual Traceability Option for Printer and Inspection Systems
It is possible to switch the generation and processing of trace data on and off for individual printers
and inspection systems. This can be done using the Traceability option in the Device Editor.
4.12 Support of 3
rd
Party Machine Types
The Generic Line Device type list in the Object Properties dialog has been extended by the
device types Conveyor, Loader and Unloader to support 3
rd
party machines. Additionally, new icons
are introduced to distinguish between the device types:
Device Type
Icon
AOI
AOXI
AXI
Classification Area
Repair Area
Placement Station
Printer
Solder Paste Inspection
System
Oven
Conveyor
SIPLACE Pro 16.1 (R19-1) / Version Description 05/2019 Edition
18
Loader
Unloader
Table 4-1: List of device type icons
4.13 OSC Package Option – Enhancements
Detailed information on the OSC Package features can be found in the OSC Package User Guide,
item no. [00198374-xx].
The main enhancements made for the OSC Package Option in SIPLACE Pro are listed in the
overview below.
Placement of Critically Tall Components
The SIPLACE Pro Optimizer has been enhanced to support the placement of tall components
when the OSC package is activated. The components are placed with a CPP head in high head
position in the line’s last placement area.
By default, this feature is disabled if a job can be optimized without it.
The maximum height for components placed with a CPP head is 15.5 mm. Without the OSC
Package, the maximum height is 11.5 mm.
Restrictions
– An OSC license is available.
– The OSC package is activated for the last station of the line.
– Critically tall components are placed only at one head of the line within the last placement area.
– The Long Board Option must not be used at the last placement area.
– If a VHF TH head is used additionally to the CPP head in the last placement area, this feature
cannot be used on the CPP head.
– Component height restrictions apply to the whole job and not only to individual recipes.
– The maximum height for components can only be reached by lowering the warpage tolerance
of the board side to zero (default is 2 mm). This is done on the customer’s own risk.
Component Chipping Detection
The component chipping detection functionality checks whether the edge of a component has
larger deviations than defined. It can be enabled or disabled using the Chipping detection
checkbox in the Vision Inspection tab of the Component Shape Editor of SIPLACE Pro Desk.
Restrictions
– Only supported for vision types BareDie, BGA, CCGA, Chip, Moulded, Nonstandard.
– The OSC license must be available.
4.14 Configuring Multiple Nozzle Pockets at Once
It is possible to select multiple nozzle pockets in the nozzle magazines grid to configure them at the
same time. Any nozzle pockets not supporting the selected nozzle type are left unchanged. The
selection can be extended to more than one nozzle magazine.
