B17 I/O 配線図 1 W iring diagra m I/O 1 ｲﾗｽﾄ番 号 Ref.No. 部品コード Parts Code 部品名 Parts Name Serial No. 個数 Q'ty 備考 Remarks 同期 Repl. 1 EZ1- 969 - 205 - 13 ﾊ - ﾈｽ (AD1, ｾﾝｻ - ｼﾝｺﾞｳ ) HARNESS 1 2 EZ1- 969 - 205 - 23 ﾊ - ﾈｽ (AD…
B17
I/O
配線図
1
Wiring diagram I/O 1
B-35
B17
I/O
配線図
1
Wiring diagram I/O 1
ｲﾗｽﾄ番号
Ref.No.
部品コード
Parts Code
部品名
Parts Name
Serial
No.
個数
Q'ty
備考
Remarks
同期
Repl.
1 EZ1-969-205-13
ﾊ-ﾈｽ
(AD1,
ｾﾝｻ- ｼﾝｺﾞｳ
)
HARNESS
1
2 EZ1-969-205-23
ﾊ-ﾈｽ
(AD2,
ｾﾝｻ- ｼﾝｺﾞｳ
)
HARNESS
1
3 EZ1-969-205-33
ﾊ-ﾈｽ
(AD3,
ｾﾝｻ- ｼﾝｺﾞｳ
)
HARNESS
1
4 EZ1-969-310-12
ﾊ-ﾈｽ
(LS
ｷﾊﾞﾝ
ﾁﾕｳｹｲ
)
HARNESS
1
5 EZ1-492-175-21
ｾﾝｻ-
ASSY (AD1
ｼﾞｸ
CCW)
ASSY, SENSOR
1
6 EZ1-492-178-11
ｾﾝｻ
-
ASSY (AD1
ｼﾞｸ
ORG)
ASSY, SENSOR
1
7 EZ1-492-178-21
ｾﾝｻ-
ASSY (AD2
ｼﾞｸ
ORG)
ASSY, SENSOR
1
8 EZ1-492-175-11
ｾﾝｻ
-
ASSY (AD3
ｼﾞｸ
CW)
ASSY, SENSOR
1
9 EZ1-492-178-31
ｾﾝｻ-
ASSY (AD3
ｼﾞｸ
ORG)
ASSY, SENSOR
1
10 EZ1-969-226-12
ﾊ-ﾈｽ
(
ﾚ-ﾝ
1,
ｾﾝｻ- ﾁﾕｳｹｲ
)
HARNESS
1
11 EZ1-492-192-32
ｾﾝｻ-
ASSY (
ｷﾊﾞﾝ
ﾐｷﾞ
F, I17)
ASSY, SENSOR
1
12 EZ1-492-192-42
ｾﾝｻ-
ASSY (
ｷﾊﾞﾝ
ﾋﾀﾞﾘ
F, I18)
ASSY, SENSOR
1
13 EZ1-492-527-11
SENSORASSY
(SUBSTRATEDECELER*)
SENSORASSY
(SUBSTRATEDECELER*)
1
14 EZ1-492-527-21
SENSOR ASSY
(SUBSTRATEARRIVAL*)
SENSOR ASSY
(SUBSTRATEARRIVAL*)
1
15 EZ1-492-191-11
ｾﾝｻ
-
ASSY (
ｽﾄﾂﾊﾟ
, I21)
ASSY, SENSOR
1
16 EZ1-492-191-21
ｾﾝｻ-
ASSY (
ｽﾄﾂﾊﾟ
, I22)
ASSY, SENSOR
1
17 EZ1-492-190-12
ｾﾝｻ-
ASSY (
ｸﾗﾝﾌﾟ
, I23)
ASSY, SENSOR
1
18 EZ1-969-220-13
ﾊ-ﾈｽ
(
ﾚ-ﾝ
2,
ｾﾝｻ- ﾁﾕｳｹｲ
)
HARNESS
1
19 EZ1-969-219-12
ﾊ-ﾈｽ
(
ﾚ
-
ﾝ
2,
ｾﾝｻ- ｶﾄﾞｳ ﾁﾕｳｹｲ
)
HARNESS
1
20 EZ1-492-176-11
ｾﾝｻ
-
ASSY (
ｲﾌﾞﾂ
ｹﾝｼﾕﾂ
1)
ASSY, SENSOR
2
22 EZ1-492-180-12
ｾﾝｻ-
ASSY (
ｸﾗﾝﾌﾟ
, I24)
ASSY, SENSOR
1
23 EZ1-492-194-12
ｾﾝｻ-
ASSY (AD1
ｼﾞｸ
CW)
ASSY, SENSOR
1
B-36
B18
I/O
配線図
2
Wiring diagram I/O 2
B-37
