Cover Ass' y NO. PART NO. PART NAME Q'TY TYPE REMARK 27 J7052302D BKT-LEFT COVER 2 J7052302D 28 J7052303D BKT-RIGHT COVER 2 J7052303D 29 J7052304C BRACKET INNER U'COVER 2 J7052304C 30 J7052032B BRACKET UPP…
Cover Ass'
y
NO. PART NO. PART NAME Q'TY TYPE REMARK
1
J7052281D COVER-L.F.U 1 J7052281D
2
J7052365C COVER-L.M.M 1 J7052365C
3
J7052282D COVER-L.R.U 1 J7052282D
4
J7052286D COVER-M.M.U 1 J7052286D
5
J7052280F COVER-R.F.U 1 J7052280F
6
J7052289C COVER-R.M.M 1 J7052289C
7
J7052283D COVER-R.R.U 1 J7052283D
8
J7052288C COVER-SIDE.M.U.L 1 J7052288C
9
J7052287C COVER-SIDE.M.U.R 1 J7052287C
10
J7052285B MAINT COVER-LEFT 1 J7052285C
11
J7052284B MAINT COVER-RIGHT 1 J7052284C
12
J7052294B MID COVER-INNER(LH) 1 J7052294B
13
J7052293C MID COVER-INNER(RH) 1 J7052293C
14
J7052247B SUPPORT DOOR CATCH 4 J7052247B
15
J7052292B UPPER COVER-INNER(LH) 1 J7052292B
16
J7052291B UPPER COVER-INNER(RH) 1 J7052291B
17
J7052306D DOOR-LOWER(REAR) 1 J7052306D
18
J7052582A DOOR-LOWER(FRONT) 1 J7052582A
J7052306D DOOR-LOWER(FRONT) 1 J7052306D
CE OPTION
19
J7052308E COVER-R/M LOWER 1 J7052308E
20
J7052309D COVER-L/M LOWER 1 J7052309D
21
J7052310B COVER-B/L/L 1 J7052310B
22
J7052311B COVER-B/L/R 1 J7052311B
23
J7052312E COVER-R/F/L 1 J7052312E
24
J7052313F COVER-L/F/L 1 J7052313F
D/C,REAR SID CONTROL(J7052995A)
25
J7052314E COVER-R/R/L 1 J7052314E
26
J7052315D COVER-L/R/L 1 J7052315D
- 7 -
Cover Ass'
y
NO. PART NO. PART NAME Q'TY TYPE REMARK
27
J7052302D BKT-LEFT COVER 2 J7052302D
28
J7052303D BKT-RIGHT COVER 2 J7052303D
29
J7052304C BRACKET INNER U'COVER 2 J7052304C
30
J7052032B BRACKET UPPER COVER 4 J7052032B
31
J7052298B BRACKET UPPER COVER 1 1 J7052298B
32 J7052299B
BRACKET UPPER COVER 2 1
J7052299B
33 J7052300B
BRACKET UPPER COVER 3 1
J7052300B
34
J7052301B BRACKET UPPER COVER 4 1 J7052301B
35 J2100033
CATCH PLATE 4
J2100033
36
J7052374F CONNECTOR BKT 1 J7052374F
37
J7252029A CONNECTOR ISOLATOR 1 1 J7252029A
38 J2100032
HINGES PLATE 8
J2100032
39 J7052604C
STAYS PLATE 4
J7052604C
40
J7052295B WINDOW-FRONT 1 J7052295B
41
J7052296B WINDOW-REAR 1 J7052296B
J7252040C ACRYL COVER-REAR 1 J7252040C
CE OPTION
42 J1300101
DRAWER PULL 4 HD-108
43 J1300497
SHOULDER BOLT 4 MSB6.5-10
44 J1300638
HINGE 6 FTH7650H(IMAO)
45 J1300640
STAYS 2 B-40-1-L(TAKIGEN)
46 J1300641
STAYS 2 B-20-1-R(TAKIGEN)
47 J1300642
CATCHE 4 SM111(SHIMONISH)
48
J7052326B CHIP COVER-FRONT1 1 J7052326B
49
J7052327B CHIP COVER-FRONT2 1 J7052327B
50
J7052328C CHIP COVER-FRONT3 1 J7052328C
51 J7057151A
CHIP COVER-REAR 1
J7057151A
52 J7052474A
CHIP COVER-SIDE 1 1
J7052474A
- 8 -
Cover Ass'
y
NO. PART NO. PART NAME Q'TY TYPE REMARK
53 J7052475A
CHIP COVER-SIDE 2 1
J7052475A
54
J7252011C MULTI STICK COVER 4 J7252011C
CE OPTION
55 J2101708
HINGE NUT 2 0133-615009
CE OPTION
56 J2101714
STOPPER, COVER 2 0133-615015
CE OPTION
57 J1301639
HINGE 2 E6-10-301-10
CE OPTION
58
J7052108A M/S COVER BKT 4 J7052108A
CE OPTION
59
J7252045C CE LOWER WINDOW-STICK 1 J7252045C
CE OPTION
60
J7052257B DOOR STOPPER 2 J7052257B
CE OPTION
61
J7252039B CE TRAY COVER
1
J7252039B
CE OPTION
62
J7052536A CE SENSOR BRACKET 2 J7052536A
CE OPTION
63
J7052537C ACRYL SUPPORT PLATE 2 J7052537C
CE OPTION
64
J7152060B CE-AL COVER 1 1 J7152060B
CE OPTION
65
J7052596B TRAY COVER BRACKET 2 J7052596B
CE OPTION
66
J7152061B CE-AL COVER 2
1
J7152061B
CE OPTION
67 J1301640
DOOR SWITCH
2
D4DS-2AFS
CE OPTION
68 J1301641
DOOR KEY 2 D4DS-K3
CE OPTION
69
J7052535C WINDOW PLATE-REAR 2 J7052535C
CE OPTION
70
71
72
73
74
75
76
77
78
79
80
81
82
- 9 -
