Installation manual SIPLACE Pro 1 Introduction Edition 12/2006 US 5 Note: Please use the document " Navigation Guide for the Ins tallation Procedure of SIPLACE Sof t- ware Systems " (Item No. 00195050- xx) to n…

1 Introduction Installation manual SIPLACE Pro

Edition 12/2006 US

1.2 Scope of Delivery

The SIPLACE Pro 4.1 software package contains the following software and

documentation: 1

1 CD-ROM “SIPLACE Pro”, which contains: 1

– SIPLACE Pro 4.1 Setup

– Microsoft MSDE SP4

– Adobe Acrobat Reader 6.0

– AppSightCode Black Box

– DotNetFramework 1.1

– DotNetFramework 1.1 SP1

– DotNetFramework 2.0

1 SIPLACE Pro Factory License (without licence for the connection to SIPLACE stations) 1

1 CD-ROM with OIS 4.1 Server and Client 1

1 DVD Support Media 1

Documentation: 1

Basic documents: 1

– Software Version Description SIPLACE Pro 4.1

(German 00195340-01; English 00195358-01)

– Getting Started with SIPLACE Pro 4.1

(English: Item No 00195340-01, German: Item 00195341-01)

– Installation of SIPLACE Pro 4.1 (Item No 00195342-01)

Detailed installation manuals: 1

– Configurations for SIPLACE Pro (English Item No. 00193760-xx)

– Guideline for XML Import / Export (English Item No. 00193789-xx)

– Standard Component Shape Library Handling (English: Item No. 00194625-xx)

– Software Version Description SIPLACE CAD V4.1 (English: Item No. 00194678-xx)

– Retrofitting Instructions for the option Recovery Placement (with NAS)

(English/German: Item No. 00194597-xx)

Installation manual SIPLACE Pro 1 Introduction

Edition 12/2006 US

Note:

Please use the document "Navigation Guide for the Installation Procedure of SIPLACE Soft-

ware Systems" (Item No. 00195050-xx) to navigate through the documentation. The navigation

guide and all related documents are available on the Support Media DVD (Art. No. 00383100-

xx) that is added to any software product. 1

1 Introduction Installation manual SIPLACE Pro

Edition 12/2006 US

1.3 System requirements

The following hardware is required for a successful SIPLACE Pro 4.1 installation. 1

1.3.1 SIPLACE Pro Server

The following Hardware is recommended for the SIPLACE Pro Server: 1

– Pentium 4 with 3.0GHz or higher

– 2x 80GB hard disk

– 1024 MB memory (512 MB min.)

– Backup drive (e.g. DAT, CD, DVD)

– 21” screen (19’’ min.)

– optional SR-UPS

The following Software is required: 1

– Windows 2003 Server Standard Edition (optional with SP1) and SQL 2000 with SP4, or

– Windows XP Professional with SP2 and MSDE 2000 with SP4 and

– Microsoft .NET Framework 1.1, and

– Microsoft .NET Framework 1.1 SP1, and

– Microsoft .NET Framework 2.0

Note:

A hard disk with 500 MB or more free space should be used for installation (without the operating

system installed there should be at least 1 GB free space). 1

Note:

Windows 2003 Server SP1 is supported, but not required for the SIPLACE Pro installation. 1

Note:

If Microsoft .NET Framwork 2.0 is installed prior to SIPLACE Pro and then the programming sys-

tem SIPLACE Pro, Microsoft Windows Installer 3.0 could be required. The Microsoft Windows In-

staller 3.0 (instmsi30.exe) is available in the root folder of the product CD. 1
