sj6 uitra.pdf - 第7页

-4- Reminder: 1. Before connecting your phone to the "SJCAM X " APP, disconnect from other Wi-Fi networks and ensure your phone's Wi-Fi is enabled. 2. Viewing and downloading photos or videos tak en by the…

-3-

Be careful not to scratch and stain the lens when

using, otherwise it will affect the imaging clarity.

Compatible with external extension bases, mini

tripods, and other accessories.

Secondary

screen

1/4

screw hole

System

Setting Button

Battery

Compartment

Cover

1.3" LCD Display screen

Single click button to enter system settings

Front Screen 2.0" LCD Touch Screen

Open and remove / insert batteries

Start / stop recording or

take photo

Switching front and rear

screen

Name

Description

Power

Button


Indicator

Recording

Indicator

Recording

Button

Wi-Fi

indicator

Power on

Turn off

Blue light on

Blue light flashing

Red light flashing

Single press under

power off mode

Long press 2 seconds

under power on mode

Single press under

power on

Standby

Red light on Standby

Capturing

Recording

Long press for 2 seconds

under power on

Wi-Fi has turned on,

waiting to be connected

Green Light Quick

Flashing

Green Light Always on Wi-Fi Connected

Lens

-4-

Reminder:

1. Before connecting your phone to the "SJCAM X" APP, disconnect from other

Wi-Fi networks and ensure your phone's Wi-Fi is enabled.

2. Viewing and downloading photos or videos taken by the camera through the

"SJCAM X" APP does not consume your phone's data plan.

3. If an older version of the "SJCAM Zone" APP was previously installed, Wi-Fi

connection might fail. Please scan the QR code below to download and install the

latest version before connecting.

SJ6 Ultra supports three Wi-Fi connection methods: Bluetooth Quick Connect, App

QR Code Connect, and Manual Connect.

Choose one connection method based on your actual needs.

Download and Install SJCAM X APP

Scan the appropriate QR code below for your device type to download the APP.

Alternatively, search for "SJCAM X" in your phone's app store (Google Play Store

or App Store).

App Connection

TF card slot, support Max of 512 G memory card,

please choose the reputable brand

Charging / data transmission;

Voltage / current: 5V/2A, 5V/1A

SD slot

Record Audio

Play beep sound, recording voice playback

Charging

indicator

USB-C

connection port

Red light on

Red Light off

charging

Full charged

Microphone

Speaker

-5-

1. Bluetooth Quick Connect

1.1 Make sure the SJ6 Ultra is powered on.

1.2 On your smartphone, go to the Settings app, find the Bluetooth option, and turn

on Bluetooth.

1.3 Open the SJCAM X app and grant the necessary permissions. After following the

steps below, wait for the automatic connection.

Note: The permissions are only used to establish the connection between the app

and the camera and will not be used for any other purposes.

2. Scan QR code to connect

2.1 Turn on the SJ6 Ultra. Swipe down from the top edge of the screen to access the

Control Center menu. Tap the Wi-Fi icon and wait for the QR code to appear on the

camera screen.

2.2 Open the "SJCAM X" APP. Tap the "Scan QR Code" button on the homepage,

then use your phone to scan the QR code displayed on the camera screen to

connect automatically.

Note: The SJ6 Ultra's indicator light blinking green indicates that the camera's Wi-Fi

is successfully enabled and awaiting connection.

1 2

Please use the app

to scan the QR code to connect.

Please use the app

to scan the QR code to connect.

1 2
