Product Engineering Division
SMT Section
IM Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50394
19/21
7579
Abnormal nozzle shape
detected.
There is something wrong attached on a nozzle.
Clean or change it.
7580
Abnormal nozzle
alignment detected.
Misalignment of nozzle tip position is over the correction
limit.
The nozzle may be damaged, unclean, or skewed.
7581
Unable to perform
nozzle health check.
It is necessary to read board data, when "ManualNzlChg"
is selected.
Read board data, or
Select "AutoNzlChg" on [Machine] - [Machine Data] -
[Head] - [Head Offset].
7584
Board data has been
edited.
Save and reload the board data to apply the changes.
Product Engineering Division
SMT Section
IM Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50394
20/21
7585
Nozzle Health Check
failed
Check the conditions below and try it again.
・Execute [Unit] - [Head] - [Nozzle Change] and confirm
the nozzle is successfully changed.
・Execute [Unit] - [Head] - [Cleaning Blow] and confirm
the cleaning blow is successfully performed.
・Settings of each nozzle check (*) are correct.
（For details, refer to the operation manual.）
* “Each nozzle check” means the following items of
Nozzle Health Check.
・Vacuum Check
・Nozzle Tip Dirt Check
・Nozzle Buffing Check
・Nozzle Shape Check
・Nozzle Alignment Check
7590
Nozzle Health Check
Execution Error
Unable to execute Nozzle Health Check with [board data
nozzle] because the board data has an error.
Reload the board data and remove the cause of the error.
7591
Nozzle Health Check
Execution Error
Unable to execute Nozzle Health Check with [board data
nozzle] because board data is not read.
Read board data.
7592
Nozzle Health Check
Execution Error
Unable to execute Nozzle Health Check with [NG Nozzle]
because there is no NG nozzle.
Product Engineering Division
SMT Section
IM Operations
YAMAHA MOTOR CO., LTD
MDOC-SOFT50394
21/21
7594
Nozzle Shape Check
Error
Nozzle Shape Check failed.
[Measure]
Please confirm the state of the nozzle.
Please install a correct nozzle when a nozzle different
from the nozzle used is installed.
Please clean the nozzle when a correct nozzle is
installed.
7595
Nozzle Alignment Check
error
Nozzle Alignment Check failed.
[Cause]
- The nozzle might be dirty.
- Database number is not correct.
[Measures]
- Check whether the nozzle is dirty.
- Check whether the parts database number for Nozzle
MACS is right.
[Pickup MACS]-[Nozzle MACS]-[Database Number]
13233
(Nozzle Station) Not
enough owning nozzle
number error ▲4
Number of owning nozzle types is not enough to use for
the production.
[Cause]
- Usable nozzle is not exist. (Include spare nozzle)
[Measure]
- Clean, change or add nozzle.
- Execute [Nozzle Health Check] again.
