Find us at www.keysight.com Page 13
External Functional Test Instruments
Functional Test Access port
Parameter
Specification
Characteristic Impedance
50 (typical)
Minimum DC Insulation Resistance
1 M
Maximum Voltage
±100 V peak (port to system ground)
Maximum Current
±500 mA peak per port
Maximum Power
7.5 VA per port
Minimum DC Insulation Resistance
10 M
Total Capacitance
< 900 pF port to ground
3 dB Bandwidth
12 MHz (typical) to and from any HybridPlus-DD pin
Crosstalk at 1 MHz
< −45 dB (50 source and load)
* External instruments can trigger frequency, pulse width, and time interval measurements.
Digital In-circuit Test and Functional Test
Edge Placement Accuracy
Parameter
Specification
Mux Systems
(1)
EPA Internally Referenced
±5 ns typical, ±10 ns warranted
EPA Externally Referenced
±7 ns typical, ±15 ns warranted
UnMux Systems
(2)
EPA Internally Referenced
±15 ns typical, ±20 ns warranted
EPA Externally Referenced
±17 ns typical, ±24 ns warranted
1. Drivers are programmed for 0.2–3.5 V and a 225 V/µs slew rate into 100 non high impedance state and measured at 1.5 V. Receivers are programmed to 1.5 V,
325 kHz DUT 20 MHz. Input signals to tester must have a slew rate 225 V/µs.
2. Drivers are programmed to 3.5 V into 100 non high impedance state and measured at 1.5 V. Receivers are programmed to 1.5 V, 325 kHz DUT 20 MHz. Input
signals to tester must have a slew rate 225 V/µs.
Pattern Rate
Parameter
Specification
Mux Systems (1)
Minimum Pattern Rate
330/sec
Maximum Pattern Rate
6.25 M/sec, 12.5 M/sec, or 20 M/sec
UnMux Systems (2)
Minimum Pattern Rate
330/sec
Maximum Pattern Rate
6.25 M/sec
1. Drivers are programmed for 0.2–3.5 V and a 225 V/µs slew rate into 100 non high impedance state and measured at 1.5 V. Receivers are programmed to 1.5 V,
325 kHz DUT clock of 20 MHz. Input signals to tester must have a slew rate of 225 V/µs.
2. Drivers have fixed rise and fall times of approximately 15 ns.
Guide Probe
Parameter
Specification
Programmable Receiver
Voltage Range
Low Threshold
−
3.5 to 5.0 V
High Threshold
−
3.5 to 5.0 V
Programming Resolution
5.25 mV
Accuracy
±150 mV
Maximum Input Voltage
±12 V
Bandwidth (using ground clip)
50 MHz
Input Resistance
20 k
Input Capacitance
10 pF
P
a
g
e
Find us at www.keysight.com Page 14
Additional Digital Specifications
Module Control Card
High-speed Clocks and Clock Receivers
TTL Compatible Input and Output
Parameter
Specification
Number of Clock Drivers/Control Card
1
Clock Driver Multiplex Ratio
2:1
Clock Driver Frequency Range
Minimum
625 kHz
Maximum
50 MHz
Resolution
1
± 1% of frequency
Number of Clock Receivers/Control Card
2
Clock Receiver Frequency
Minimum
160 kHz
Maximum
80 MHz
1. Add ± 1 ns for periods over 100 ns.
Even Triggers
Parameter
Specification
Number of Triggers/ Control Card
3
Trigger Multiplex Ratio
2:1
Start-up Delay
550 ns (11 events)
Number of Triggers/ Control Card
3
Minimum Pattern Rate
330/sec
Capture Ram
Parameter
Specification
Serial Capture RAM depth
1,048,576 (1 Mb)
General-Purpose Relays
Parameter
Specification
Number of General-Purpose Relays/Control Card
8
Maximum Voltage to Earth
±100 V peak
Maximum Switching Voltage
100 V peak
Maximum Switching Power
30 W
Maximum Switching Current
750 mA
Maximum Carry Current
750 mA
General-Purpose Relay Resistance
60 m
Switching Time (typical)
50 ms
Debug Ports
Output Voltage: TTL levels
Parameter
Specification*
Clock Port
Sequencer or event clock
Data Port
Buffered data from a receiver
Synchronization Port
Sync pulses added in digital test debug
* Systematic delay is typically 100–200 ns
P
a
g
e
Find us at www.keysight.com Page 15
Pin Cards and Test Access
Pin Cards for UnMux Systems
Maximum Number of Resources
1-Module
2-Module
4-Module
Pins / Nodes
1,296
2,592
5,184
Drive Channels
1,296
2,592
5,184
Receive Channels
1,296
2,592
5,184
Hybrid-144 pin Card*
9
18
36
Utility Card*
1
2
4
* Maximum number of cards per module = 9.
Hybrid-144 non-multiplex pin card
Parameter
Specification
Number of Pins/Card
144
Number of Channels/Card
144
Number of Drive Channels/Card
144
Number of Receive Channels/Card
144
Number of Grounds/Card
156
Multiplexing Ratio
1:1
Overdrive Capability
Yes
nanoVTEP Technology Capability
Yes
Hybrid-144 Non-multiplexed Pin Card Receivers
Parameter
Specification
Programmable Receive Delay Time
Minimum
0 ns
Maximum
Programmed vector cycle time
Resolution
2 ns (typical)
Accuracy (same card)
±8 ns typical, ±11 ns warranted
Input Voltage Range
0–4.875 V
Input Bias Current
+150 µA maximum
1
Parallel Capture RAM
128 bits
Response Compression
IEEE CRC-32 polynomial
2
Receiver Threshold Voltage
Range
0–4.875 V
Programming Resolution
20 mV (typical)
Static Accuracy
± 2% of setting ± 100 mV (typical)
Termination
Pull-Up Resistor
1000
Pull-Down Resistor
383
AC
150 pF, 68.1 in series
1. Varies with voltage.
2. Polynomial is 1 + x
2
+ x
4
+ x
5
+ x
7
+ x
8
+ x
10
+ x
11
+ x
12
+ x
16
+ x
22
+ x
23
+ x
26
+ x
32
Hybrid-144 Non-multiplexed Pin Card Drivers
Parameter
Specification
Frequency Range as a Clock
Minimum
625 kHz
Maximum
10 MHz
Programming Resolution
1
1% of frequency
Programmable Vector Cycle Time
Minimum
160 ns
Maximum
1.5 ms
Resolution
1
1% of vector cycle
Programming Resolution
1 ns
