The Connection Between CAN Master Board and I/F Boards - 93 - CAN MASTER BOARD CN1 FRONT FEEDER I/F BOARD HEAD ILL. I/F BOARD HEAD I/F BOARD X SUB I/F BOARD Y SUB I/F BOARD REAR FEEDER I/F BOARD STAGE ILL I/F BOARD CONVE…
- 92 -
PC BUS
(MMI)
CPU(PENTIUM)
VGA I/F
HDD I/F
FDD I/F
COMM. PORT
PRINTER PORT
PC ISA I/F B/D
PC VME COMMUNICATION
VME BUS
CPU(68040)
FIDUCIAL CAMERA
STAGE CAMERA
FLYING CAMERA
X DRV
X DRV
X DRV
X DRV
Z1 DRV
Z2 DRV
R1/2 DRV
CV. DRV
Z3 DRV
Z4 DRV
R3/4 DRV
X DRV
X DRV
X DRV
VISION
XY AXIS
H1/2 AXIS
H3/4 AXIS
H5/6 AXIS
CAN MASTER
Electric Control Diagram
The Connection Between CAN Master Board and I/F Boards
- 93 -
CAN MASTER BOARD
CN1
FRONT FEEDER
I/F BOARD
HEAD ILL.
I/F BOARD
HEAD
I/F BOARD
X SUB I/F
BOARD
Y SUB I/F
BOARD
REAR FEEDER
I/F BOARD
STAGE ILL
I/F BOARD
CONVEYOR I/F
BOARD
AXIS Z1/2 Board
AXIS Z3/4 Board
AXIS Z5/6 Board
CN3
CN3
CN2
CN3
CN2
CN14
CN14
CN8 CN7 CN6 CN5
CN3
CN4
CN2
CAN
CAN
CAN
CAN
ISA
CAN
CAN
HOME SENSOR SIGNAL
HOME SENSOR SIGNAL
CN3
CN4
CN3
CN2
CN3
CN2
CN3
AXIS XY Board
CN3
CN3
CN3
VME PC
COMMUNICATION
PC ISA
I/F BOARD
PC Mother Board Interface
NO. PART NO. PART NAME Q'TY TYPE REMARK
1
J9061173B INLINE IN/OUT CABLE ASS'Y MK-CV07
2
J9061330A PRINT PORT CABLE ASS'Y MK-PC01
3
J9061334A TRAY FEEDER CABLE ASS'Y MK-VM01
4
J9061335A TRAY FEEDER CABLE ASS'Y MK-VM02
5
J9061336A TRAY FEEDER CABLE ASS'Y MK-VM03
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
