Excellent Modular Component Placer EXCEN Series EXCEN PRO(M)/(D)/(L) Technical Reference.pdf - 第53页
Page +$1:+$ 47 Cart Clamp AR /BF EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L) NO. P ART NO. P ART NAME Q' TY Old No. Su pply Supply L T Reference 1 FC15-001438B COVER-V1P15-FEEDER_COVE R_B 1 2 EP02-001637B HARNESS-CART LO…
Page
+$1:+$
46
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Cart Clamp AR /BF
4
4
5
6
22
42
42
42
56
17
42
29
11
18
18
18
30
21
23
44
44
51
33
49
34
38
44
44
46
31
1
2
32
9
8
50
43
52
55
52
22
22
22
14
32
2
15
16
7
A
10
35
36
37
40
36
35
39
18
33
54
31
41
20
24
25
47
18
48
35
52
36
36
35
39
40
41
53
28
26
27
13
11
12
22
30
19
52
53
45
45
54
3
OPTION
57
Page
+$1:+$
47
Cart Clamp AR /BF
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 FC15-001438B COVER-V1P15-FEEDER_COVER_B 1
2 EP02-001637B HARNESS-CART LOCK RELEASE SENSOR CABLE 2
3 FC09-002112B BRACKET-SENSOR_BKT_L 1 FC09-002112A
4 J70621029A NUT_PLT_A J70621029A 4
5 FC09-002513B BRACKET-V1P15-FEEDER_COVER_BKT_L_B 1
6 FC29-007042A BRACKET-MTV1PP-FB006A-GUIDE_BKT_H2 1 FC09-002470A/ FC09-003682A/ FC09-004327A
7 FC09-003689A BRACKET-MTV1PP-FB011A-CC_SENSOR_BKT_1 1 FC07-000584A
8 J72651385A GUIDE_PLT_B_R 1
9 FC07-001214A BLOCK-MTV1PP-FB009A-GUIDE_PLT_H2 1 FC09-001087A
10 EP19-000104 SENSOR-PHOTO_SENSOR_E3T-FD12_OMRON 1
11 FC18-000062A SPACER-V1_CC_SPACER_A 10
12 J71631003A GUIDE_PLT_A_R J71631003A 1
13 J71631004A GUIDE_PLT_B_L J71631004A 1
14 FC29-007041B GUIDE-PRO-CC_GUIDE_COMB_C_B 1 J70621019A/ FC29-007041A
15 FC09-002113B BRACKET-SENSOR_BKT_R 1 FC09-002113A
16 FC09-002512B BRACKET-V1P15-FEEDER_COVER_BKT_R_B 1
17 FC09-001796B BRACKET-PRO_CC_CYL_COVER_A 1 FC09-001796A
18 FC28-000033A POST UNIT,TOOL-V1_CC_POST_AA;ME1:Steel 5
19 J70621036A X_GUIDE_A J70621036A 1
20 FC09-004281A CN_BKT 1 J70621030A
21 J70621035A STOPPER J70621035A 2
22 FC18-903189 TIE_MOUNT 4
23 J70621015A STOPPER_BLK_L J70621015A 1
24 FC09-001792B BRACKET-V1-CARTCLAMP_BASE_PLT_A 1
25 FC09-001797A BRACKET-V_CARTCLAMP_CYL_COVER_B 1
26 J70621016A STOPPER_BLK_R 1
27 FC09-004282A CN_BKT_B 1 J70621039A
28 HP06-900018 FITTING [KQ2U06-00/PY6M] 2 HP06-900152
29 FC09-001793B BRACKET-V1-CARTCLAMP_BASE_PLT_B 1 FC09-001793A
30 MC03-000056 BEARING,NEEDLE 2
31 FC29-006667A BRACKET-V_CC_CAM_FOLLOW_HOLDER 2 FC09-001800A
Page
+$1:+$
48
Cart Clamp AR /BF
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 EP02-001990A HARNESS-FDR UNLOCK 2 SNS CABLE ASSY 2
33 FC18-000081 NUT-NUT;M12 1,ME1:Steel 2
34 J70621031A CAM_B_L J70621031A 1
35 FC29-000145A COLLAR-V1_CC_COLLAR_B;ME1:Steel 1
36 MC03-900116 BEARING 6000ZZNR 4
37 J70621013A LEVER_L J70621013A 1
38 FC18-000344A HOOK-HOOK_CF 1
39 J70621017A BLOCK J70621017A 2
40 FC29-000146A COLLAR-V1_CC_COLLAR_C;ME1:Steel 2
41 FC14-000122 END,STUB-ROD END 2
42 HP06-900076 ELBOW_FITTING KQ2L06-01S 4 HP14-900109
43 HP03-001001 CYLINDER-CYLINDER;AQ2D40-75D,1MPa,75 1 HP03-000011/ HP03-000124
44 FC18-901667 C-RING(SHAFT) 4
45 FC18-901969 SOCKET_HEAD_SET_SCREW 0
46 FC09-001801A BRACKET-V_CARTCLAMP-CYL_FI_BLOCK_1 1
47 J70621034A CAM_B_R J70621034A 1
48 J70621014A LEVER_R J70621014A 1
49 FC18-000352A HOOK-HOOK_CR 1
50 HP03-001002 CYLINDER-CYLINDER;ADQ2D40-75D,1MPa,75 1 HP03-000012 /HP03-000025
51 FC09-001802A BRACKET-V_CARTCLAMP-CYL_FI_BLOCK_2 1
52 FC18-901050 HEX NUT [M8 (BL/ZN)] 1
53 FC18-902792 SOCKET HEAD CAP SCREW [M8*35 (BL/ZN)] 1
54 FC15-004845A COVER-V10-DT_DC_FEEDER_COVER_C;COVER 1 PRO(D) EXTENSION OPTION
55 FC09-007489A BRACKET-MTED-CC001A_FEEDER_COVER_BKT_L 1 PRO(D) EXTENSION OPTION
56 FC09-007490A BRACKET-MTED-CC002A_FEEDER_COVER_BKT_R 1 PRO(D) EXTENSION OPTION
57 PT03-000252A STICKER-STICKER-FEEDER_NUMBER_DC;BONDING 1
