4OM-1610
0911-001 1-B
4OM-1610
1-1
1. Outline of Maintenance : Chap.1
1011-002
1. Outline of Maintenance
This session describes how to perform inspections, cleaning, lubrication, and
adjustment to keep the machine in good shape.
Be sure to periodically perform the maintenance tasks.
1.1 Notes on Maintenance
WARNING
Only a well-trained service person should perform
maintenance tasks carefully through the specied
procedures.
Before maintenance work, shut off the power breaker
and lock the power breaker with the padlock.
Designate a person who can have charge of the
padlock key.
If the provided padlock is lost or damaged, purchase
its substitute.
CAUTION
Even when the power breaker is set to "OFF", the
primary line is powered, making it possible to cause
an electric shock.
Be sure to completely stop the power supply to the
machine before maintenance work.
Residual voltages may remain behind for a few
minutes in the internal devices of the machine after
power interception.
Before performing maintenance work, wait until the charge
lamps of the DC power supply and the servo amplier go
"OFF" in 10 minutes or more after the power breaker is set
to "OFF".
Note
(a) Preliminary preparation is required for some maintenance tasks with the
power being supplied.
(b) Note that the linear measure sensors must be cleaned with the power being
supplied.
Although the load power to the motors, etc., is turned OFF when the
transparent cover is opened, the maintenance must be performed carefully
because you have to put your hand(s) inside the machine.
4OM-1610
1-2
1. Outline of Maintenance : Chap.1
1.2 Preparation for Maintenance
1.2.1 Preparation for Cleaning
Prepare the following items.
•
Brush
Use a brush whose bristles do not come off if possible.
•
Cotton Swab
Use a normal cotton swab on the market.
•
Rag
Use a rag made of such material as cotton, etc., that produces as less waste
thread as possible.
A clean rag must be used depending on a spot to be cleaned.
Notice
The remaining waste thread if any will cause the machine to break down.
•
Oiled Rag
Use a rag made of such material as cotton, etc., that produces as less waste
thread as possible.
Too much grease should not be applied and any different type of grease should
not be mixed into the specied one.
Notice
The remaining waste thread if any will cause the machine to break down.
•
Gloves
Use the gloves made of material (such as rubber) which leaves bers as less as
possible.
Notice
The remaining waste thread if any will cause the machine to break down.
0911-001
