FASTECH Ezi-SERVO ST
109
高转矩高速度
与普通的步进电机和驱动器相比， Ezi-SERVO 运动控制系
统可以在相当长的时间内保持高扭矩状态。
这意味着 Ezi-SERVO 在100％的负载下连续运行而不会丢失
位置。与传统的微步进驱动器不同，Ezi-SERVO 由于其创新
的最佳电流相位控制，在高速运动期间也能持续的高转矩运
行。
Ezi-SERVO 在高速运行时不会失去同步或定位误差。
Ezi-SERVO 的连续电流位置监控功能使步进电机即使
在100％负载条件下也能产生高扭矩。
优于开环控制步进驱动器
优于伺服电机控制器
5
1. 可靠的定位，而不会失去同步性。
2. 可稳定维持位置，即便遭到外力影响 (如机械震动或垂直定位运动) 造成位置误差也能够自动返回目标位置。
3. Ezi-SERVO采用100%额定转矩来驱动电机，而传统开回路步进电机为避免失步问题，通常只会用50%额定
4. Ezi-SERVO采用与负载相关的电流控制，能在高速(最高可达3000rpm)下运行，而传统开回路步进驱动器在
所有速度范围内都使用恒定电流控制，不会考虑负载变化。
转矩来驱动电机。
1. 没有增益调整。 （根据负载变化自动调整增益）
2. 定位完成后，保持稳定的保持位置，不振荡。
3. 板载MCU独立控制，可实现快速定位。
4. 由于是瞬时定位，所以在快速短行程运动中可连续运行。
武汉星之雨科技有限公司
www.whxzy-tech.com
6
FASTECH Ezi-SERVO ST
Ezi-SERVO-ST-56L-A-BK-PN05-□
20 : 20mm
28 : 28mm
35 : 35mm
42 : 42mm
56 : 56mm
60 : 60mm
86 : 86mm
S ：Small
M ：Medium
L ：Large
XL：Extra Large
A：10,000[ppr]
B：20,000[ppr]
C：32,000[ppr]
D：16,000[ppr]
F ：4,000[ppr]
PN03- 1:3
PN05- 1:5
PN08 - 1:8
PN10- 1:10
PN15- 1:15
PN25- 1:25
PN40- 1:40
PN50- 1:50
ST : Stand Alone
● Ezi-SERVO ST 型号编码
● 标准组合
＊
Ezi-SERVO-ST-20M-FEzM-20M-FEzS-PD-20M-F
Ezi-SERVO-ST-20L-FEzM-20L-FEzS-PD-20L-F
Ezi-SERVO-ST-28S-DEzM-28S-DEzS-PD-28S-D
Ezi-SERVO-ST-28SM-DEzM-28SM-DEzS-PD-28S-D
Ezi-SERVO-ST-28M-DEzM-28M-DEzS-PD-28M-D
Ezi-SERVO-ST-28MM-DEzM-28MM-DEzS-PD-28M-D
Ezi-SERVO-ST-28L-DEzM-28L-DEzS-PD-28L-D
Ezi-SERVO-ST-28LM-DEzM-28LM-DEzS-PD-28L-D
Ezi-SERVO-ST-35M-DEzM-35M-DEzS-PD-35M-D
Ezi-SERVO-ST-35MM-DEzM-35MM-DEzS-PD-35M-D
Ezi-SERVO-ST-35L-DEzM-35L-DEzS-PD-35L-D
Ezi-SERVO-ST-35LM-DEzM-35LM-DEzS-PD-35L-D
Ezi-SERVO-ST-42S-AEzM-42S-AEzS-PD-42S-A
Ezi-SERVO-ST-42S-BEzM-42S-BEz
S-PD-42S-B
Ezi-SERVO-ST-42S-CEzM-42S-CEzS-PD-42S-C
Ezi-SERVO-ST-42M-AEzM-42M-AEzS-PD-42M-A
Ezi-SERVO-ST-42M-BEzM-42M-BEzS-PD-42M-B
Ezi-SERVO-ST-42M-CEzM-42M-CEzS-PD-42M-C
Ezi-SERVO-ST-42L-AEzM-42L-AEzS-PD-42L-A
Ezi-SERVO-ST-42L-BEzM-42L-BEzS-PD-42L-B
Ezi-SERVO-ST-42L-CEzM-42L-CEzS-PD-42L-C
Ezi-SERVO-ST-42XL-AEzM-42XL-AEzS-PD-42XL-A
Ezi-SERVO-ST-42XL-BEzM-42XL-BEzS-PD-42XL-B
Ezi-SERVO-ST-42XL-CEzM-42XL-CEzS-PD-42XL-C
Ezi-SERVO-ST-56S-AEzM-56S-AEzS-PD-56S-A
Ezi-SERVO-ST-56S-BEzM-56S-BEzS-PD-56S-B
Ezi-SERVO-ST-56S-CEzM-56S-CEzS-PD-56S-C
Ezi-SERVO-ST-56M-AEzM-56M-AEzS-PD-56M-A
Ezi-SERVO-ST
-56M-BEzM-56M-BEzS-PD-56M-B
Ezi-SERVO-ST-56M-CEzM-56M-CEzS-PD-56M-C
Ezi-SERVO-ST-56L-AEzM-56L-AEzS-PD-56L-A
Ezi-SERVO-ST-56L-BEzM-56L-BEzS-PD-56L-B
Ezi-SERVO-ST-56L-CEzM-56L-CEzS-PD-56L-C
Ezi-SERVO-ST-60S-AEzM-60S-AEzS-PD-60S-A
Ezi-SERVO-ST-60S-BEzM-60S-BEzS-PD-60S-B
Ezi-SERVO-ST-60S-CEzM-60S-CEzS-PD-60S-C
Ezi-SERVO-ST-60M-AEzM-60M-AEzS-PD-60M-A
Ezi-SERVO-ST-60M-BEzM-60M-BEzS-PD-60M-B
Ezi-SERVO-ST-60M-CEzM-60M-CEzS-PD-60M-C
Ezi-SERVO-ST-60L-AEzM-60L-AEzS-PD-60L-A
Ezi-SERVO-ST-60L-BEzM-60L-BEzS-PD-60L-B
Ezi-SERVO-ST-60L-CEzM-60L-CEzS-PD-60L-C
Ezi-SERVO-ST-86M-AEz
M-86M-AEzS-PD-86M-A
Ezi-SERVO-ST-86M-BEzM-86M-BEzS-PD-86M-B
Ezi-SERVO-ST-86M-CEzM-86M-CEzS-PD-86M-C
Ezi-SERVO-ST-86L-AEzM-86L-AEzS-PD-86L-A
Ezi-SERVO-ST-86L-BEzM-86L-BEzS-PD-86L-B
Ezi-SERVO-ST-86L-CEzM-86L-CEzS-PD-86L-C
Ezi-SERVO-ST-86XL-AEzM-86XL-AEzS-PD-86XL-A
Ezi-SERVO-ST-86XL-BEzM-86XL-BEzS-PD-86XL-B
Ezi-SERVO-ST-86XL-CEzM-86XL-CEzS-PD-86XL-C
产品名称
驱动系列类型
电机法兰尺寸
电机长度
编码器分辨率
刹车
减速比
用户代码
空白 : 不带减速机
空白 : 不带刹车
BK : 刹车
整套型号电机型号驱动器型号
当订购Stopper 型28mm,35mm电机时，请在单元部件型号的
电机长度后再加”M”。
(例如：Ezi-SERVO-ST-28LM-D,Ezi-SERVO-ST-35LM-D)
武汉星之雨科技有限公司
www.whxzy-tech.com
7
FASTECH Ezi-SERVO ST
Ezi-SERVO-ST-42S-A-BKEzM-42S-A-BKEzS-PD-42S-A
Ezi-SERVO-ST-42S-B-BKEzM-42S-B-BK EzS-PD-42S-B
Ezi-SERVO-ST-42M-A-BKEzM-42M-A-BKEzS-PD-42M-A
Ezi-SERVO-ST-42M-B-BKEzM-42M-B-BKEzS-PD-42M-B
Ezi-SERVO-ST-42L-A-BKEzM-42L-A-BKEzS-PD-42L-A
Ezi-SERVO-ST-42L-B-BKEzM-42L-B-BKEzS-PD-42L-B
Ezi-SERVO-ST-42XL-A-BK EzM-42XL-A-BKEzS-PD-42XL-A
Ezi-SERVO-ST-42XL-B-BKEzM-42XL-B-BKEzS-PD-42XL-B
Ezi-SERVO-ST-56S-A-BK EzM-56S-A-BKEzS-PD-56S-A
Ezi-SERVO-ST-56S-B-BKEzM-56S-B-BKEzS-PD-56S-B
Ezi-SERVO-ST-56M-A-BKEzM-56M-A-BKEzS-PD-56M-A
Ezi-SERVO-ST-56M-B-BKEzM-56M-B-BKEzS-PD-56M-B
Ezi-SERVO-ST-56L-A-BKEzM-56L-
A-BKEzS-PD-56L-A
Ezi-SERVO-ST-56L-B-BKEzM-56L-B-BKEzS-PD-56L-B
Ezi-SERVO-ST-60S-A-BK EzM-60S-A-BKEzS-PD-60S-A
Ezi-SERVO-ST-60S-B-BK EzM-60S-B-BKEzS-PD-60S-B
Ezi-SERVO-ST-60M-A-BK EzM-60M-A-BKEzS-PD-60M-A
Ezi-SERVO-ST-60M-B-BK EzM-60M-B-BKEzS-PD-60M-B
Ezi-SERVO-ST-60L-A-BK EzM-60L-A-BKEzS-PD-60L-A
Ezi-SERVO-ST-60L-B-BK EzM-60L-B-BKEzS-PD-60L-B
Ezi-SERVO-ST-86M-A-BKEzM-86M-A-BKEzS-PD-86M-A
Ezi-SERVO-ST-86M-B-BKEzM-86M-B-BKEzS-PD-86M-B
Ezi-SERVO-ST-86L-A-BKEzM-86L-A-BKEzS-PD-86L-A
Ezi-SERVO-ST-86L-B-BKEzM-86L-B-BKEzS-PD-86L-B
Ezi-SERVO-ST-86XL-A-BKEzM-86XL-A-BKEzS-PD-86XL-A
Ezi-
SERVO-ST-86XL-B-BKEzM-86XL-B-BKEzS-PD-86XL-B
Ezi-SERVO-ST-42S-A-PN3EzM-42S-A-PN3EzS-PD-42S-A
1:3
Ezi-SERVO-ST-42S-B-PN3EzM-42S-B-PN3
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN5EzM-42S-A-PN5EzS-PD-42S-A
1:5
Ezi-SERVO-ST-42S-B-PN5EzM-42S-B-PN5
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN8EzM-42S-A-PN8EzS-PD-42S-A
1:8
Ezi-SERVO-ST-42S-B-PN8EzM-42S-B-PN8
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN10EzM-42S-A-PN10EzS-PD-42S-A
1:10
Ezi-SERVO-ST-42S-B-PN10EzM-42S-B-PN10
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN15EzM-42S-A-PN15EzS-PD-42S-A
1:15
Ezi-SERVO-ST-42S-B-PN15EzM-42S-B-PN15
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN25EzM-42S-A-PN25EzS-PD-42S-A
1:25
Ezi-SERVO-ST-42S-B-PN25EzM-42S-B-PN25
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN40EzM-42S-A-PN40EzS-PD-42S-A
1:40
Ezi-SERVO-ST-42S-B-PN40EzM-42S-B-PN40
EzS-PD-42S-B
Ezi-SERVO-ST-42S-A-PN50EzM-42S-A-PN50EzS-PD-42S-A
1:50
Ezi-SERVO-ST-42S-B-PN50EzM-42S-B-PN50
EzS-PD-42S-B
Ezi-SERVO-ST-42M-A-PN3EzM-42M-A-PN3EzS-PD-42M-A
1:3
Ezi-SERVO-ST-42M-B-PN3EzM-42M-B-PN3
EzS-PD-42M-B
Ezi-SERVO-ST-42M-A-PN5EzM-42M-A-PN5EzS-PD-42M-A
1:5
Ezi-SERVO-ST-42M-B-PN5EzM-42M-B-PN5
EzS-PD-42M-B
Ezi-SERVO-ST-42M-A-PN8EzM-42M-A-PN8EzS-PD-42M-A
1:8
Ezi-SERVO-ST-42M-B-PN8EzM-42M-B-PN8
EzS-PD-42M-B
Ezi-SERVO-ST-42M-A-PN10EzM-42M-A-PN10EzS-PD-42M-A
1:10
Ezi-SERVO-ST-42M-B-PN10EzM-42M-B-PN10
EzS-PD-42M-B
Ezi-SER
VO-ST-42M-A-PN15EzM-42M-A-PN15
EzS-PD-42M-A
1:15
Ezi-SERVO-ST-42M-B-PN15EzM-42M-B-PN15
EzS-PD-42M-B
Ezi-SERVO-ST-42M-A-PN25EzM-42M-A-PN25EzS-PD-42M-A
1:25
Ezi-SERVO-ST-42M-B-PN25EzM-42M-B-PN25
EzS-PD-42M-B
Ezi-SERVO-ST-42M-A-PN40EzM-42M-A-PN40EzS-PD-42M-A
1:40
Ezi-SERVO-ST-42M-B-PN40EzM-42M-B-PN40
EzS-PD-42M-B
Ezi-SERVO-ST-42M-A-PN50EzM-42M-A-PN50EzS-PD-42M-A
1:50
Ezi-SERVO-ST-42M-B-PN50EzM-42M-B-PN50
EzS-PD-42M-B
Ezi-SERVO-ST-42L-A-PN3EzM-42L-A-PN3EzS-PD-42L-A
1:3
Ezi-SERVO-ST-42L-B-PN3EzM-42L-B-PN3
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN5EzM-42L-A-PN5EzS-PD-42L-A
1:5
Ezi-SERVO-ST-42L-B-PN5EzM-42L-B-PN5
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN8EzM-42L-A-PN8EzS-PD-42L-A
1:8
Ezi-SERVO-ST-42L-B-PN8EzM-42L-B-PN8
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN10EzM-42L-A-PN10EzS-PD-42L-A
1:10
Ezi-SERVO-ST-42L-B-PN10EzM-42L-B-PN10
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN15EzM-42L-A-PN15EzS-PD-42L-A
1:15
Ezi-SERVO-ST-42L-B-PN15EzM-42L-B-PN15
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN25EzM-42L-A-PN25EzS-PD-42L-A
1:25
Ezi-SERVO-ST-42L-B-PN25EzM-42L-B-PN25
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN40EzM-42L-A-PN40EzS-PD-42L-A
1:40
Ez
i-SERVO-ST-42L-B-PN40EzM-42L-B-PN40
EzS-PD-42L-B
Ezi-SERVO-ST-42L-A-PN50EzM-42L-A-PN50EzS-PD-42L-A
1:50
Ezi-SERVO-ST-42L-B-PN50EzM-42L-B-PN50
EzS-PD-42L-B
Ezi-SERVO-ST-42XL-A-PN3EzM-42XL-A-PN3EzS-PD-42XL-A
1:3
Ezi-SERVO-ST-42XL-B-PN3EzM-42XL-B-PN3
EzS-PD-42XL-B
Ezi-SERVO-ST-42XL-A-PN5EzM-42XL-A-PN5EzS-PD-42XL-A
1:5
Ezi-SERVO-ST-42XL-B-PN5EzM-42XL-B-PN5
EzS-PD-42XL-B
Ezi-SERVO-ST-42XL-A-PN8EzM-42XL-A-PN8EzS-PD-42XL-A
1:8
Ezi-SERVO-ST-42XL-B-PN8EzM-42XL-B-PN8
EzS-PD-42XL-B
Ezi-SERVO-ST-42XL-A-PN10EzM-42XL-A-PN10EzS-PD-42XL-A
1:10
Ezi-SERVO-ST-42XL-B-PN10EzM-42XL-B-PN10
EzS-PD-42XL-B
Ezi-SERVO-ST-42XL-A-PN15EzM-42XL-A-PN15EzS-PD-42XL-A
1:15
Ezi-SERVO-ST-42XL-B-PN15EzM-42XL-B-PN15
EzS-PD-4
2XL-B
Ezi-SERVO-ST-42XL-A-PN25EzM-42XL-A-PN25EzS-PD-42XL-A
1:25
Ezi-SERVO-ST-42XL-B-PN25EzM-42XL-B-PN25
EzS-PD-42XL-B
Ezi-SERVO-ST-42XL-A-PN40EzM-42XL-A-PN40EzS-PD-42XL-A
1:40
Ezi-SERVO-ST-42XL-B-PN40EzM-42XL-B-PN40
EzS-PD-42XL-B
Ezi-SERVO-ST-42XL-A-PN50EzM-42XL-A-PN50EzS-PD-42XL-A
1:50
Ezi-SERVO-ST-42XL-B-PN50EzM-42XL-B-PN50
EzS-PD-42XL-B
Ezi-SERVO-ST-56S-A-PN3EzM-56S-A-PN3EzS-PD-56S-A
1:3
Ezi-SERVO-ST-56S-B-PN3EzM-56S-B-PN3
EzS-PD-56S-B
Ezi-SERVO-ST-56S-A-PN5EzM-56S-A-PN5
EzS-PD-56S-A
1:5
Ezi-SERVO-ST-56S-B-PN5EzM-56S-B-PN5
EzS-PD-56S-B
Ezi-SERVO-ST-56S-A-PN8EzM-56S-A-PN8
EzS-PD-56S-A
1:8
Ezi-SERVO-ST-56S-B-PN8EzM-56S-B-PN8
EzS-PD-56S-B
Ezi-SERVO-ST-56S-A-PN10EzM-56S-A-PN10
EzS-PD-56S-A
1:10
Ezi-SERVO-ST-56S-B-PN10EzM-56S-B-PN10
EzS-PD-56S-B
Ezi-SERVO-ST
-56S-A-PN15EzM-56S-A-PN15
EzS-PD-56S-A
1:15
Ezi-SERVO-ST-56S-B-PN15EzM-56S-B-PN15EzS-PD-56S-B
Ezi-SERVO-ST-56S-A-PN25EzM-56S-A-PN25EzS-PD-56S-A
1:25
Ezi-SERVO-ST-56S-B-PN25EzM-56S-B-PN25
EzS-PD-56S-B
Ezi-SERVO-ST-56S-A-PN40EzM-56S-A-PN40EzS-PD-56S-A
1:40
Ezi-SERVO-ST-56S-B-PN40EzM-56S-B-PN40
EzS-PD-56S-B
Ezi-SERVO-ST-56S-A-PN50EzM-56S-A-PN50EzS-PD-56S-A
1:50
Ezi-SERVO-ST-56S-B-PN50EzM-56S-B-PN50
EzS-PD-56S-B
Ezi-SERVO-ST-56M-A-PN3
EzM-56M-A-PN3
EzS-PD-56M-A
1:3
Ezi-SERVO-ST-56M-B-PN3
EzM-56M-B-PN3
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN5
EzM-56M-A-PN5
EzS-PD-56M-A
1:5
Ezi-SERVO-ST-56M-B-PN5
EzM-56M-B-PN5
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN8
EzM-56M-A-PN8
EzS-PD-56M-A
1:8
Ezi-SERVO-ST-56M-B-PN8
EzM-56M-B-PN8
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN10
EzM-56M-A-PN10
EzS-PD-56M-A
1:10
Ezi-SERVO-
ST-56M-B-PN10
EzM-56M-B-PN10
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN15
EzM-56M-A-PN15
EzS-PD-56M-A
1:15
Ezi-SERVO-ST-56M-B-PN15
EzM-56M-B-PN15
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN25
EzM-56M-A-PN25
EzS-PD-56M-A
1:25
Ezi-SERVO-ST-56M-B-PN25
EzM-56M-B-PN25
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN40
EzM-56M-A-PN40
EzS-PD-56M-A
1:40
Ezi-SERVO-ST-56M-B-PN40
EzM-56M-B-PN40
EzS-PD-56M-B
Ezi-SERVO-ST-56M-A-PN50
EzM-56M-A-PN50
EzS-PD-56M-A
1:50
Ezi-SERVO-ST-56M-B-PN50
EzM-56M-B-PN50
EzS-PD-56M-B
● 附刹车组合● 附减速机组合
● 附减速机组合
整套型号电机型号驱动器型号整套型号电机型号驱动器型号减速比
整套型号电机型号驱动器型号减速比
