DECAN_F2_S2_TRM(Ver7.4_CS20.12).pdf - 第394页
Page +$1:+$ 390 DECAN F2/S2 Axis IO Board #3 (8/8) 1 2 3 4 5 CN7 HEAD IF BOARD #2 CN18 1 2 7 8 Z1-HOME Z2-HOME Z3-HOME Z4-HOME AXIO-CN7 HD-CN18 A1 B1 A2 B2 AXIO BD #3 BOARD A3 1-1827864-5(X) 14 19 20 Z5-HOME Z6-HOME Z7-H…
Page
+$1:+$
389
DECAN
F2/S2
Axis IO Board #3 (7/8)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-014690B CABLE ASSY-RSW_DRV_COMMAND 5 AM03-010981A/ AM03-014690A
2 AM03-014687A CABLE ASSY-RSW_MOTOR_PWR 1 AM03-010890B
3 AM03-026274A CABLE ASSY-DECAN FLAT 2[SM511_FL002] 1 AM03-010516C
4 AM03-015237A CABLE ASSY-SWING MOTOR 1 AM03-005611A/ AM03-005611B
5 AM03-010891A CABLE ASSY-RSW_MOTOR_ENC 1
Page
+$1:+$
390
DECAN
F2/S2
Axis IO Board #3 (8/8)
1
2
3 4 5
CN7
HEAD IF BOARD #2
CN18
1
2
7
8
Z1-HOME
Z2-HOME
Z3-HOME
Z4-HOME
AXIO-CN7 HD-CN18
A1
B1
A2
B2
AXIO BD #3
BOARD
A3
1-1827864-5(X)
14
19
20
Z5-HOME
Z6-HOME
Z7-HOME
Z8-HOME
30GND
501189-3010
B3
A4
B4
A5
B5
13
1
2
7
8
14
19
20
30
13
Z1-HOME
Z2-HOME
Z3-HOME
Z4-HOME
Z5-HOME
Z6-HOME
Z7-HOME
Z8-HOME
GND
A1
B1
A2
B2
A3
B3
A4
B4
A5
B5
CN1
SM511_FL001(15)
1
2
3
4
AM03-026275A
HD-PW HD-CN1
B1
B2
A1
A2
1-1827864-243020-0400
B1
B2
A1
A2
+24V
+24V
24G
24G
CN9
CN19
1
2
7
8
Z9-HOME
Z10-HOME
R1-HOME
R2-HOME
AXIO-CN9 HD-CN19
A1
B1
A2
B2
A3
1-1827864-5(X)
14
19
20
R3-HOME
R4-HOME
R5-HOME
SW-HOME
30GND
501189-3010
B3
A4
B4
A5
B5
13
1
2
7
8
14
19
20
30
13
A1
B1
A2
B2
A3
B3
A4
B4
A5
B5
SM511_FL002(15)
AM03-026274A
Z9-HOME
Z10-HOME
R1-HOME
R2-HOME
R3-HOME
R4-HOME
R5-HOME
SW-HOME
GND
GND
CN3
A1
A2
A3
B1
CAN_H
CAN_L
/IO_RESET
+24G
AXIO#3-CN3 SC-J8L-2
A1
B1
A2
B2
A3
J25MF-06V-K
B3
12V GND
+12V
1-1827864-3 (X)
B3
B2
SM511_CA102-4
AM03-010790E
A1
A2
A3
B1
B3
B2
A4
B4
A5
B5
A6
B6
SC-J8L
J25DPM-20V-K
SM511_CA201
AM03-010794A
SC-J3R
J25DPM-20V-K
A1
B1
A2
B2
A3
B3
SC-J3R-2
J25MF-06V-K
SM511_CA101-3
AM03-010787B
RFD-CN3
1
2
3
4
5
DF1B-6DS-2.5RC
6
1
2
3
4
5
6
REAR FEEDRR IO B/D
CN3
+12V
CAN_H
CAN_L
/IO_RESET
+24G
12V GND
A4
B4
A5
B5
A6
B6
Page
+$1:+$
391
DECAN
F2/S2
Axis IO Board #3 (8/8)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 AM03-026275A CABLE ASSY-DECAN FLAT 1[SM511_FL001] 1 AM03-010515C/ AM03-010515D
2 AM03-026274A CABLE ASSY-DECAN FLAT 2[SM511_FL002] 1 AM03-010516C
3 AM03-010790E CABLE ASSY-AXIO_BD_3_RFD_CAN_J8L 1 AM03-010790B/ AM03-010790C
4 AM03-010794A CABLE ASSY-AXIO_CAN_FDR_UL_J3R-J8L 1
5 AM03-010787B CABLE ASSY-AXIO_BD_3_RFD_CAN_J3R 1
