System Specification
Device Under Test (DUT) Power Supplies
DUT Supply Source
Output Ratings
N6751A Modular Power Supply
0-50 V, 0-5 A, 50 W
N6752A Modular Power Supply
0-50 V, 0-10 A, 100 W
N6773A Modular Power Supply
0-20 V, 0-15 A, 300 W
N6746B Modular Power Supply
0-100 V, 0-1 A, 100 W
N5747 Power Supply
0 to 50 V, 0 to 10 A, 500W
Input Voltage and Current
Power Option Matrix
Power Option
Voltage line-to-neutral
Full-Load Amps (FLA) for:
4-Module
2-Module
1-Module
3PD
200
24
18
13
220
24
18
13
230
24
18
13
240
24
18
13
3PY
208
24
18
13
220
24
18
13
3PN
220/380
16
10
9
230/400
16
10
9
240/415
16
10
9
Three-Phase Delta* Three-Phase Wye* Three-Phase Wye with Neutral
* Neutral is not used by the systems for power options 3PD and 3PY. Neutral is shown in the diagrams because it is cabled into the PDU.
Environmental Requirements
Operating Temperature
Operating Humidity
Storage Temperature
Testhead
0°C to 40°C (32°F to 104°F)
5 to 80 % non-condensing
−
40°C to 70°C (
−
40°F to 158°F)
Controller
5°C to 45°C (41°F to 113°F)
20 to 80 % non-condensing
−
40°C to 65°C (
−
40°F to 149°F)
* Testhead over-temperature shutdown is typically at 55°C. Auto-adjust will occur automatically for ±5°C changes in temperature.
Dimensions and Weights
Width
Depth
Height
Weight
Four-Module System (E9903G)
Testhead
1490 mm
(58.66 in)
935 mm
(36.81 in)
887 mm
(34.92 in)
523 kg
(1153 lb)
Packaged for shipment
2134 mm
(84.02 in)
1219 mm
(47.99 in)
1377 mm
(54.21 in)
776 kg
(1710 lb)
P
a
g
e
Find us at www.keysight.com Page 20
Two-Module System (E9902G)
Testhead
1490 mm
(58.66 in)
935 mm
(36.81 in)
887 mm
(34.92 in)
425 kg
(937 lb)
Packaged for shipment
2134 mm
(84.02 in)
1219 mm
(47.99 in)
1377 mm
(54.21 in)
678 kg
(1495 lb)
Two-Module System (E9905G)
Testhead
954 mm
(37.56 in)
935 mm
(36.81 in)
887 mm
(34.92 in)
386 kg
(851 lb)
Packaged for shipment
1555 mm
(61.22 in)
1219 mm
(47.99 in)
1377 mm
(54.21 in)
561 kg
(1237 lb)
Vacuum and Compressed Air
DUT Supply Source
Output Ratings
Number of Vacuum Ports/Module
2 ports for 1- and 2-module systems
4 ports for 4-module systems
Vacuum Connector Diameter
2.54 cm (1 in) male
Compressed Air Connector
Parker 20 or 30 series 0.25 inch coupler
Vacuum Value Control Voltage
24 VDC at 1 A maximum
Minimum Free Air Displacement (Vacuum)
68 m
3
/hr (40 SCFM)
Minimum Compressed Air Pressure
4.9 kg/cm
2
(70 psi) non-lubricated
Maximum Compressed Air Pressure
10.6 kg/cm
2
(150 psi) non-lubricated
Fixture Specification
Fixture Kit
Maximum
PC Board Size
Maximum Probable
Area
Approximate Storage
Dimensions L x W x H
Kit Weight
Long Wire Fixture
Standard
450 x 396 mm
17.7 x 15.6 in
389 x 364 mm
15.3 x 14.3 in
457 x 401 x 147 mm
18.0 x 18.5 x 5.8 in
10.5 kg
23.1 lb
Large
450 x 757 mm
17.7 x 29.8 in
389 x 726 mm
15.3 x 28.6 in
457 x 775 x 147 mm
18.0 x 30.5 x 5.8 in
19 kg
41.8 lb
Short Wire Fixture
Standard
450 x 396 mm
17.7 x 15.6 in
414 x 374 mm
16.3 x 14.7 in
457 x 452 x 83 mm
18.0 x 17.8 x 3.25 in
10.7 kg
23.5 lb
Large
450 x 757 mm
17.7 x 29.8 in
414 x 735 mm
16.3 x 28.9 in
457 x 813 x 83 mm
18.0 x 32.0 x 3.25 in
18.6 kg
41.0 lb
P
a
g
e
Find us at www.keysight.com Page 21
