1 Overview
This installation manual provides instructions on installing the Windows XP Embedded SP2
(627B/827B) / Windows XP Embedded SP3 (I-Base) / Windows Embedded Standard (XPe
SP3) (627C/827C) operating system for the machine computer and (optionally) for the Vision
computer with station software:
– 605.03 SP1 version for D-series placement machines in one-computer operation
– 605.03 SP2 version for placement machines with computer type BoxPC 627C / 827C
– 605.x version for D-series placement machines with computer type I-Base
– as of the 704 version
It contains information on the scope of delivery and requirements for successful installation.
NOTICE
The Windows XP Embedded operating system is only used for new installations. On
upgrading to a higher station software version, there will be no operating system change
from Windows XP Professional to Windows XP Embedded (XPe SP3).
Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition
6
2 Scope of Delivery
A media standard package is available for installing the Windows XP Embedded SP2 / Windows
XP Embedded SP3 / Windows Embedded Standard (XPe SP3) operating system. It contains
different CDs/DVDs for the machine types.
CAUTION
It is imperative that the installation CD/DVD from the standard package for the relevant
computer type is used to install the operating system on a machine/Vision computer.
Operating system media package XP emb. V3.2, item no. [03097965-03]
– Restore CD CPU 627/627B/827B V1.0
– Restore DVD CPU 627C/827C V1.0
– Restore CD I-Base ABP102-A
– Software CD "SIPLACE XP embedded Configurator V3.2", item no.: [00388543-06]
– Ghost OEM Corporate License
– Installation Manual "Operating System Windows XP Embedded", item no. [00196737-07]
– Packaging
Software WIN eXP Runtime, item no. [03053899-01]
– eXP Sticker
– MS-WIN eXP Runtime Sticker
– MS-WIN eXP Runtime License
– Montagehinweis Embedded System License 01
– MS-WIN eXP Runtime EULA
Windows XP Embedded / Installation Manual Ausgabe 06/2013 Edition
7
Overview Machine and Vision Computer types
X2 X3 X4 X4I SX1/SX2 SX4 D-series
SIMATIC BoxPC 627,
two-computer operation
X
X
X
X
SIMATIC BoxPC
627B/627C,
two-computer operation
X
X
X
X
SIMATIC BoxPC
627B/627C,
one-computer operation
X X
SIMATIC BoxPC
827B/827C,
one-computer operation
X
X
X
X
X
I-Base PC,
one-computer operation
X
Table 2-1: Overview Machine and Vision Computer types
The Windows XP Embedded operation system is supported in the following combinations:
– Windows XP Embedded SP2: BoxPC 627/627B/827B
– Windows Embedded Standard (XPe SP3): BoxPC 627C/827C
– Windows XP Embedded SP3: I-Base ABP102-A
