1Introduction
This manual describes maintenance tasks for the SIPLACE® WPC4, WPC5 and WPC6 modules.
Safety Instruc tions
1.1 Safety Instructions
Conventions for the Use o f Safety Instr uctions
1.1.1 Conventions for the Use of Safety Instructions
This manual contains notes that must be observed to guarantee your personal safety and to avoid
damage to equipment. These notes are highlighted by warning triangles and are indicated as follows
according to the level of risk:
DANGER
Nonobservance of these safety instructions may cause injury to personnel and damage to the
machine!
► Please observe the safety instructions in the user manual of the relevant machine for all
work!
DANGER
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or considerable
damage to property will occur if this hazard warning is not observed.
WARNING
Definition
For the purposes of this manual, this indicates that fatal or severe injuries or considerable
damage to equipment may occur if these warning instructions are not followed.
CAUTION
Definition
For the purposes of this manual, this indicates that minor injuries or damage to property may
occur if this caution is not observed.
NOTICE
Definition
For the purposes of this manual, this note provides information about the product or indicates
a part of the manual that requires particular attention.
Introduction
Safety Instructions Safety Instructions for the Power Supply
6 Maintenance Manual SIPLACE WPC4, WPC5 and WPC6
Safety Instruc tions for th e Power Supply
1.1.2 Safety Instructions for the Power Supply
▪ This means that some parts of the system carry potentially lethal voltages - even when switched off
at the main power switch.
▪ Incorrect handling of the placement system can therefore result in fatal injuries, severe injuries or
considerable damage to equipment.
▪ Measurements and maintenance work must always be carried out by appropriately qualified
personnel.
▪ Always follow the applicable accident prevention and DIN regulations (particularly DIN EN 60 204,
part 1) or the regulations specific to your country.
▪ Before starting any maintenance work, switch off at the main switch and disconnect the machine
from the main power supply.
▪ Always secure the machine against unauthorized reactivation. If these instructions are not followed,
you may be able to touch live parts, which could result in fatal or severe injuries.
Maintaining or replacing assemblies
► End all placement operations on the machine.
► Shut down the Windows operating system correctly, otherwise problems may occur when restarting
or data may be lost.
► Switch the machine off at the main switch.
► Disconnect the machine from the main power supply.
► Switch off the machine and attach warnings signs to indicate that service work is in progress.
Safety Instruc tions for Main tenance Task s
1.1.3 Safety Instructions for Maintenance Tasks
WARNING
Hazardous Voltages!
The machine is supplied with 3 x 400 V~ (or 3 x 204 V~ / 3 x 230 V~ / 3 x 380 V~ / 3 x 415 V~)
± 5 %, 50/60 Hz mains voltage.
► Observe the safety instructions in the user manual during all service work!
WARNING
Danger of burning
► Never use alcohol for cleaning purposes when working in the vicinity of a naked flame or
fire.
► Never spray lubricants or cleaning agents from aerosol cans in the vicinity of a naked flame
or fire.
CAUTION
Ethanol
► Always wear safety goggles and gloves when using concentrated ethanol to clean modules.
► If ethanol should accidentally get into your eyes, rinse your eyes immediately with water.
Introduction
Safety Instructions for Maintenance Tasks Safety Instructions
Maintenance Manual SIPLACE WPC4, WPC5 and WPC6 7
CAUTION! SIPLACE cleaning tissue
Harmful: may cause lung damage if swallowed.
Do not inhale vapor / aerosol.
Avoid contact with the skin. If swallowed, do not induce
vomiting. See medical attention immediately and show
the packaging or label.
Wear latex gloves while using the cleaning tissue.
CAUTION
Consumable materials
Observe the safety data sheets for consumable materials!
CAUTION
Cleaning and lubrication
► Always use ethanol for cleaning – do not use solvents.
► NEVER use compressed air to clean units inside the placement machine or modules.
CAUTION
Danger of cutting on the IC and FC camera
There is a risk of cutting your fingers along the edges of the mirror.
► Wear laboratory gloves as protection and avoid touching the edges.
► The laboratory gloves are also required for effective cleaning (fingerprints!).
CAUTION
Only one person must be present at each component preparation station at any given time.
This is to ensure the safety of the operator and the safety of the second person. Pulling in the
component trolley is a two-handed operation, so only one person can be reliably protected from
the possible risks.
