2.10 Reel to Reel Manual Chapter Issue 3, August 14
TROUBLESHOOTING
The following table contains some of the most common problems that may be
encountered and is by no means exhaustive:
Fault Cause Solution
Rippled product on transport system Product reel not setup square within
machine
1. Realign product reel
2. Check gap between Inroad product
guides and product reel
3. Check gap between outroad trans-
port clamps and product reel
Fiducials not found Incorrect fiducial alignment Reset fiducials
Product fiducial creep exceeds
machine’s capability
If creep is outside of machine’s capabil-
ity, investigate product reel, change
product reel
Index length incorrect Adjust index length
Machine fails to pull enough product
through on first print, causing 'averag-
ing' calculation to be incorrect
Ensure there is no slack in the product
reel after the print area and reset fidu-
cials
Too much tension on product 1. Ensure there is slack, in the product
reel, before the print station
2. Ensure there is slack between the
outroad transport clamps and the
downline machine
Loss of vacuum Tooling plates not properly secure Ensure the tooling plates and all fittings
are secured
Vacuum covers not fitted correctly Ensure that the vacuum covers are cov-
ering the redundant holes on the inner
and outer transport vacuum plates.
Offset image print Screen centre not in line with tooling
centre
Reset screen alignment - Setup Prod-
uct - Alignment - Reset Screen Align-
ment
Image smudging Alignment of screen and tooling incor-
rect
Check centre of the product is in line
with centre of the tooling
Backoff too small causing product reel
to come into contact with the screen
Increase backoff distance
Backoff too big causing product reel to
bow upwards into the screen
Reduce backoff distance
Transport clamps overhanging the print
area
Reduce overhang distance
Product tearing during transport Feed rates of transport system too fast Reduce Feeder Speed and Feeder
Acceleration of transport system
Product not transporting Transport system not gripping product Ensure vacuum and the outroad trans-
port clamps are working correctly
A3 DRAWINGS
CONTENTS
Chapter Issue 3, Aug 14 Reel to Reel Manual 3.1
CHAPTER 3 A3 DRAWINGS
CONTENTS
Electrical
Pneumatic
Description Drawing No. Sheets Issue State
R2R Media Transport Circuit Diagram 193700 1 02
R2R CAN Distribution Circuit Diagram 201707 1 01
Description Drawing No. Sheets Issue State
R2R Installation Pneumatic Diagram 193697 1 02
A3 DRAWINGS
CONTENTS
3.2 Reel to Reel Manual Chapter Issue 3, Aug 14
