W indows XP Em bedded / I nstallat ion Ma nual Ausgabe 06/2013 Ed ition 10 Nam e SIMAT IC Box PC 82 7B CPU / cloc k fr equency Core 2 Duo T 740 0 / 2,16 G Hz RAM 2 GB Harddis k Yes External D VD dr ive No Internal D VD d…

Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition

Name SIMATIC BoxPC 627C

CPU / clock frequency Intel(R) Celeron(R) P4505 / 1,87 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-3: Machine/Vision computer hardware SIPLACE X-series

3.2.1.2 Machine/Vision Computer (in One-Computer Operation)

Name SIMATIC BoxPC 627B

CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and

external USB hub

Yes

Network 2x 100 MBit

Table 3-4: Machine/Vision computer hardware SIPLACE SX1/2 and D-series

Name SIMATIC BoxPC 627C

CPU / clock frequency Intel(R) Celeron(R) P4505 / 1,87 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-5: Machine/Vision computer hardware SIPLACE SX1/2 and D-series

Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition

Name SIMATIC BoxPC 827B

CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz

RAM 2 GB

Harddisk Yes

External DVD drive No

Internal DVD drive Yes

Serial interfaces 1

USB interfaces Yes

External USB hub Yes (X-series) / No (SX4)

Network 2x 100 MBit

Table 3-6: Machine/Vision computer hardware SIPLACE X-series and SX4

Name SIMATIC BoxPC 827C

CPU / clock frequency Intel(R) Core(TM) i3 / 2,13 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-7: Machine/Vision computer hardware SIPLACE X-series and SX4

Name I-Base ABP102-A

CPU / clock frequency Celeron® Dual Core T3100 / 1,9 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 1000 MBit

Table 3-8: Machine/Vision computer hardware SIPLACE D-series

Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition

4 Installation

4.1 Overview

Install Boot CD/DVD

Choose computer configuration

CD SIPLACE XP embedded Configurator

Install and calibrate Touchscreen

BIOS settings on the machine/Vision

computer

Perform BIOS settings

Back up the machine data

BIOS update on the machine/Vision

computer

Perform BIOS update

Restore CD

CPU 627/627B/

827B, I-Base

Restore DVD

CPU 627C/827C

Restore the initial configuration

See section 4.2.

Installing the operation system Windows XP

embedded, see section 4.3.

See section 4.3.2.

See section 5.

See section 6.
