Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition

3 Prerequisites for Installation

3.1 Software Components

Standard package Software SIPLACE Station as of version 605.03 SP1:

SR 605.03 SP1, item no. [00140001-06] or

Standard package Software SIPLACE Station as of version 704.01:

SR 704.01, item no. [00388544-01]

3.2 Hardware Components of the Computer System for the

Machine/Vision Computer

3.2.1 SIPLACE X- and SX-Series Hardware Components

3.2.1.1 Machine/Vision Computer (in Two-Computer Operation)

Name SIMATIC BoxPC 627

CPU / clock frequency Pentium M 760 / 2 GHz

RAM 1 GB

Hard disk Yes

External DVD drive Yes (1 per machine)

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-1: Machine/Vision computer hardware SIPLACE X-series

Name SIMATIC BoxPC 627B

CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes (1 per machine)

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-2: Machine/Vision computer hardware SIPLACE X-series

Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition

Name SIMATIC BoxPC 627C

CPU / clock frequency Intel(R) Celeron(R) P4505 / 1,87 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-3: Machine/Vision computer hardware SIPLACE X-series

3.2.1.2 Machine/Vision Computer (in One-Computer Operation)

Name SIMATIC BoxPC 627B

CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and

external USB hub

Yes

Network 2x 100 MBit

Table 3-4: Machine/Vision computer hardware SIPLACE SX1/2 and D-series

Name SIMATIC BoxPC 627C

CPU / clock frequency Intel(R) Celeron(R) P4505 / 1,87 GHz

RAM 1 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-5: Machine/Vision computer hardware SIPLACE SX1/2 and D-series

Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition

Name SIMATIC BoxPC 827B

CPU / clock frequency Core 2 Duo T7400 / 2,16 GHz

RAM 2 GB

Harddisk Yes

External DVD drive No

Internal DVD drive Yes

Serial interfaces 1

USB interfaces Yes

External USB hub Yes (X-series) / No (SX4)

Network 2x 100 MBit

Table 3-6: Machine/Vision computer hardware SIPLACE X-series and SX4

Name SIMATIC BoxPC 827C

CPU / clock frequency Intel(R) Core(TM) i3 / 2,13 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 100 MBit

Table 3-7: Machine/Vision computer hardware SIPLACE X-series and SX4

Name I-Base ABP102-A

CPU / clock frequency Celeron® Dual Core T3100 / 1,9 GHz

RAM 2 GB

Harddisk Yes

External DVD drive Yes

Internal DVD drive No

Serial interfaces 1

USB interfaces and external USB hub Yes

Network 2x 1000 MBit

Table 3-8: Machine/Vision computer hardware SIPLACE D-series
