MODEL TCM-3500Z-2 0109-001 108 ㇱຠଏ⛎ㇱ FEEDER CARRIAGE SECTION Fig. 5-2 ࡞࡙࠾࠶࠻ Feeder Carriage 3 9 4 0 4 1 1 - 1 2 5 4 3 6 7 8 9 1 0 11 11 1 4 1 3 1 2 15 15 1 6 1 7 1 8 19 19 2 1 2 2 2 3 3 6 3 7 3 8 3 2 3 3 3 4 3 5 3 9 4 …
MODEL TCM-3500Z-2
0109-001
107
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
5-1
1 630 048 1464 BALL SCREW 1 678C--02H-001
2 630 047 9454 BRACKET 2 678C--02B-035
3 630 046 6874 COLLAR 2 678C--02B-037
4 630 046 6805 BEARING,PARTS 2 678C--02B-038
6 411 141 4503 WASHER V 8X17X1.6 4 FW8
7 411 141 3100 WASHER SPR 8 4 SW8
8 630 000 8043 BOLT,HEX-SCT 4 M8X35
9 630 032 5379 PIN,LOCATE 4 678C--02H-007
10 411 141 4800 WASHER V 12X24X2.5 8 FW12
11 411 141 3308 WASHER SPR 12 8 SW12
12 630 000 8241 BOLT,HEX-SCT 8 M12X40
21 630 047 8013 GUIDE,LINEAR 2 678C--02H-002
22 630 000 7770 BOLT,HEX-SCT 134 M5X20
31 630 047 6811 BRACKET 5 678C--02B-034
32 630 000 0252 SENSOR,PHOTO 8 PHS24, PHS25, PHS28, PHS29,
PHS30, PHS31, PHS32, PHS33
678C--02H-005
33 630 000 0269 SENSOR,PHOTO(CONNECTOR) 8 678C--02H-006
34 411 119 1909 WASHER V 3X7X0.5 32 FW3 F
35 411 086 4408 WASHER SPR 3 16 SW3 F
36 411 040 7803 SCR PAN 3X12 16 M3X12 PAN
37 411 141 4107 WASHER V 5X10X1 10 FW5
38 411 141 6705 WASHER SPR 5 10 SW5
39 630 000 7749 BOLT,HEX-SCT 10 M5X10
41 630 054 9973 BLOCK 4 678C--02B-031
42 630 048 4052 MECH PARTS(URETHANES) 4 678C--02H-016
43 630 000 7879 BOLT,HEX-SCT 4 M6X12
44 411 141 4701 WASHER V 10X21X2 8 FW10
45 411 141 3209 WASHER SPR 10 8 SW10
46 630 000 8142 BOLT,HEX-SCT 8 M10X35
MODEL TCM-3500Z-2
0109-001
108
ㇱຠଏ⛎ㇱ FEEDER CARRIAGE SECTION
Fig. 5-2 ࡞࡙࠾࠶࠻ Feeder Carriage
39
40
41
1-1
2
5
4
3
6
7
8
9
10
11
11
14
13
12
15
15
16
17
18
19
19
21
22
23
36
37
38
32
33
34
35
39
40
41
90
51
52
52
53
53
1-2
1-2
31-1
31-1
31-2
.
.
1-2
1-2
24
24
25
25
26
26
27
20-1
20-2
20-2
.
90
90
90
MODEL TCM-3500Z-2
0109-001
109
Key No. PART No. PART NAME Q’ty REMARKS
NOTE
5-2
1 -1 630 059 3280 BASE 1 678C--02B-001
1 -2 630 059 3297 BASE 1 678C--02B-002
2 630 048 4335 PLATE 4 678C--02B-003
3 411 141 4008 WASHER V 4X9X0.8 36 FW4
4 411 141 2905 WASHER SPR 4 36 SW4
5 630 000 7633 BOLT,HEX-SCT 36 M4X12
6 630 048 4175 PLATE 2 678C--02B-005
7 630 048 4182 PLATE 2 678C--02B-006
8 411 141 4107 WASHER V 5X10X1 46 FW5
9 411 141 6705 WASHER SPR 5 46 SW5
10 630 000 7763 BOLT,HEX-SCT 46 M5X16
11 630 048 4342 PLATE 4 678C--02B-007
12 411 141 4008 WASHER V 4X9X0.8 36 FW4
13 411 141 2905 WASHER SPR 4 36 SW4
14 630 000 7633 BOLT,HEX-SCT 36 M4X12
15 630 048 4359 SUPPORT 2 678C--02B-009
16 630 048 4366 SUPPORT 2 678C--02B-010
17 411 141 4107 WASHER V 5X10X1 16 FW5
18 411 141 6705 WASHER SPR 5 16 SW5
19 630 000 7756 BOLT,HEX-SCT 16 M5X12
20 -1 630 047 6798 BRACKET 1 678C--02B-032
20 -2 630 047 6804 BRACKET 1 678C--02B-033
21 411 141 4008 WASHER V 4X9X0.8 4 FW4
22 411 141 2905 WASHER SPR 4 4 SW4
23 630 000 7619 BOLT,HEX-SCT 4 M4X8
24 411 141 4107 WASHER V 5X10X1 48 FW5
25 411 141 6705 WASHER SPR 5 48 SW5
26 630 000 7763 BOLT,HEX-SCT 48 M5X16
27 630 005 4057 ACCESSORY,SW 4 678C--02H-022
31 -1 630 071 0465 SUPPORT 1 678C--02B-011
31 -2 630 071 0472 SUPPORT 1 678C--02B-012
32 630 055 1792 SUPPORT 16 678C--02B-013
33 411 141 4305 WASHER V 6X12.5X1.6 32 FW6
34 411 141 3001 WASHER SPR 6 32 SW6
35 630 000 7886 BOLT,HEX-SCT 32 M6X16
36 411 141 4305 WASHER V 6X12.5X1.6 12 FW6
37 411 141 3001 WASHER SPR 6 12 SW6
38 630 000 7879 BOLT,HEX-SCT 12 M6X12
39 411 088 1702 WASHER V 5X10X1 16 FW5 F
40 411 008 2109 WASHER SPR 5 16 SW5 F
41 411 140 4900 BOLT HEX 5X12 16 M5X12 HEX
51 630 056 1050 PLATE 1 678C--02B-014
52 411 141 4008 WASHER V 4X9X0.8 2 FW4
53 630 000 7626 BOLT,HEX-SCT 2 M4X10
90 630 047 6378 NAME PLATE,INDEX 6 678C--02H-024
