A1 X ビームユニット X beam unit ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. EZ4- 720 - 755 - 01 ｲﾄﾞｳ ﾔｼﾞﾙｼ ｼ - ﾙ ( ｼﾖｳ ) SEAL, MOVE ARROW MARK (SMALL) 2 EZ4- 722 - 956 - 01 ﾌﾞﾗﾝｸ …
A1
X
ビームユニット
X beam unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
30 EZ4-459-210-21
ﾛﾂｶｸ
ｼﾁﾕｳ
(M4-10)
SUPPORT (M4-10), HEXAGON
8
31 EZ4-459-210-11
ﾛﾂｶｸ
ｼﾁﾕｳ
(M4-20)
SUPPORT (M4-20), HEXAGON
4
32 EZ4-459-207-03
LED
ﾄﾞﾗｲﾌﾞ
ｷﾊﾞﾝ
ｶﾊﾞ
-
COVER, LED DRIVE PC BOARD
1
33 EZ1-734-191-11
LED MASTERSLAVE
ｼﾕｳｺﾞｳ
ﾊｲｾﾝﾊﾞﾝ
PWB, LED MASTERSLAVE
COMBINED
1
34 EZ1-888-211-11
LED MASTER
ﾊｲｾﾝﾊﾞﾝ
PWB, LED MASTER
1
35 EZ4-452-273-01
Y
ｾﾝｻ- ﾄﾞｸﾞ
(1)
Y SENSOR DOG (1)
1
36 EZ4-452-275-02
X
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ
(2)
BRACKET, X CABLE BARE (2)
1
37 EZ4-452-276-02
ｾﾝｻ
ﾌﾞﾗｹﾂﾄ
SENSOR BRACKET
1
38 EZ4-452-279-03
Y
ｹ-ﾌﾞﾙ ﾍﾞｱ ﾌﾞﾗｹﾂﾄ
Y CABLE BARE BRACKET
1
39 EZ4-452-269-01
X
ｺﾃｲｸﾞ
X RETAINER
1
40 EZ4-452-264-02
ｽｹ-ﾙ ﾌﾞﾗｹﾂﾄ
(X)
SCALE BRACKET (X)
1
EZ3-278-403-11
ｺﾞｸﾃｲﾄｳﾛﾂｶｸｱﾅﾂｷﾎﾞﾙﾄ
(CBSTS4-6)
BOLT, HEXAGON SOCKET (CBSTS4-
6
4
EZ4-456-435-11
ｸﾐｺﾐ
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(CBST3-12)
BOLT (CBST3-12), HEXAGON HOLE
4
EZ4-700-040-31
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M5X15)
BOLT (M5X15), HEXAGON SOCKET
28
EZ4-700-042-41
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
(M4X15)
BOLT (M4X15), HEXAGON SOCKET
24
EZ4-701-097-01
ﾛﾂｶｸ
ｱﾅﾂｷ
ﾎﾞﾙﾄ
M4X45
BOLT (M4X45), HEXAGON SOCKET
2
EZ7-683-403-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
3X6
BOLT,HEXAGON SOCKET 3X6
8
EZ7-683-418-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X6
BOLT,HEXAGON SOCKET 4X6
11
EZ7-683-419-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X8
BOLT,HEXAGON SOCKET 4X8
5
EZ7-683-420-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X10
BOLT,HEXAGON SOCKET 4X10
4
EZ7-683-421-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X12
BOLT,HEXAGON SOCKET 4X12
18
EZ7-683-428-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
4X40
BOLT, HEXAGON SOCKET 4X40
2
EZ7-683-434-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X8
BOLT,HEXAGON SOCKET 5X8
12
EZ7-683-435-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
5X10
BOLT,HEXAGON SOCKET 5X10
4
EZ7-683-447-04
6
ｶｸｱﾅﾂｷ
ﾎﾞﾙﾄ
5X50
BOLT,HEXAGON SOCKET 5X50
2
EZ7-683-459-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X25
BOLT,HEXAGON SOCKET 6X25
2
EZ7-683-465-04
6
ｶｸｱﾅﾂｷﾎﾞﾙﾄ
6X40
BOLT,HEXAGON SOCKET 6X40
6
EZ4-452-347-01
ｼﾘｱﾙ
NO.
ﾗﾍﾞﾙ
(
ﾑｼﾞ
) (1446)
LABEL (PLAIN),SERIAL NO.(1446)
1
EZ4-455-994-01
ｹｲｺｸ
ﾗﾍﾞﾙ
(
ｹｶﾞ
ﾌｸｺﾞｳ
)
LABEL (HURT), WARNING
2
A-6
A1
X
ビームユニット
X beam unit
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
EZ4-720-755-01
ｲﾄﾞｳ ﾔｼﾞﾙｼ ｼ-ﾙ
(
ｼﾖｳ
)
SEAL, MOVE ARROW MARK
(SMALL)
2
EZ4-722-956-01
ﾌﾞﾗﾝｸ
ﾗﾍﾞﾙ
ｷﾞﾝ
(TTC82YS-10)
LABEL (SILVER), BLANK
7
