SIPLACE Pro 16.1 (R19-1) / Version Description 05/2019 Edition
7
2 Scope of Delivery
2.1 Packages
● SIPLACE Pro Basic License V16.1, item no. [00117842-xx] contains:
1 SIPLACE Pro Factory License (without connection to the SIPLACE stations)
● Software belonging to R19-1 is available on the ASM Software Collection USB Medium
R19-1, item no. [00117884-xx]. This USB stick contains all basic product packages of R19-1.
Additionally, the individual software packages (*.iso files) contain the relevant software
documents (Installation Manuals, Software Version Descriptions, User Guides etc.).
NOTICE
To Support Media:
Please use the Navigation Guide button of the Support Media Launcher to navigate
through the documentation.
The navigation guide and all related documents are available with the Support Media.
2.2 Languages
User Interface and Online Help SIPLACE Pro
The standard package contains German, English and Simplified Chinese. Other languages
contained in the language package are optional. The language package can be downloaded free of
charge from the ASM Download Center.
Available languages
● Czech
● French
● Hungarian
● Italian
● Japanese
● Korean
● Portuguese (Brazil)
● Spanish (Mexico)
NOTICE
The Optimizer Toolkit and SIPLACE LED Pairing are available in English, German and
Simplified Chinese. The SIPLACE Pro Optimizer Messages Help is available in English
and German only.
SIPLACE Pro 16.1 (R19-1) / Version Description 05/2019 Edition
8
2.3 Licenses
The available licenses are listed in the following table.
License
Type
Factory
Single
Object
Floating
Lines
SIPLACE Pro Server / Desk (includes OIS /
SIS)
✓
SIPLACE Pro Machine Connection
✓
✓
ASM Printer Programming
✓
✓
SiCluster
✓
SiCluster Professional
✓
SiCluster Professional – Machine
Connection
✓
✓
SiCluster Multiline – Machine Connection
✓
✓
Split Table Mode – Machine Connection
✓
✓
SIPLACE ASM Traceability – Machine
Connection
✓
✓
DEK ASM Traceability – Machine
Connection
✓
✓
SIPLACE Vision Teach Station
✓
Whispering Down The Line
Notice: This license is not needed if IPC-
HERMES-9852 is activated on all devices
between first and last placement station.
✓
✓
Automatic Program Download (PCB-
Barcode)
✓
✓
Station Wise Download – Machine
Connection
✓
✓
Borrow Performance – Machine
Connection
✓
✓
Reading Barcode recognition with PCB
Camera
Notice: This license is required for each
station in the line.
✓
✓
Alternative Components
✓
✓
Random Setup
✓
✓
SIPLACE Pro 16.1 (R19-1) / Version Description 05/2019 Edition
9
License
Type
Factory
Single
Object
Floating
Lines
Long Board Option – Machine Connection
(with station software version < 709)
Long Board Option up to 850 mm –
Machine Connection
(with station software version 7xx)
Long Board Option up to 1500 mm –
Machine Connection
(with station software version 709 and
higher)
Notice: The license is required for each
station in the line.
✓
✓
✓
✓
✓
✓
SIPLACE LED Pairing – Machine
Connection
✓
✓
Flexible Dual Lane – Machine Connection
Bound
✓
✓
Micron 15u3Sigma – Machine Connection
✓
✓
Vision OSC Package – Machine
Connection
✓
✓
SIPLACE LED Centering – Machine
Connection
✓
✓
MES - Process Interlocking - SIPLACE -
Machine Connection
✓
SIPLACE PCB Inspection – Machine
Connection
✓
Table 2-1: Available Licenses
Definition of the License Types
Factory
This license type is valid for the entire production run and is not assigned to a license server.
Single
This license type is valid in connection with a (single) station.
Object
This license type is bound to an object, in this case to the machine id. The license is unbound
until the first download to a station which requires this license type. Thereafter the license is
permanently bound to the machine id of this station.
Floating
This license type is fetched from a license server by the application and then released again
when the application is terminated. However, the number of licenses on the license server is
limited.
Lines
This license type is assigned to the placement line.
