Page +$1:+$ 53 Cart Clamp AR /BF - Direct Tray Docking Cart Option EXCEN PRO(M) EXCEN PRO(D) EXCEN PRO(L) NO. P ART NO. P ART NAME Q' TY Old No. Su pply Supply L T Reference 1 FC07-003702A BLOCK-DT_ DC_COVER_GUIDE_B…
Page
+$1:+$
52
EXCEN PRO(M)
EXCEN PRO(D
)
EXCEN PRO(L)
Cart Clamp AR /BF - Direct Tray Docking Cart Option
40
41
42
43
44
22
6
1
10
7
4
23
22
18
12
11
47
19
19
18
16
1
46
25
26
27
24
28
29
30
4
31
32
33
5
6
8
16
17
13
16
15
14
14
15
16
36
23
35
21
9
3
45
38
39
20
21
47
12
34
37
2
Page
+$1:+$
53
Cart Clamp AR /BF - Direct Tray Docking Cart Option
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
1 FC07-003702A BLOCK-DT_DC_COVER_GUIDE_BLOCK_A 2
2 FC15-004847A COVER-V10-DT_DC_SIDE_COVER_LD;COVER 1
3 FC15-004845A COVER-V10-DT_DC_FEEDER_COVER_C;COVER 1
4 J70621029A NUT_PLT_A J70621029A 2
5 FC09-007408A BRACKET-DC_SENSOR_BKT_L 1
6 EP02-001637B HARNESS-CART LOCK RELEASE SENSOR CABLE 2
7 FC09-007409A BRACKET-DC_CONNECTOR_BKT_L 1
8 FC09-007407A BRACKET-DC_SENSOR_BKT_UL 1
9 EP02-001635A HARNESS-CART CLAMP SENSOR CABLE ASSY 1
10 FC30-004719A PLATE-DC_DOCKING_PLATE 1
11 FC07-003502A BLOCK-DC_DOCKING_HOLDER_L 1
12 FC29-008469A GUIDE-DC_DOCKING_SLIDE_GUIDE_A 1
13 AM03-020358A ASSY,AIR-CYLINDER_ASSY_B 1
14 FC29-001131 HINGES-CLBRM8_22 1
15 FC07-003503A BLOCK-DC_CYLINDER_FIX_A 1
16 MC03-001039 BEARING,BALL-F688AZZ1 2
17 FC24-001008A LEVER-DC_CYLINDER_LEVER_A 1
18 FC07-003504A BLOCK-DC_CYLINDER_FIX_C 1
19 FC24-001007A LEVER-DC_CYLINDER_LEVER_PIN 1
20 FC29-007669A HOLDER-DC_GUIDE_PIN_HOLDER_L 1
21 HP14-900109 SPEED_CONTROLLER AS2201F-01-06S 2
22 HP03-001031 CYLINDER-CDQ2D20-15DZ-M9BW;0.5,15 1
23 MC03-001040 BEARING,ROD-END-JMT5 1
24 AM03-020834A ASSY,JIG-DC_FD_SENSOR_JIG_ASSY 1
25 FC30-004797A PLATE-DC_FD_SENSOR_JIG_C 1
26 FC30-004798A PLATE-DC_FD_SENSOR_JIG_B 1
27 FC30-004796A PLATE-DC_FD_SENSOR_JIG_A 1
28 FC30-004719A PLATE-DC_DOCKING_PLATE 1
29 FC07-003501A BLOCK-DC_DOCKING_HOLDER_R 1
30 FC09-007411A BRACKET-DC_SENSOR_BKT_R 1
31 FC09-007410A BRACKET-DC_CONNECTOR_BKT_R 1
Page
+$1:+$
54
Cart Clamp AR /BF - Direct Tray Docking Cart Option
EXCEN PRO(M)
EXCEN PRO(D)
EXCEN PRO(L)
NO. PART NO. PART NAME Q'TY Old No. Supply Supply LT Reference
32 FC15-004848A COVER-V10-DT_DC_SIDE_COVER_RD;COVER 1
33 FC18-000311 NUT,ETC-SPRING_NUT_M6;SQUARE,SPRING_NUT, 2
34 FC09-007852A BRACKET-DT_DC_SIDE_COVER_R_BKT 1
35 AM03-020359A ASSY,AIR-CYLINDER_ASSY_C 1
36 FC24-001009A LEVER-DC_CYLINDER_LEVER_B 1
37 FC29-007668A HOLDER-DC_GUIDE_PIN_HOLDER_R 1
38 HP06-001123 FITTING-KQ2L06-M5;KQ2L06-M5 2
39 FC09-007405B BRACKET-DC_CONNECTOR_BKT_B_B 1
40 FC18-003805A SPACER-DC_CONNECTOR_BKT_SPACER 2
41 FC38-000004A SPRING-V1_CUT_SPRING;ME1:Steel 2
42 FC09-007412A BRACKET-DC_CONNECTOR_BKT_A 1
43
44 FC09-007406B BRACKET-DC_CONNECTOR_BKT_C_B 1
45 FC14-000876 COUPLER-KD_M5_SA 2
46 PT03-000111A STICKER-STICKER-FEEDER_NUMBER; 1
47 EP02-001990A HARNESS-FDR UNLOCK 2 SNS CABLE ASSY 2
PT03-000252A STICKER-STICKER-FEEDER_NUMBER_DC;BONDING 1
