680SD BRUSHLESS SERVO PUMP
Installation Procedures
2 680SD Brushless Servo Driven Pump
Installation Procedures
Introduction The 680SD pump is mounted directly to the Flex Dispenser Z -axis mounting plate
using the supplied Z-axis mounting adapter.
In this Section Refer to the following:
Topic See Page
Installing a Needle 3
Mounting the Pump 4
Electrical Connection 5
Pump Pneumatic Connections 6
Syringe Air Connections 7
.
.
.
.
.
680SD BRUSHLESS SERVO PUMP
Installing a Needle
Operation and Maintenance Guide 3
Installing a Needle
Procedure Reference Figure 7 when performing the following:
Attention
The needle can be installed with the pump on or off the machine.
1. Unscrew the needle holder nut from the bottom of the pump cartridge.
2. Drop a needle into the needle holder nut and thread the assembly onto the bot-
tom of the cartridge. Make sure that the needle is centered within the needle
holder nut. While turning the nut, a spring tension, created by the self-centering
action of the leadscrew, will be felt.
3. Tighten the needle holder nut (by hand only) until the assembly is tight.
680SD BRUSHLESS SERVO PUMP
Mounting the Pump
4 680SD Brushless Servo Driven Pump
Mounting the Pump
Procedure Attach the mounting bracket to the Z-axis plate as follows:
1. Loosen the four socket head cap screws that secure the Z-axis mount assembly
to the pump and remove the mount assembly. The socket head cap screws are
held captive by cross-point screws.
2. Align the bottom edge of the mount assembly as flush as possible with the bot-
tom edge of the A-axis mounting plate.
3. Using two socket head cap screws and washers, secure the mount assembly to
the Z-Axis mounting plate.
Attention
The lower edge of the pump body should always protrude past the bottom of the Z-
axis slide when in place.
4. Assemble the pump to the Z-axis assembly mount so that the two locating pins
on the mount engage in the pump body.
5. Secure the pump to the mount with four socket head cap screws.
