Page +$1:+$ 89 EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L)
Page
+$1:+$
88
Large Conveyor(3/7) Front Move
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 J70532064A IDLER_SPACER J70532064A 64
33 MC03-900045 BALL_BEARING_685ZZ-STF100N #685ZZ 32
34 MC19-000422A PULLEY-IDLER_S2M 32
35 J70531836A IDLER_SHAFT J70531836A 32
36 FC09-007277A BRACKET-CONV_PIN_DETECT_BKT 4
37 MC19-000429A SHAFT-PCB_CLAMP_ADJUST_SHAFT 16
38 MC05-001005 BELT,TIMING-60_S2M_1330_GB;1330,6,1.36 8
39 MC05-000142 TIMING BELT-S2M_MID_HTBN800S2M-60;S2M 4
40 FC29-001426A COLLAR-BALL_BUSH_COLLAR 8
41 MC06-900006 BALL_BUSH LMU5 8
42 MC19-000426A SHAFT-BALL_BUSH_SHAFT_M 8
43 MC19-000427A SHAFT-HEX_POST_M 8
44 FC30-004971A PLATE-MTV1PP-L_PCB_CLAMPING_PLATE 8
45 FC30-001034A PLATE-REINFORCE_PLATE 16
46 FC30-001048A PLATE-NUT_PLATE 16
47 FC18-901353 C-RING #10 (SHAFT, BL/ZN) 38
48 J70532067A CLAMP_BALL_BUSH_SHAFT J70532067A 16
49 MC03-900112 BALL_BUSH LM5L 16
50 FC07-001115A BLOCK-BUSH_2 8
51 FC07-001114A BLOCK-BUSH_1 8
Page
+$1:+$
89
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
Page
+$1:+$
90
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Large Conveyor(4/7) Rear Move
Rear side
Front side
Front side
Rear side
40
42
41
43
46
51
9
47
30
32
34
29
12
28
25
22
23
5
8
7
1
39
38
21
20
19
18
24
10
11
6
48
50
47
17
35
33
27
36
26
27
2
3
4
16
15
14
13
49
37
44
45
38
31
8
