Sonic Buzzer S F C - Serie.pdf - 第32页
2 Retrofit instructions SOKO Sonic Buzzer SIPLACE S / F / C-series SOKO 04/2006 Edition 32 : Place the son ic buzzer on the PC ho lder . 2 2 : Connect the connector X1 together . : Replace the st ation computer again. 2 …
SOKO 2 Retrofit instructions SOKO Sonic Buzzer SIPLACE S / F / C-series
04/2006 Edition
31
2
2
: Place all cables safely inside the machine.
: Close all cable ducts.
: Hook in the servo unit and control unit and tighten them.
: Close all machine covers.
2
2
2
2
2
2
2
2
2
2
S-27 HM
2 Retrofit instructions SOKO Sonic Buzzer SIPLACE S / F / C-series SOKO
04/2006 Edition
32
: Place the sonic buzzer on the PC holder.
2
2
: Connect the connector X1 together.
: Replace the station computer again.
2
2
2
2
2
2
2
SOKO 2 Retrofit instructions SOKO Sonic Buzzer SIPLACE S / F / C-series
04/2006 Edition
33
2.7 Circuit diagrams
2.7.1 Control unit
2
Wire colour
Input/ Output Function Terminal designation
Pink
Input + 24V P
Grey
Input Ground (0V) M
White
Input Signal light right I1
Yellow
Input Signal light left I2
Blue
Input Stop or reset I3
Brown
Output +24V Q1
White
Output Ground (0V) M
