7 Issue 06, December 2020
Services Required
ASM requires additional machine supply protection with the fitment of an external double
pole circuit breaker conforming to national/federal regulations. Use the following table to
ensure the recommended circuit breaker is used.
Voltage
Frequency
Value of Supply Circuit
Breaker
Type of Circuit
Breaker
230V +/- 10%
(207 to 253V)
50/60Hz
16 Amp
C
CAUTION
OVER CURRENT PROTECTION. An over current circuit
breaker protects the machines internal wiring and
components from over heating or catching fire during fault
conditions. Under no circumstances must a circuit breaker
of greater value than 16 Amps be used
WARNING
Connect to a properly earthed/grounded outlet.
.
Transportation
The unit may only be lifted using suitable equipment capable of lifting 120Kg.
Move the unit to the location where it is going to be installed and remove the unit from its
transportation crate along with any accessories. Remove the protective covering.
CAUTION
FORK LIFTING. The lifting forks must enter under the
machine from either end of the transportation crate only.
Care must be taken to ensure stability at all times.
8 Issue 06, December 2020
Power Supply Connection
WARNING
All electrical connections should be carried out by suitably
qualified personnel ensuring relevant rules and regulations
are observed.
WARNING
To reduce the risk of fire, electric shock, or injury:
Connect to a properly earthed/grounded outlet.
Use only as described in the manual.
Isolate from power supply before opening covers.
WARNING
LETHAL VOLTAGE. Dangerous voltages exist within this
equipment. Ensure all electrical covers and main machine
covers are fitted before operating equipment.
WARNING
ELECTRICAL HAZARD. If any damage to the electrical cable
is found the unit must not be connected. Installation is to
cease until inspected by a qualified electrician.
1. Check the integrity of the electrical power supply cable.
2. Test the mains input at the isolated supply is the correct voltage and frequency
before proceeding.
3. Connect to the mains supply.
9 Issue 06, December 2020
Condensate Collection
Condensate is collected in the plastic container at the base of the machine and is
accessed from the rear (FIG 1).
FIG 1
Alternatively, condensate can be diverted directly to a drain via pipe work (not included)
connected to the spout on the underside of the condensate tray (FIG 2 – Condensate
Collector removed).
FIG 2
